poolstar POOLEX POOLICAN Installation And Operation Manual

The 4-in-1 solution for pools
Hide thumbs Also See for POOLEX POOLICAN:

Advertisement

Quick Links

Download this manual
CIRCULATION
CIRCULACIÓN
CIRCOLAZIONE
WASSERUMLAUF
CIRCULATIE
FILTRATION
FILTRACIÓN
FILTRAZIONE
FILTERUNG
POMPE À CHALEUR
HEAT PUMP
BOMBA DE CALOR
POMPA DI CALORE
WÄRMEPUMPE
WARMTEPOMP
TRAITEMENT
WATER TREATMENT
TRATAMIENTO
TRATTAMENTO
WASSERAUFBEREITUNG
BEHANDELING
LA SOLUTION 4 EN 1 POUR PISCINE / THE 4-IN-1 SOLUTION FOR POOLS
LA SOLUCIÓN 4 EN 1 PARA LAS PISCINAS/ LA SOLUZIONE 4 IN 1 PER LA PISCINA
4 LÖSUNGEN IN EINER FÜR POOLS/ DE 4-IN-1 OPLOSSING VOOR UW ZWEMBAD
FILTRATIE
MANUEL D'INSTALLATION ET D'UTILISATION
INSTALLATION AND OPERATION MANUAL
MANUAL DE INSTALACIÓN Y DE USO
MANUALE D'INSTALLAZIONE E D'USO
INSTALLATIONS- & BENUTZERHANDBUCH
INSTALLATIE- EN GEBRUIKSHANDLEIDING
www.poolstar.fr

Advertisement

loading
Need help?

Need help?

Do you have a question about the POOLEX POOLICAN and is the answer not in the manual?

Questions and answers

Related Manuals for poolstar POOLEX POOLICAN

Summary of Contents for poolstar POOLEX POOLICAN

  • Page 1 LA SOLUCIÓN 4 EN 1 PARA LAS PISCINAS/ LA SOLUZIONE 4 IN 1 PER LA PISCINA 4 LÖSUNGEN IN EINER FÜR POOLS/ DE 4-IN-1 OPLOSSING VOOR UW ZWEMBAD MANUEL D’INSTALLATION ET D’UTILISATION INSTALLATION AND OPERATION MANUAL MANUAL DE INSTALACIÓN Y DE USO MANUALE D’INSTALLAZIONE E D’USO INSTALLATIONS- & BENUTZERHANDBUCH INSTALLATIE- EN GEBRUIKSHANDLEIDING www.poolstar.fr...
  • Page 2 WARNINGS This heat pump contains R32 flammable refrigerant. Prior approval must be obtained before any procedure is performed on the refrigerant circuit. To ensure user safety, the following precautions must be followed before any procedure is performed on the refrigerant circuit. 1.
  • Page 3 ACKNOWLEDGEMENTS Dear customer, Thank you for your purchase and your trust in our products. Our products are the result of years of research in the design and manufacture of heat pumps, water treatment, and filtration systems for pools. Our goal is to deliver high- quality products with exceptional performance.

  • Page 4: Please Read Carefully

    PLEASE READ CAREFULLY These installation instructions form an integral part of the product. They must be provided to the installer and kept in a safe place by the user. If you lose this manual, please visit our website: www.poolex.fr The warnings and guidelines contained in this manual must be carefully read and understood; they provide important information concerning the safe handling and operation of your product.

  • Page 5: Table Of Contents

    SUMMARY I. GENERAL TERMS OF DELIVERY II. SAFETY INSTRUCTIONS III. HOW IT WORKS IV. OPERATING LIMITS 1 / Heat pump 2 / Circulation / Filtration 3 / Lighting 4 / Salt chlorination V. FEATURES 1 / Dimensions 2 / Exploded view VI. INSTALLATION 1 / Installation diagram 2 / Hydraulic connections 3 / Starting the pump 4 / Electrical connections VII.

  • Page 6: General Terms Of Delivery

    GENERAL TERMS OF DELIVERY All products and packaging, even those delivered carriage paid, travel at the risk of the recipient. Persons responsible for accepting delivery of the device must perform a visual inspection to make a note any damage that may have occurred during transportation. Any damage occurring during transportation must be noted by the recipient on the delivery receipt of the carrier and confirmed by registered post sent to the carrier within 48 hours.

  • Page 7: Safety Instructions

    SAFETY INSTRUCTIONS When in use Do not touch the vent during operation due to the risk of serious injury. Do not leave the heat pump within reach of children due to the risk of injury caused by the heat exchanger fins. Do not switch on the unit without water in the pool.

