COLOR TELEVISION RECEIVER
COLOR TELEVISION RECEIVER
Chassis : KS3A(N)
Model
: TXL3276S/XAA
TXL3676S/XAA
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
CONTENTS
Specifications
Exploded Views and Parts List

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TXL3276S/XAA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Samsung TXL3276S/XAA

Summary of Contents for Samsung TXL3276S/XAA

  • Page 1: Table Of Contents

    COLOR TELEVISION RECEIVER Chassis : KS3A(N) Model : TXL3276S/XAA TXL3676S/XAA COLOR TELEVISION RECEIVER CONTENTS Precautions Reference Information Specifications Alignment and Adjustments Troubleshooting Exploded Views and Parts List Electrical Parts List Block Diagrams Wiring Diagram Schematic Diagrams...
  • Page 2 ELECTRONICS © Samsung Electronics Co., Ltd. JUL . 2001 Printed in Korea AA68-01805A...

  • Page 3: Safety Precautions

    Heed the high voltage limits. These include not exceed 0.5 milliamp. Reverse the power- the X–ray Protection Specifications Label, and plug prongs in the AC outlet and repeat the the Product Safety and X-ray Warning Note on test. the service data schematic. Samsung Electronics...
  • Page 4 14. Components, parts and wiring that appear to have overheated or that are otherwise damaged should be replaced with parts that meet the original specifications. Always determine the cause of damage or overheating, and correct any potential hazards. Samsung Electronics...

  • Page 5: Servicing Precautions

    Make sure that the portion around 8. Always connect a test instrument’s ground the serviced part has not been damaged. lead to the instrument chassis ground before connecting the positive lead; always remove the instrument’s ground lead last. Samsung Electronics...

  • Page 6: Precautions For Electrostatically Sensitive Devices (Esds)

    4. Do not use freon-propelled chemicals. These unpackaged replacement ESDs. Motions such can generate electrical charges that damage as brushing clothes together, or lifting a foot ESDs. from a carpeted floor can generate enough static electricity to damage an ESD. Samsung Electronics...

  • Page 7: Reference Information

    Millimeter Hour Millisecond Inches Per Second Millivolt Kilowatt-hour Nanofarad Ω Kilogram Kilohertz Picofarad kΩ Kilohm Pound Kilometer Revolutions Per Minute km/h Kilometer Per Hour Revolutions Per Second Kilovolt Second (Time) Kilovolt-ampere Volt Kilowatt Volt-ampere Liter Watt Megahertz Watt-hour Samsung Electronics...
  • Page 8 Fail Safe Voltage Controlled Oscillator Ground VCXO Voltage Controlled Crystal Oscillator Green-Y Very High Frequency High Video Intermediate Frequency High-Frequency Variable Resistor HI-FI High Fidelity Video Tape Recorder Inductance-Capacitance VTVM Vacuum Tube Voltmeter Integrated Circuit Transistor Intermediate Frequency Samsung Electronics...
  • Page 9 8V Controlled Regulator KA78RM33 IC903 3.3V Regulator KIA7025AP IC904 MICOM Reset IC Q909 2N7000 IIC Level Shifter Q910 Refer to Table 2-3-4 TU01S TCLN3181PA09A Main Tuner with IF Block Refer to Table 2-3-5 TU02S TCPN3081PD09A Sub Tuner with IF Block Samsung Electronics...
  • Page 10 TR-Power (TILT) QG03 KSD2073-H2 ICG01 KA4558 OP-AMP (TILT) ICH01 KA4558 OP-AMP DOUBLE Option FOCUS QH01 2SC4636RB TR-Power V-S/W TEA6425 ICS01 Video Switching IC with Adder Output Option High-end Picture-In Picture IC Option SDA9388X ICP01 EZ1086CM ICP02 3.3V Regulator Samsung Electronics...
  • Page 11 Main, Thin Jack Main 1Tuner PAL N.M, NTSC, LNA Function TCPN3081PA09A Note TCPS3001PD09A(S) is out-of-date, TCPS3001PD09D(S) which is up-to-date has the same function. Table 2-3-5 2’nd TUNER (TU02S) REMARK FUNCTION SPEC NTSC, PAL N.M LNA Function TCLN3181PD09A TCPN3081PD09A NTSC Samsung Electronics...
  • Page 12 MEMO Samsung Electronics...

