Magnus REX CFS-100 Owner's Manual

Folding camera stand
Hide thumbs

Advertisement

Quick Links

Download this manual
Folding Camera Stand
Owner's
Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the REX CFS-100 and is the answer not in the manual?

Questions and answers

Summary of Contents for Magnus REX CFS-100

  • Page 1 Folding Camera Stand Owner’s Manual...
  • Page 2 Thank you for choosing Magnus. The Magnus REX Folding Camera Stand is designed with advanced features for professional photographers and videographers shooting vlogs or products in the studio or at home. It’s constructed with high-grade aluminum tubing and offers a foot-pedal locking mechanism so you can quickly reposition your camera to any angle.
  • Page 3 Precautions • Please read and follow these instructions, and keep this manual in a safe place. • Do not exceed the maximum weight capacity of the folding stand. • The camera should be securely fastened to the quick- release mounting plate before mounting it onto the folding stand.
  • Page 4 Overview 1/4-20 camera mount Quick-release plate Screw key Locking lever and safety latch Increment scale Handle tension Mount slide knob screws 3/8-16 screw 1/4-20 screw Handle Upper section Middle section Lower section Center leg Telescoping leg Left leg Caster Caster lock Right leg Pedal lock Also Includes:...
  • Page 5 Operating the CFS-100 Setting Up the Folding Stand Grab the stand from the handle and remove it from the case. Unfasten the stand wrap. Make sure the stand’s handle is straight as shown. Pull up on the stand handle, and down on the legs handle until all the legs are extended.

  • Page 6: Attaching A Camera

    Warning! Make sure the handle is pointed up like in the image. Grip the handle with one hand and press the pedal with your foot to release the stand. Use the handle to pull the stand up to the desired angle and height, and release the pedal to lock the stand in place.
  • Page 7 Attach the camera/quick-release assembly to the mount by seating the front end of the plate into the mount. Then press the rear side down until it locks into place. To balance the camera, use a screwdriver to remove the mount slide screws and adjust the plate position.
  • Page 8 Folding the Stand Straighten out the handle, and grip it with both hands. Press the pedal with your foot, and push down to collapse the stand. You may need to use one hand to help collapse the sectionals. Retract the telescoping leg if extended. Grip the handle and pull up on the pedal to collapse the stand.

  • Page 9: Specifications

    Specifications Maximum height: 55 in. (139.7 cm) Minimum height: 24 in. (61 cm) Folded length: 23 in. (58.4 cm) Materials: Anodized aluminum alloy Quick-release plate: 0.24 × 2.2 × 3.3 in. (0.6 × 5.5 × 8.3 cm) Camera mounting screw: 1/4-20, 3/8-16 Built-in balance plate: Yes Leg width: 31 in.

  • Page 10: One-Year Limited Warranty

    Customer Service Department to obtain a return merchandise authorization (“RMA”) number, and return the defective product to Magnus along with the RMA number and proof of purchase. Shipment of the defective product is at the purchaser’s own risk and expense.
