RTC-500/RTC-500-WIFI Temperature and Humidity Controller...
Page 3
1. Introduction The Robertshaw RTC-500 / RTC-500-WIFI is a digital controller that has two output sockets to control temperature (work1) and humidity (work2). This controller comes with two probes, a dual temperature and humidity sensor and a fully submersible temperature sensor. The large LCD screen intuitively displays temperature, humidity and other parameters.
3. Operation Important: Improper use of the product may cause injury or product damage. Please read, understand and follow the operating steps below. 3.1 Sensor Installation Plug the sensor fully into the 3.5mm jack on the bottom of the main controller. 3.2 Power On Power on controller by plugging into electrical outlet (within the range of 100-240VAC).
3.3 Parameter Setting Parameters can be set on the Robertshaw app for RTC-500-WIFI (Section 8 of manual). Plug the RTC-500 in to power on the controller. On the home screen, press and hold the SET button until you hear a beep and the TCH parameter displays. To adjust parameters: 1.
Page 7
Parameter Function Description Ranges Sets a high limit that will alert you if Humidity Alarm Hpv rises above your set value. 5 to 99%RH High Limit (EHH code) The time interval for its power off Humidity to power on again should meet the 0 to 10 Protection Delay time requirement for HPT...
Page 8
4. Function Descriptions 4.1 Temperature Setting – TCH, TS, TD Cooling mode (TCH=C) When Tpv is higher than TS + TD, will appear, Work1 will be turned on, and cooling will begin. When Tpv is lower than TS, will disappear, Work1 will be turned off, and cooling will stop.
Page 9
4.4 Temperature Calibration - TCA The temperature can be calibrated if the Tpv deviates from the actual temperature. Tpv after calibration = Tpv before calibration + TCA 4.5 Temperature Unit – CF The temperature unit can be switched between Celsius and Fahrenheit. The temperature-related parameter values will be restored to factory default values after the temperature unit is changed.
Page 10
4.7 Humidity Protection Delay – HPT Work2 is a humidity socket and the time interval for its power off to power on again should meet the time requirement for HPT. If not, will flash. This protection time requirement should also be satisfied when the controller is just powered on.
5. Alarm In the following circumstances during operation, the buzzer will give a “bi-bi-Biii” alarm, and at the same time, the alarm symbol will appear on the screen. Press any button to mute the alarm. 6. Equipment Installation As a safety precaution, it is recommended to power on the equipment after the installation is completed.
Page 12
Please do not power off the equipment during the restoration process. 8. Access to Network (for RTC-500-WIFI) RTC-500-WIFI features a built-in WiFi module that allows you to remotely view and configure it on the app. 8.1 Before You Begin, Please Make Sure: The device supports 2.4G WiFi, (5G WiFi is not compatible).
Page 13
6. Ensure the RTC-500-WIFI is plugged in and powered on. Then press and hold the and SET button at the same time until the AP character is displayed. Once it is displayed, select the YES button in the app. 7. Now enter your WiFi and the correct password.
Length of output power cable: 1ft Length of sensor cable: 6.5ft (including probe length) Enclosure size: 153mm x 60mm x 29m WiFi type available on RTC-500-WIFI: 2.4G (does not support 5G) Complies with FCC Standards Warranty: 3 Year Limited Warranty...