  • Page 13: Alignment And Adjustments

    2. Turn on the TV. Set the Brightness and Contrast controls to minimum (zero beam current). 3. Adjust the Brightness and contrast controls to both extremes. Ensure that the high voltage does not exceed 32 KV under any conditions. Samsung Electronics...

  • Page 14: Dynamic Focus Adjustment

    4-5 SCREEN Adjustment 1. Input Toshiba Pattern 2. Enter “Service Mode”.(Refer to “Service Mode”) 3. Select “G2-Adjust”. 4. Set the values as below. IBRM = 200 WDRV = 35 = 200 COLR G B = 120 120 120 Samsung Electronics...
  • Page 15 For example, when the value of “Red Cutoff” is 127, change the value to 128 and restore the value to 127. If you do not follow this procedure, the picture may be abnormal. For example, when the TV set is on, the picture becames brighter gradually. Samsung Electronics...

  • Page 16: White Balance Adjustment

    7. Adjust CA-100 so that the final adjustment value can be fixed. 8. Use the Channel Up/Down ( / ) buttons to move the cursor on the adjustment modes. 9. Use the Volume +/- buttons to change the adjustment value. Samsung Electronics...

  • Page 17: Factory Adjustment

    3. After all settings are completed, adjust the service value of each mode to its default. 4. Refer to “Service Manual” for factory value. 5. Check the version a. Check the VDP version “Y” in the Factory Mode. b. Version Mode : “Y”, “B” from IC201S(Video Chip) VDD3130”Y” VDD3112”B”, VDD3108”B” Samsung Electronics...

  • Page 18: Memory Data

    Adjustment V SC Fixed H EW Adjustment H TRAPEZIUM Adjustment H PARABOLA Adjustment H SYMMETRY Fixed H CORNER Adjustment H SHIFT PIP CONTRAST Fixed PIP TINT Fixed PIP PAL V.POS Fixed PIP NTSC V.POS Fixed PIP H.POS Fixed Samsung Electronics...
  • Page 19 Alignment and Adjustments 4-8-2(B) SCREEN CHANGE (I2C BUS GEOMETRIC ADJUSTMENT) V Shift V Amp V Slope V SC H Trapizium H EW H Symmetry H Parabola H Corner H Shift Samsung Electronics...
  • Page 20 Fixed N. YC DELAY Beam Control Limit Characteristic Note 3. Table 1. YC Delay Adjustment Table beam NTSC N.YC Delay 1.8mA Def. 1.6mA Value BCL GAIN BCL THESHOLD The “Def.” means that TV is in AV mode. WDRGB Samsung Electronics...
  • Page 21 Fixed A TILT POINT Fixed B TILT POINT Fixed GAIN 1 (VIDEO) Fixed DELAY 1 (VIDEO) Fixed PEAK VIDEO REF Fixed PEAK VIDEO GAIN Fixed LIMIT VALUE Fixed VELOCITY DELAY Fixed VELOCITY CORING Fixed ACC-REF Fixed ACCR Fixed Samsung Electronics...
  • Page 22 VIDEO-MUTE TILT CONTROL GAME+DEMO(CN) 2-TUNER 2-TUNER 2-TUNER VCHIP(CT,CTA) BLUE SCREEN AUTO POWER ON HOTEL 04 DE 12 1C 01 01 80 09 Option Byte 01 01 88 09 04 01 92 09 Note 6. V-DOLBY MSP3451G, MSP3440GB6 4-10 Samsung Electronics...
  • Page 23 4-8-2(G) G2 ADJUST Initial SAM2540 Adjustment G2 Adjust TXK3276 CL29A6 TXK3279 TXK3676 TXK3679 SAM2740 Value Value MRC R G B MRWDG IBRM WDRV VDP Version 275,295,35 275,295,28 275,295,50 275,295,28 275,295,28 275,295,28 WHITE BALANCE 275,295,1.2 275,295,1.0 275,295,1.5 275,295,1.0 275,295,1.0 275,295,1.0 Samsung Electronics 4-11...