  • Page 8: How It Works

    HOW IT WORKS POOLICAN is the all-in-one system designed for pools which fulfils all of the main functions required by your pool: CIRCULATION / FILTRATION HEATING WATER TREATMENT The first step is setting your desired temperature, and from there adjusting the settings of the other elements in order to reach this value according to the size of your pool.

  • Page 9: Operating Limits

    OPERATING LIMITS Heat pump As with any other heat pump, the one installed in the POOLICAN system may only be used when the outside temperature is between -7°C and 43°C; however, we recommend winterizing your pool if the water temperature drops below 10°C. Thanks to the Full Inverter system, POOLICAN automati- cally adjusts power depending on its settings and the external environment.

  • Page 10: Lighting

    OPERATING LIMITS Lighting You can control the lighting in your pool using Poolican's driver LED. This function can only be ac- cessed via the application. To do this, connect your LED spotlights (12 Vdc / 60W max.) directly to the power supply terminals supplied (B).
  • Page 11 OPERATING LIMITS Readings to be taken weekly: test and adjust if necessary Parameter Target values Comments Once the salt is in the water (taking 24 to 48h to fully dissolve), Salinity 3 to 4 g/l salt concentration will only vary slightly over the course of the season.

  • Page 12: Features

    FEATURES Technical specifications are listed for reference only; we reserve the right to change this data wit- hout prior notice. General Heat pump Max. pool volume 25 m Output power (kW) 3.5 kW 15°C Power supply 230V-50Hz Water 26°C Power consumption (W) 0.83 kW Max.

  • Page 13: Exploded View

    FEATURES Exploded view Grille panel Motherboard Deflector Light driver water pump Motherboard housing Rear panel Evaporator Support bar Flow sensor Filter basket support frame Front panel Filter basket Equipped power cable Cartridge filter Copper water pipe Filter basket lid Titanium heat exchanger Suction valve Rotary compressor Internal connection pipes...

  • Page 14: Installation

    INSTALLATION For more details about the kit, refer to Chapter 3. POOLICAN must be installed between 2 and 3.5 metres from the pool basin: Between 2 and 3.5 m Pool Please respect the following rules when choosing your installation location: The location must be easily accessible for optimal operation and ¬maintenance.

  • Page 15: Installation Diagram

    INSTALLATION Installation diagram POOLICAN is an all-in-one system for your pool; simply connect the suction line from the pool to the POOLICAN inlet and the return line to the POOLICAN outlet. To pool Pool From pool Hydraulic connections Raccords de connexion : 1.5’’ vers D32/38 Use with OFF-GROUND pools Vanne 2 positions...

  • Page 16: Starting The Pump

    INSTALLATION Starting the pump When unpacking, remove the plastic film around the filter and rinse thoroughly. Before starting the circulation pump, check that the water can flow easily into POOLICAN. And this especially if POOLICAN is installed above the water level (often the case for installations on buried pools).

  • Page 17: Before Use

    BEFORE USE Adding salt Prior to adding salt, ALWAYS test the salinity. Only use salt which complies with European standard EN 16401 to extend service life and improve efficiency of the chlorinator cell. DO NOT ADD chemical products or salt directly into the skimmer. This can da- mage the cell.

  • Page 18: Required Stabiliser Levels

    BEFORE USE In the event of excess salinity (> 4.5 g/l or 45 kg/m ), partial emptying of the pool may be necessary in order to add fresh water without salt. Furthermore, the correct stabiliser level must be between 20ppm and 50ppm.

  • Page 19: Using The Control Panel

    USING THE CONTROL PANEL Overview of control panel Lock status Active defrosting mode Unit of temperature Temperature display and error codes Water treatment: Normal or BOOST Heating mode mode Auto mode Wifi Cooling mode Filtration On / Off T° +/- adjustment &...

  • Page 20: Easy To Use In Four Simple Steps

    USING THE CONTROL PANEL Easy to use in four simple steps POOL 1 – Calculate the volume of your pool and note it here: Volume  2 – Choose your bathing temperature and note it here:  T° desired = 3 – Calculate filtration time (in hours) (C8) and note it here: 4 –...

  • Page 21: Covered Mode

    USING THE CONTROL PANEL Covered mode Covering pools for prolonged periods of time may result in over-chlorination. When the pool is covered, the application allows you to adapt the treatment time: to do this, activate the cover button; Poolican will then reduce its treatment time. Remember to deactivate the cover button when you uncover your pool.

  • Page 22: Setting Filtration Time

    USING THE CONTROL PANEL Setting filtration time The filtration time can be adjusted when the POOLICAN heat pump is not in use. To ensure optimal filtration, the filtration time of the POOLICAN system must be sufficiently long. A simple formula is given below as a guideline: Water T°...

