Summary of Contents for Dakota USA-WD2100
-
Page 2: Typical Installations
TYPICAL INSTALLATIONS *Dimensions are mm Heavy Duty 1/2 HP 254mm Super Duty 3/4 HP 254mm Deluxe 1-1/4 HP 254mm SINGLE BOWL DOUBLE BOWL CENTER OUTLET DOUBLE BOWL END OUTLET *Dimensions are mm Basic Model 1/2 HP 203mm... -
Page 3: Important Safety Instructions
SEE INSERT FOR SPECIFIC INFORMATION ABOUT YOUR NEW DISPOSER NOTE: This Food Waste Disposer has been designed to operate with your appropriate household current exclusively. Using any other voltage or Hz adversely affects performance. IMPORTANT: Read all instructions thoroughly. Keep this guide for reference. CAUTION: Be sure to review instructions pertaining to a risk of fire, electric, shock or personal injury before using disposer. RECORD IMPORTANT DISPOSER INFORMATION HERE Model Number: Serial Number: *The above information appears on the label affixed to bottom of the disposer. For your... -
Page 4: Removal Of Old Unit
1. REMOVAL OF OLD UNIT Typical instructions, your model may vary. Before starting this step, turn off electrical power at the circuit breaker or fuse box. Unplug disposer. If your old mount is the same type as the mount on your new disposer, just reverse the assembly instructions found in section 3. If your new mount system is different, follow these instructions: A. Use a pipe wrench to disconnect drain line mounting ring is disconnected from the mounting assembly. -
Page 5: Installation Of Mounting Assembly
3. INSTALLATION OF MOUNTING ASSEMBLY READ COMPLETELY BEFORE STARTING NOTE: Pay close attention to the order of mount assembly parts, as they have been correctly assembled by the factory (see 3A). Also, reference the cushion mount detail in illustration 3G for the proper position of the cushion mount. NOTE: Try practicing this assembly before you get under the sink to get the “feel” of how the parts fit together. SPEED MASTER MOUNT SYSTEM A. Disassemble mount assembly from may want to insert stopper in sink and fill disposer by turning mount ring to the left with water to check sink flange seal and (clockwise) and remove. ensure there are no leaks. B. Raise mount ring toward top of sink H. Place mount ring over sink flange and flange. Remove cushion mount. remove hold in place while installing cushion mount ring. -
Page 6: Electrical Connections
IMPORTANT NOTICE: CUSHION MOUNT DETAIL When the cushion mount is installed correctly, the lip of the sink flange fits into the groove on the inside of the cushion mount and mount ring can be pulled downward over cushion mount and will be free to rotate. The bottom bead of the cushion mount acts as a gasket between the bottom of the sink flange and the top of the disposer. -
Page 7: Attaching Discharge Elbow
5. ATTACHING DISCHARGE ELBOW A. Connect waste elbow to the disposer (see 5A), proceed to step 6 and then connect bottom of the elbow by tightening the slip nut (see 5B). B. If you are connecting to a dishwasher, return to section 2B. If not, make sure all plumbing connections are tight and in accordance with all plumbing codes and ordinances. Run water and check for leaks. 6. CONNECTING DISPOSER TO MOUNT ASSEMBLY A. Line up disposer under mounting assembly. Guide hopper projections into mount ring slots. Turn mount ring about 1/4” to right so that disposer is temporarily supported (see 6A). B. Turn mount ring and disposer until disposer elbow lines up with trap (see 6B). -
Page 8: Tips For Successful Operation
TIPS FOR SUCCESSFUL OPERATION A. Be sure disposer is empty before using your dishwasher so it may drain properly. B. You may want to leave the stopper in the drain when not in use to prevent utensils and foreign objects from falling into the disposer. C. Your disposer is ruggedly built to give you many years of trouble free service. It will handle all normal food wastes, but it will NOT grind or dispose of such items as plastic, tin cans, bottle caps, glass, china, leather, cloth, rubber, string, and aluminum foil or feathers. 8. CLEANING AND MAINTENCE DO NOT ATTEMPT TO LUBRICATE YOUR DISPOSER! The motor is permanently lubricated. - Page 9 10. Disposer Air Switch Assembly(built-in Air Switch) Instructions Disposer Air Switch Assembly is supplied in three basic parts: The Actuator which consists of: D. Plug Disposer Power Cord(#6) into main 1. Actuator Button electrical service. E. To turn on disposer, press Actuator Button 2. Actuator Nut 3. Actuator Outlet(Black Threaded portion) (#1). To turn off, press Actuator Button again.
- Page 10 Specification Sheet Model USA-WD2100 DSA-WD2000 DSA-WD3000 DSA-WD5000 Configuration Type Basic Heavy Duty Super Duty Deluxe Feed Type Continuous Continuous Continuous Continuous Hopper Capacity(ml) 1070 1070 1070 Suitable For Families 2-6 Persons 5-7 Persons 7-12 Persons 7-12 Persons or More Ultra-power, High Efficiency Permanet Magnet DC Motors...
- Page 11 LENGTH OF WARRANTY: Lifetime Warranty applies to Model DSA-WD5000. 10 Year Warranty applies to models DSA-WD3000 and DSA-WD2000. 5 Year Warranty applies to model USA-WD2100. DEFECTIVE DISPOSER: During the warranty period, a defective or inoperative disposer will be replaced by the company at no charge to you. Original sales receipt and website registration required. CHANGE OF OWNERSHIP: Warranty remains in force for warranty period from date of purchase of disposer but is limited to the original purchaser. Original sales receipt and...
- Page 12 Garbage Disposal Unit Installation & Operation Manual USA-WD2100 / DSA-WD2000 / DSA-WD3000 / DSA-WD5000 www.dakotasinks.com...