  • Page 24: Pin Layout

    OSD-B OSD-G OSD-R AV1 Ident VDD 2.5V AV2 Ident Key 1 X-TAL Out H-Sync X-TAL In V-Sync MICOM Reset Key 3 N.C. Key 2 N.C. X-Ray Protect VDD 3.3V IR Input Stand-By LED N.C. Time LED Relay 4-12 Samsung Electronics...
  • Page 25 AV1 Ident AV1-ID AV2-ID AV2 Ident Key1 Key1 Input H-Sync Horizontal Sync Input Vertical Sync Input V-Sync Key3 Input Key3 Key2 Key2 Input X-Ray X-Ray Protection IR-In Remocon Signal Input STD-LED LED Drive Output(Red) TIM-LED LED Drive Output(Green) Samsung Electronics 4-13...
  • Page 26 VDD 2.5V VDD 3.3V PX.Y When The Caption Function Adopted, Used. PX.Y N.C. Not Used (Programmed Gound Level) N.C. Sound Amp Mute S-Mute High Picture On/Off Control Power Not Used (Programmed Gound Level) N.C. Tilt Tilt Control Output 4-14 Samsung Electronics...

  • Page 27: Troubleshooting

    Troubleshooting 5. Troubleshooting 5-1 No Power Samsung Electronics...
  • Page 28 Troubleshooting 5-2 No Picture Samsung Electronics...
  • Page 29 Sound is mute) Normal Check D816, Q906 Check Abnormal IC601 #24, #25 Normal Replace IC602 Check Abnormal IC601 Input Voltages (5V,8V) Normal Check the coils around IC601 Check Abnormal IC601 Input Signal Normal Check Replace the Tuner IC601 Samsung Electronics...
  • Page 30 MEMO Samsung Electronics...
  • Page 31 Exploded View & Parts List 6. Exploded View & Parts List 6-1 TXL3276S/XAA Code No Description Specification Q’ty Remark AA92-00390F ASSY CABINET FRONT ;TXL3276C/XAA AA64-00885A CABINET FRONT ;TOOL,34D3-1,MOLD,-,-,-,-,- AA64-70124C BADGE-BRAND ;AL,R2500,SILVER,L=70,SAMSUNG AA64-00354A WINDOW-REMOCON ;MOLD,37D3,MOLD,-,-,-,- AA64-00352A KNOB-POWER ;TOOL,37D3,MOLD,-,-,- AA61-60003J SPRING-CS ;-,SUS304,0.5,OD6,H12,N7,-,-,-...
  • Page 32 1-12 3001-001115 SPEAKER ;15W,8ohm,93dB,110 1-13 6003-001019 SCREW-TAPTITE ;RH,+,B,M4,L12,ZPC(BLK),SWR SPK+CF AA03-00126A CRT COLOR ;-,A90AHH50X08(V),+380mG,-,110, AA65-30113A CLAMP-D,COIL ;-,NYLON 66,V2,-,BLK,TVI 25~ D-COIL AA60-10050V SCREW-ASSY ;-,SWRCH18A,M6,L30,HH,+,WC,-,Z CRT+CF 3704-000114 SOCKET-CRT ;14P,29.1,35.5,SN,ISH09S/BK VA999 AA64-00350A CABINET-BACK ;TOOL,37D3,MOLD,-,-,-,-,- AA60-10050T SCREW-TAPPING ;-,SWRCH18A,M4,L20,RH,+,2S, CB+CF AA39-10007Y POWER-CORD ;-,EP2/YES,SPT-2 18AWGx2C,2.4m Samsung Electronics...

