C5H6S, H5H6S, T5H6S
Single-Stage Heat Pump
with R-454B Refrigerant
1-1/2 To 5 Nominal Tons
NOTE: For use with R-454B indoor units only. Read the entire instruction manual before starting the installation.
SAFETY CONSIDERATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Check Equipment and Job Site . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Install on a Solid, Level Mounting Pad . . . . . . . . . . . . . . . . . . . . . 2
Clearance Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Operating Ambient. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Check OAT and OCT Thermistor Attachments . . . . . . . . . . . . . . 3
Elevate Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Make Piping Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Mandatory Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Make Electrical Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Compressor Crankcase Heater . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Install Electrical Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Start-Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Check Charge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Major Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Final Checks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Repairing Refrigerant Circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Care and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

SAFETY CONSIDERATIONS

IMPORTANT: This appliance shall only be installed by EPA qualified
personnel having appropriate certification. This appliance is not
intended for use by persons (including children) with reduced physical,
sensory or mental capabilities or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of
the appliance by a person responsible for their safety
Improper installation, adjustment, alteration, service, maintenance, or
use can cause explosion, fire, electrical shock, or other conditions which
may cause death, personal injury, or property damage. Consult a
qualified installer, service agency, or your distributor or branch for
information or assistance. The qualified installer or agency must use
factory-authorized kits or accessories when modifying this product.
Refer to the individual instructions packaged with the kits or accessories
when installing.
Follow all safety codes. Wear safety glasses, protective clothing, and
work gloves. Use quenching cloth for brazing operations. Have a dry
powder or CO2 fire extinguisher available. Read these instructions
thoroughly and follow all warnings or cautions included in literature and
attached to the unit. Consult local building codes and current editions of
the National Electrical Code (NEC) NFPA 70. In Canada, refer to
current editions of the Canadian electrical code CSA 22.1.
Proper tools should be used that are designed for the refrigerant of the
unit being installed. For A2L refrigerants, non-sparking tools are
required. A refrigerant detector should be used prior to and during the
installation process to check for leaks. Open flames or other ignition
sources should not be present except during brazing. Brazing should
only take place on refrigerant tubes that are open to the atmosphere or
have been properly evacuated
Installation Instructions
Recognize safety information. This is the safety-alert symbol
you see this symbol on the unit and in instructions or manuals, be alert to
the potential for personal injury.
Understand these signal words; DANGER, WARNING, and CAUTION.
These words are used with the safety-alert symbol. DANGER identifies
the most serious hazards which will result in severe personal injury or
death.
WARNING signifies hazards which could result in personal
injury or death. CAUTION is used to identify unsafe practices which
may result in minor personal injury or product and property damage.
NOTE is used to highlight suggestions which will result in enhanced
installation, reliability, or operation.
WARNING
!
ELECTRICAL SHOCK HAZARD
Failure to follow this warning could result in personal injury or death.
Before installing, modifying, or servicing system, main electrical
disconnect switch must be in the OFF position. There may be more than
one disconnect switch. Lock out and tag switch with a suitable warning
label.
WARNING
!
EXPLOSION HAZARD
Failure to follow this warning could result in
death, serious personal injury, and/or property
damage.
Never use air or any gas containing oxygen for
leak
compressors. Never allow compressor suction
pressure to operate in a vacuum with service
valves
pump-down instructions.
!
CUT HAZARD
Failure to follow this caution may result in personal injury.
Sheet metal parts may have sharp edges or burrs. Use care and wear
appropriate protective clothing and gloves when handling parts.
testing
or
operating
closed.
See
service
CAUTION
. When
refrigerant
manual
for

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C5H6S and is the answer not in the manual?

Questions and answers

Summary of Contents for Carrier C5H6S

  • Page 1: Table Of Contents

    C5H6S, H5H6S, T5H6S Single-Stage Heat Pump with R-454B Refrigerant 1-1/2 To 5 Nominal Tons Installation Instructions NOTE: For use with R-454B indoor units only. Read the entire instruction manual before starting the installation. SAFETY CONSIDERATIONS ......1 Recognize safety information.
  • Page 2: General

    C5H6S, H5H6S, T5H6S: Installation Instructions GENERAL Refrigerant Tubing Connection Outdoor IMPORTANT: Maximum liquid–line size is 3/8–in. OD for all NOTE: In some cases noise in the living area has been traced to gas residential applications including long line. Refer to Residential Piping pulsations from improper installation of equipment.
  • Page 3: Operating Ambient

