- Page 1 HK-11WE All-position automatic welding machine for pipelines...
-
Page 2: Safety Precautions
HK-11WE All-position automatic welding machine for pipelines Instruction Thank you very much for purchasing this product. Read this instruction manual thoroughly to insure correct, safe and effective use of the machine. Read the manual first to understand how to operate and maintain the machine. - Page 3 HK-11WE All-position automatic welding machine for pipelines Symbol Title Meaning General General caution, warning and danger Be careful not to get Possible injury to fingers if caught in the your fingers caught. insertion part. Caution: Electric Possible electric shock under special shock! conditions.
-
Page 4: Table Of Contents
HK-11WE All-position automatic welding machine for pipelines Content 1. Security Descriptions ..................1 2. Security Precautions before Operations ............. 1 3. Summary ......................4 4. Component Descriptions ................... 4 5. Technical Specifications ..................5 6. Descriptions of the Control Panel ............... 5 7. -
Page 5: Safety Instruction
HK-11WE All-position automatic welding machine for pipelines 1 Safety Instruction Operation, inspection, and maintenance that disregard the basic safety rules cause many accidents. Carefully read, understand, and master the safety measures and precautions described in this instruction manual and on the machine before operating, inspecting, and maintaining the machine. - Page 6 HK-11WE All-position automatic welding machine for pipelines ◆ If you want to touch the machine in the process of welding or after welding, you must wear protective gloves. Don’t touch it before the face cools. Precaution Please obey the following precautions in case of electric shock.
- Page 7 HK-11WE All-position automatic welding machine for pipelines Precaution Use shield to protect you and others from being damaged by fume in the welding process. ◆ There is fume in the process. These fumes can damage your health. ◆ If you operate in a small space, it may lead to apnea because of lack of oxygen.
-
Page 8: Summary
HK-11WE All-position automatic welding machine for pipelines ◆ Welding on encapsulate container may lead to burst. ◆ Don’t weld on the space on which the spatter can contact combustibles and don’t weld near inflammable gas. ◆ Don’t put the overheated metal base after welding near combustibles. -
Page 9: Technical Specifications
HK-11WE All-position automatic welding machine for pipelines 5 Technical Specifications Item Content Note Item Content Note Outline 250X400X210 Machine weight 12Kg (including swinger) dimensions Packaging 600X375X405 Package weight 20.5Kg dimensions Input voltage 220V AC 50/60Hz Swing motor Brush motor Drive mode... - Page 10 HK-11WE All-position automatic welding machine for pipelines (3) Left dwell time: Rotate the side turn-knob to adjust parameters and set the left dwell time. (4) Right dwell time: Rotate the side turn-knob to adjust parameters and set the right dwell time.
-
Page 11: Installations And Connections
HK-11WE All-position automatic welding machine for pipelines 7 Installations and Connections Gas pipe 7.1. The installation of the swinger After installing the moving seat and other components, remove the swinger, loosen the butterfly screw of the gripper, and install the swinger on the connector. Then select the welding mode as required (except for straight line welding, the welding mode can also be reasonably selected according to the actual situation). -
Page 12: Precautions For Power Connection
HK-11WE All-position automatic welding machine for pipelines 7.2 Precautions for power connection Wiring pipe Note: Before the machine is powered on, please make sure that the input voltage limit is consistent with the requirements specified on To the direction of the mach the label. - Page 13 HK-11WE All-position automatic welding machine for pipelines When the extension length is too short When the extension length is too long Influences Influences Produce pores, the arc guidance is not good, the electric arc is not stable The nozzle is easy to be blocked by splashes, the welding line is not...
- Page 14 HK-11WE All-position automatic welding machine for pipelines When the distance between nozzle and components is too large, it is easy to produce defects(such as pores, pits, etc.). Please adjust it according aaccording to the following figure when using the machine.
-
Page 15: Welding Process Parameters
HK-11WE All-position automatic welding machine for pipelines Welding Process Parameters Φ1.2mm Φ1.4mm Φ1.6mm Welding wire diameter Welding parameters Flat welding 120-300 150-380 180-430 Current（A） Flat fillet welding 120-280 150-320 180-380 Girth welding 120-280 150-300 180-330 ① ②When under 300A, U=0.041+16± 1.50 U＝14+0.051... -
Page 16: Maintenance And Storage Of The Welding Trolley
HK-11WE All-position automatic welding machine for pipelines The following is swing parameter table for reference: Dwell time of the left, Thickness of the plate δ(mm) Swing mode Swing speed Swing angle middle and right (S) Zigzag wave 4～5 1～2 0.1～0.2 Zigzag wave 5～6... -
Page 17: Faults And Countermeasures Of The Trolley During Welding
HK-11WE All-position automatic welding machine for pipelines 11 Faults and Countermeasures of the Trolley during Welding Faults and countermeasures of the CO trolley are shown as follows: 1）The power light in the control box is not on. Causes Repair measures... -
Page 18: Electrical Wiring Diagram
HK-11WE All-position automatic welding machine for pipelines position position 7）The welding is not performed as the welding seam track. Cause Repair measure The position of the guiding wheel is not fixed properly Reposition the guiding wheel and fix it 12 Electrical Wiring Diagram... -
Page 19: Contact Details
If you have any comments, suggestions or unsolvable faults in the process of using the machine, please go to our homepage for inquiry （www.huawei.sh.cn）or consult our technical department to inform us of the relevant content(Tel: 021-69590305, service time: 8:00 to 16: 30 each Monday to Saturday ). Thanks for your cooperation! Note: Shanghai Huawei Welding and Cutting Machinery Co., LTD reserves the right of final... - Page 20 HK-11WE All-position automatic welding machine for pipelines Thanks for choosing our products Our main product: CG1-30 Series Trolley-type flame cutting machine CG1-30H High-speed trolley-type cutting machine（Plasma cutting torch is available） CG1-100 Flame cutting machine(Double cutting torches) CGD2-100 Multi-head flame cutting machine (Three to five sets of cutting torches)