  • Page 33: Electrical Parts List

    Electrical Parts List 7. Electrical Parts List 7-1 TXL3276S/XAA Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark ASSY PCB CHASSISPACK ..4 CN501 3711-002641 CONNECTOR-HEADER;BOX,10P,1R,2.54mm,STRAI ..4 CX801S 2306-000318 C-FILM,MPPF;220nF,20%,250V,TP,-,22.5mm ..4 CX802S 2306-000318 C-FILM,MPPF;220nF,20%,250V,TP,-,22.5mm AA93-00058J ASSY PCB CHASSISPACK;,KS3A,TXL3276C/XAA...
  • Page 34 2201-000304 C-CERAMIC,DISC;0.001nF,0.25pF,50V,NP0,TP ..5 D301 0402-000546 DIODE-RECTIFIER;TVR10G,400V,1.0A,DO-41,T ..5 C701 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP ..5 D401 0402-000540 DIODE-RECTIFIER;RU20A,600V,1.5A,-,TP ..5 C702 2202-000243 C-CERAMIC,MLC-AXIAL;33pF,5%,50V,SL,TP,3..5 D402 0402-000534 DIODE-RECTIFIER;RG10V,400V,1.2A,DO-201,T ..5 C703 2202-000243 C-CERAMIC,MLC-AXIAL;33pF,5%,50V,SL,TP,3..5 D403 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP ..5 C709 2202-000243 C-CERAMIC,MLC-AXIAL;33pF,5%,50V,SL,TP,3..5 D404 0402-000540 DIODE-RECTIFIER;RU20A,600V,1.5A,-,TP Samsung Electronics...
  • Page 35 2702-001094 INDUCTOR-RADIAL;10uH,10%,6x4mm ..5 R214 2001-000411 R-CARBON;18KOHM,5%,1/8W,AA,TP,1.8X3.2M ..5 L204 2701-000184 INDUCTOR-AXIAL;4.7uH,10%,2.5x3.4mm ..5 R215 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2M ..5 L207 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500, ..5 R216 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..5 L208 2701-000146 INDUCTOR-AXIAL;2.2uH,10%,2.5x3.4mm ..5 R223 2001-000003 R-CARBON;330ohm,5%,1/8W,AA,TP,1.8x3.2m ..5 L209 2701-000168 INDUCTOR-AXIAL;3.3uH,5%,2.5x3.4mm ..5 R224 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2M Samsung Electronics...
  • Page 36 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2M ..5 R930 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..5 R615 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2M ..5 R931 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2M ..5 R616 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2M ..5 R932 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2M ..5 R617 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2M ..5 R933 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2M ..5 R620 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2M ..5 R934 2001-000003 R-CARBON;330ohm,5%,1/8W,AA,TP,1.8x3.2m Samsung Electronics...
  • Page 37 ...3 BOTZ 0403-001211 DIODE-ZENER;MTZJ12B,11.44-12.03V,500MW,D ..4 DZF02 0403-001039 DIODE-ZENER;MA2560,56V,52-60V,1W,DO-41,T ...3 CN501A 3711-002641 CONNECTOR-HEADER;BOX,10P,1R,2.54mm,STRAI ..4 L501 2701-000178 INDUCTOR-AXIAL;33uH,10%,3x7mm ...3 CN501E AA39-00225C LEAD CONNECTOR ASSY;,10P,67096-010,S,700 ..4 L503 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,- ...3 CN502E AA39-20029D LEAD CONNECTOR-ASSY;,7P,67096-007,S,500, ..4 L504 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,- Samsung Electronics...
  • Page 38 ..4 R544 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM AA64-00355A INDICATOR-LED;DP,37D3,MOLD,-,-,-,- S.N.A ..4 R546 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM AA64-00885A CABINET FRONT;TOOL,34D3-1,MOLD,-,-,-,-,- S.N.A ..4 RF02 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2 AA64-70124C BADGE-BRAND;AL,R2500,SILVER,L=70,SAMSUNG S.N.A ..4 RF03 2001-000362 R-CARBON;150OHM,5%,1/8W,AA,TP,1.8X3.2M AA65-00011C CLAMP-WIRE;ALL MODEL,NYLON 66,V2,-,NTR,2 S.N.A ..4 RF04 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2 AA64-00354A WINDOW-REMOCON;MOLD,37D3,MOLD,-,-,-,- S.N.A ..4 RF05 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2M...
  • Page 39 AA39-00102M LEAD CONNECTOR-ASSY;,4P,35155-0400,REC,8 ASSY-POWER,CORD AA96-20129B ASSY-POWER,CORD;-,EP2/YES,H/C400,ME301P, S.N.A 3811-000401 WIRE-PVC CU;BCWA,300V,ROLL,17/0.16mm,#22 AA61-20284A HOLDER;-,P-CORD,PP,VO,BLK,KE-002 S.N.A AA39-10007Y POWER-CORD;-,EP2/YES,SPT-2 18AWGx2C,2.4m ASSY CRT AA97-00721A ASSY CRT;-,-,32,-,TXK3276C/XAA,- S.N.A AA03-00131A CRT COLOR;A81AGZ50X07,-,34Inch,-,-,-,1.2 ASSY TBC WIRE(P) AA98-70025B ASSY TBC WIRE(P);DP,34inch,AA98-70010C,2 S.N.A REMOCON AA59-00141D REMOCON;,TM58,SSM174PT,41,SS,L/GRAY,M 2802-000194 RESONATOR-CERAMIC;8MHz,1.0%,TP,8.5x4.5x5 AA09-00052A IC-MCU;Z86L8808SSC-R5019,-,STICK,-,28 Samsung Electronics...