    C5H6S, H5H6S, T5H6S: Installation Instructions Check OAT and OCT Thermistor Attachments 3/4 IN.DIA TIEDOWN KNOCKOUTS IN BASEPAN TWO (2) PLACES WARNING PERSONAL INJURY AND ENVIRONMENTAL HAZARD Failure to follow this warning could result in personal injury or death. Do not use means to accelerate the defrosting process or to clean, other than those recommended by the manufacturer.
  • Page 4: Make Piping Connections

    C5H6S, H5H6S, T5H6S: Installation Instructions Table 1 – Accessory Usage REQUIRED FOR REQUIRED FOR LOW–AMBIENT REQUIRED FOR SEA COAST Accessory COOLING APPLICATIONS LONG LINE APPLICATIONS APPLICATIONS (Within 2 (Below 55°F / 12.8°C) miles / 3.22 km) Accumulator Standard Standard Standard †...
  • Page 5: Burn Hazard

    C5H6S, H5H6S, T5H6S: Installation Instructions 1. Remove plastic cap holding piston in piston body of liquid service For Vapor Service Valve - remove valve core from schrader port on valve. Service Valve BEFORE brazing. This helps prevent overheating and damage to valve seals (refer to Fig.
  • Page 6: Mandatory Requirements

    C5H6S, H5H6S, T5H6S: Installation Instructions Mandatory Requirements Evacuate Refrigerant Tubing and Indoor Coil Pressure Proof Check CAUTION Refrigerant tubes and indoor coil should be pressure tested with an inert gas such as nitrogen. Pressurize the system with the inert gas to the Low...
  • Page 7: Compressor Crankcase Heater

    C5H6S, H5H6S, T5H6S: Installation Instructions Connect Control Wiring Route 24v control wires through control wiring grommet and connect leads to control wiring. See Thermostat Installation Instructions for wiring specific unit combinations. (See Fig. 10 Fig. 11.) Use No. 18 AWG color–coded, insulated (35°C minimum) wire. If thermostat is located more than 100 ft (31 m) from unit, as measured along the control voltage wires, use No.
  • Page 8: Start-Up

    C5H6S, H5H6S, T5H6S: Installation Instructions Start–Up Check Charge Factory charge amount and desired subcooling are shown on unit rating CAUTION plate. Additional subcooling may be required to achieve optimal heating performance based on the installed indoor unit.. PERSONAL INJURY HAZARD Care should be taken to ensure proper refrigerant is used for charging.
  • Page 9 C5H6S, H5H6S, T5H6S: Installation Instructions Units with Cooling Mode TXV General Sequence of Operation - Standard Thermostat (non-communicating) Units installed with cooling mode TXV require charging by the subcooling method. Turn on power to indoor and outdoor units. Transformer is energized.
  • Page 10 C5H6S, H5H6S, T5H6S: Installation Instructions HK38EA058 Fig. 12 – Control Board Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
  • Page 11 C5H6S, H5H6S, T5H6S: Installation Instructions Outdoor Fan Motor Operation initial time. Quiet Shift-2 can be selected while using Auto Defrost Mode. The outdoor unit control energizes outdoor fan any time the compressor The control board accumulates compressor run time. As the accumulated...
  • Page 12: Major Components

    C5H6S, H5H6S, T5H6S: Installation Instructions Major Components 24V Brown Out Protection If the control voltage is less than 15.5 volts for at least 4 seconds, the Control Board compressor contactor and fan relay are de-energized. Compressor and The Heat Pump control board controls the following functions: fan operation are not allowed until control voltage is a minimum of 17.5...
  • Page 13: Status Codes

    C5H6S, H5H6S, T5H6S: Installation Instructions Thermistor Sensor Comparison If there is a thermistor out of range error, defrost will occur at each time interval during heating operation, but will terminate after 5 minutes. The control continuously monitors and compares the outdoor air Thermistor Curve: The resistance vs.
  • Page 14: Final Checks

    5. Open the circuit by cutting or brazing. © 2023 Carrier. All rights reserved. Edition Date: 12/23 Catalog No: CHT5H6S-01SI A Proud Member of the Carrier Family Replaces: New Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