  • Page 23: Setting Water Treatment Time (In Hours)

    USING THE CONTROL PANEL Setting water treatment time (in hours) Setting the correct water treatment time (or chlorine production time) is extremely important to achieve adequate disinfectant levels and avoid over-chlorination. The settings given below are for reference only; you can adjust your settings depending on your personal experience.

  • Page 24: Using The App

    USING THE APP In order to simplify the use of the POOLICAN system, an app is available on the Android Google Play store and the iOS App Store. Before beginning, ensure that the POOLICAN is within Wifi range of your router; a Wifi repeater may be required to provide sufficient signal to the POOLICAN installation site.

  • Page 25: Overview Of The Application Control Panel

    USING THE APP Overview of the application control panel Change device name Heat pump operating (and other functions) mode indicator Lock the control panel Lighting On/Off Indication of pool cover Reduces treatment time Defrosting On/Off Set temperature using Target temperature the slider indicator Set temperature by...

  • Page 26: Change Operating Parameters

    USING THE APP Change operating parameters 24 |...
  • Page 27 USING THE APP Filtration settings Filtration time settings, from 1h to 24h (see table page 20) Setting reminders for filter cleaning from 130h to 200h Water treatment by salt chlorinator settings Setting water treatment time, 1h to 24h (see table page 21) Setting water treatment boost time, 1h to 24h...
  • Page 28 USING THE APP Programming a schedule Permet d’activer un Run time settings programme existant (Allow 2 minutes for the programme to register in the cloud) Activates an existing program Repeat: once by default, select the days in question Program settings to be acti- vated or disabled Add new program POWER : ON / OFF...
  • Page 29 USING THE APP Verification of heat pump parameters Outside air tempera- ture indicator POOLICAN water inlet temperature indicator POOLICAN water outlet temperature indicator Compressor gas di- scharge temperature Compressor gas suction temperature Compressor frequency indicator Water flow status indi- cator Fan speed indicator List of errors in chrono- logical order of appea-...

  • Page 30: Maintenance, Servicing & Winterizing

    MAINTENANCE, SERVICING & WINTERIZING Cleaning The heat pump housing must be cleaned with a damp cloth. Using detergents or other household cleaning products may degrade the surface of the housing and affect its integrity. In the event of scale build-up, clean the cell with a descaling agent. Regular maintenance Check that nothing is obstructed the grills.

  • Page 31: Winterizing

    MAINTENANCE, SERVICING & WINTERIZING Winterizing Your heat pump is designed to operate in all weather. However, we recommended not leaving it outside for prolonged periods of time, in particular during winter. In the off-season, when the ambient temperature is below 10°C, the POOLICAN must be switched off and winterized to avoid any damage caused by freezing.

  • Page 32: Breakdown And Faults

    BREAKDOWN AND FAULTS Code Error Resolution Reminder to clean the filtration system Clean or check the filter. RAZ up arrow + filtration Water flow switch protection Check that water is properly flowing through the pipes, ensure the filter is clean, and the inlet/outlet valves are open. If this does not solve the problem, contact customer support to reconnect or replace the flow sensor.
  • Page 33 BREAKDOWN AND FAULTS Code Error Resolution System detection circuit malfunction Automatically clears (switch the POOLICAN off and on again). (must be manually cleared) Contact customer support if problem persists Abnormal temperature range of the Check the water temperature is not below 10°C or above 40°C (if water in the chlorinator necessary, winterize the POOLICAN or cool down the water using the cooling mode)

  • Page 34: Warranty

    WARRANTY Poolstar SAS warrants to the original owner that the goods shall remain free of manufacturing and material defects for a period of two (2) years. The compressor is guaranteed for a period of five (5) years. The titanium tube heat exchanger is guaranteed for a period of fifteen (15) years against chemical corrosion, except in the case of damage due to freezing.
  • Page 35 Poolstar. The parts under warranty shall be replaced or repaired at the discretion of Poolstar. Faulty parts must be returned to us during the warranty period in order to be covered. The warranty does not cover unauthorised replacements or labour costs.

  • Page 36: Annex

    ANNEXE / APÉNDICE / APPENDICE / ANNEX / ANHANG / BIJLAGE Schéma de câblage / Wiring diagram / Esquema eléctrico / Schema di cablaggio / Schaltplan / Aansluitschema...
  • Page 37 A SIS TE NC I A TÉ C NI C A / ASSI STEN ZA T ECN I CA TE C H NI SC H E H I L FE / TE C HN I SCH E B IJ ST A N D www.poolex.fr 04-2024 www.poolstar.fr...