  • Page 40 2301-001192 C-FILM,MPPF;820nF,5%,400V,TP,29x18.5x25..5 C253 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 C815 2401-003026 C-AL;330uF,20%,200V,GP,ST,22x35,10 ..5 C254 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V ..4 CN501 3711-002641 CONNECTOR-HEADER;BOX,10P,1R,2.54mm,STRAI ..5 C301 2401-000603 C-AL;1uF,20%,50V,GP,TP,5x11,5 ..4 CX801S 2306-000318 C-FILM,MPPF;220nF,20%,250V,TP,-,22.5mm ..5 C302 2401-000360 C-AL;100uF,20%,50V,GP,TP,8x11.5,5 ..4 CX802S 2306-000318 C-FILM,MPPF;220nF,20%,250V,TP,-,22.5mm ..5 C303 2201-002103 C-CERAMIC,DISC;0.015nF,5%,500V,NP0,TP,6. Samsung Electronics...
  • Page 41 2401-003046 C-AL;47uF,20%,50V,WT,TP,6.3x11,2.5 ..5 D413 0402-000537 DIODE-RECTIFIER;RH1A,600V,0.6A,DO-204AC ..5 C809 2301-000356 C-FILM,PEF;47nF,5%,50V,TP,7.5x4.0x6.5,5m ..5 D602 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, ..5 C810 2301-000356 C-FILM,PEF;47nF,5%,50V,TP,7.5x4.0x6.5,5m ..5 D604 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, ..5 C811 2301-000356 C-FILM,PEF;47nF,5%,50V,TP,7.5x4.0x6.5,5m ..5 D801 0402-001111 DIODE-RECTIFIER;1N5397GP,600V,1.5A,DO-20 ..5 C814 2201-000406 C-CERAMIC,DISC;0.27nF,10%,2kV,Y5P,TP,6.3 ..5 D803 0402-000546 DIODE-RECTIFIER;TVR10G,400V,1.0A,DO-41,T Samsung Electronics...
  • Page 42 2003-000592 R-METAL OXIDE(S);22ohm,5%,2W,AF,TP,4x12m ..5 L406 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm ..5 R234 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..5 L407 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,- ..5 R235 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..5 L410 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500, ..5 R236 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2M ..5 L601 2702-001094 INDUCTOR-RADIAL;10uH,10%,6x4mm ..5 R237 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2M 7-10 Samsung Electronics...
  • Page 43 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM ..5 R940 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2M ..5 R705 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM ..5 R941 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2M ..5 R709 2001-000938 R-CARBON;68OHM,5%,1/8W,AA,TP,1.8X3.2MM ..5 R942 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2M ..5 R711 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM ..5 R943 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2M ..5 R712 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM ..5 R945 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2 Samsung Electronics 7-11...
  • Page 44 AA96-50151A ASSY-H/S;-,TR,AA61-10060A,TDA6101Q,- S.N.A ..4 LF05 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,- ...3 JA501 3722-001503 JACK-PIN;1P,1PI,NI,RED,SCR-JACK ..4 Q502 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,T ...3 PCB AA41-00210D PCB-CRT;CS29A6,FR-1,1L,D,1.6T,330x245, S.N.A ..4 Q503 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,T ...3 QF04 AA96-00111A ASSY-H/S;-,-,AA62-30013L,2SC2344,- ..4 Q504 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,T 7-12 Samsung Electronics...
  • Page 45 2001-001179 R-CARBON(S);68KOHM,5%,1/2W,AA,TP,2.4X6.4 AA64-00354A WINDOW-REMOCON;MOLD,37D3,MOLD,-,-,-,- S.N.A ..4 RF17 2001-001100 R-CARBON(S);2.7OHM,5%,1/2W,AA,TP,2.4X6.4 AA64-00355A INDICATOR-LED;DP,37D3,MOLD,-,-,-,- S.N.A ..4 RF18 2003-000458 R-METAL OXIDE(S);100ohm,5%,2W,AF,TP,4x12 AA64-70124C BADGE-BRAND;AL,R2500,SILVER,L=70,SAMSUNG S.N.A ..4 RF19 2003-001023 R-METAL OXIDE(S);120ohm,5%,2W,AF,TP,3.9x AA65-00011C CLAMP-WIRE;ALL MODEL,NYLON 66,V2,-,NTR,2 S.N.A ..4 RF20 2003-002214 R-METAL OXIDE(S);680ohm,5%,2W,AG,TP,3.9x AA64-00353A KNOB-CONTROL;TOOL,37D3,MOLD,-,-,- S.N.A ..4 RF21 2003-002214 R-METAL OXIDE(S);680ohm,5%,2W,AG,TP,3.9x...
  • Page 46 Code No. Description ; Specification Remark ASSY SPEAKER AA96-00459A ASSY SPEAKER;-,8ohm,15W,-,AA39-00102M,- S.N.A 3001-001115 SPEAKER;15W,8ohm,93dB,110 AA39-00102M LEAD CONNECTOR-ASSY;,4P,35155-0400,REC,8 ASSY-POWER,CORD AA96-20129B ASSY-POWER,CORD;-,EP2/YES,H/C400,ME301P, S.N.A 3811-000401 WIRE-PVC CU;BCWA,300V,ROLL,17/0.16mm,#22 AA61-20284A HOLDER;-,P-CORD,PP,VO,BLK,KE-002 S.N.A AA39-10007Y POWER-CORD;-,EP2/YES,SPT-2 18AWGx2C,2.4m REMOCON AA59-00141D REMOCON;,TM58,SSM174PT,41,SS,L/GRAY,M 2802-000194 RESONATOR-CERAMIC;8MHz,1.0%,TP,8.5x4.5x5 AA09-00052A IC-MCU;Z86L8808SSC-R5019,-,STICK,-,28 7-14 Samsung Electronics...

  • Page 47: Block Diagrams

    Schematic Diagrams 8. Block Diagrams 8-1 Power Diagram KA78RM33 Regulator 3.3V SDA9388X SIM408AY Samsung Electronics...
  • Page 48 Schematic Diagrams 8-2 Block Diagram SIM408AY 3.3V SDA9388X SDA9388X Samsung Electronics...

  • Page 49: Wiring Diagram

    ABL +16V GND HEAT 200V DOUBLE FOCUS 600V SC-I GND SY-I GND SC-O GND SY-O CN704 16.5VAC GND DOUBLE 16.5VAC GND DOUBLE CN501A B OUT G OUT R OUT CRT PCB SENSE TILT -16V ABL +16V GND HEAT 200V CN502A Samsung Electronics...
  • Page 50 MEMO Samsung Electronics...

  • Page 51: Schematic Diagrams

    Schematic Diagrams 10. Schematic Diagrams 10-1 MAIN 1 TP07 TP01 TP10 TP08 TP02 TP09 TP03 TP09 TP01 TP06 TP10 TP04 TP03 TP05 TP08 TP05 TP04 TP02 TP06 TP07 : Power Line : Signal Line Samsung Electronics 10-1...
  • Page 52 Schematic Diagrams 10-2 MAIN 2 TCLN3181PA09A TP11 TCPN3081 PD09A TP12 TP13 TP12 TP13 TP14 TP11 TP25 TP15 TP14 TP25 : Power Line : Signal Line TP15 10-2 Samsung Electronics...
  • Page 53 Schematic Diagrams 10-3 MAIN3 TP22 TP16 TP23 TP23 TP17 TP24 TP18 TP17 TP16 TP22 TP18 TP19 TP21 TP20 TP24 TP19 TP20 TP21 : Power Line : Signal Line Samsung Electronics 10-3...
  • Page 54 Schematic Diagrams 10-4 MAIN 4 TP32 TP26 TP33 TP27 TP26 TP33 TP35 TP34 TP28 TP27 TP35 TP29 TP34 TP28 TP32 TP31 TP30 TP29 TP31 TP30 : Power Line : Signal Line 10-4 Samsung Electronics...
  • Page 55 Schematic Diagrams 10-5 PIP : Power Line l Li Samsung Electronics 10-5...
  • Page 56 Schematic Diagrams 10-6 CRT, SWITCH SWITCH : Power Line : Signal Line 10-6 Samsung Electronics...

This manual is also suitable for:

Txl3676s/xaa

Table of Contents
