Summary of Contents for Lotus LT1200DWX/20
- Page 1 ™ P e r f o r m a n c e , D e l i v e r e d . 20L Wet/Dry Vacuum Cleaner Made in China/Fabriqué en Chine Lotus Tool Group (Philippines) www.lotustoolworks.com LT1200DWX/20...
-
Page 2: Warranty
FOR YOUR SAFETY CAREFULLY READ AND UNDERSTAND ALL INSTRUCTIONS WARRANTY We take pride in producing a high quality, durable product. This LOTUS utility vac carries a limited ® six (6) month warranty against defects in workmanship and materials from date of purchase under normal household use. -
Page 3: Double Insulation Instructions
(SQUARE WITHIN A SQUARE) MAY ALSO BE MARKED ON THE APPLIANCE. •To reduce the risk of electric shock-unplug before cleaning or servicing. • DO NOT use without filters in place. CAUTION: TO REDUCE THE RISK OF INJURY FROM MOVING PARTS- UNPLUG BEFORE SERVICING. ® Lotus Tool Group... -
Page 4: Specifications
• The wire which is coloured Blue must be connected to the terminal which is marked N or coloured Black. • The wire which is coloured Brown must be connected to the terminal which is marked L or coloured Red. ® Lotus Tool Group... - Page 5 UNPACKING AND CHECKING CARTON 1.Overview of the Appliance Components A Vac assembly….…………….…...1 B Hose…………….………...……...1 C Caster ………….…………...…...4 D Extension wands..……….……...3 E Crevice tool……………………..1 F Floor brush……………………….1 G Foam filter………………………..1 H Dust bag………………………….1 I Dust filter………………………..1 J Operator’s manual…….………..1 ® Lotus Tool Group...
- Page 6 3.10. Insert the locking end of the hose into the port of the container and turn to lock in to place. (fig.11) 3.11 Choose the desired accessories and extension wands and push onto the suction tube.(fig.12) ® Lotus Tool Group...
-
Page 7: Dry Vacuum Operation
LIMITED TO; COAL, MAGNESIUM, GRAIN OR GUN POWDER. TO REDUCE THE RISK OF HEALTH HAZARDS FROM VAPORS OR DUST, DO NOT VACUUM TOXIC MATERIALS.WARNING: DO NOT PLUG IN POWER CORD TO POWER OUTLET, MAKE SURE PLUG IS DISCONNECTED BEFORE ASSEMBLING THE WET/DRY VAC ® Lotus Tool Group... -
Page 8: Blowing Operation
6.6. Ensure the power switch is turned off and plug in the power supply. (fig. 4) 6.7 Before turning on the vac, firmly hold loose end of the hose. Turn the motor on by BLOWING OPERATION flipping the switch to the ‘I’ ON position.(fig. 5) ® Lotus Tool Group... -
Page 9: Maintenance
9.5. With the removed power head in the upside down position, carefully remove foam filter. (fig.3) 9.6. Use a mild soap and water solution to wash foam filter and rinse with clean water. (fig.4) 9.7. Allow filter to air dry before installing and using again. ® Lotus Tool Group... -
Page 10: Troubleshooting
To return your used device, please use the return and collection systems or contact the retailer where the product was purchased. They can take this product for environmental safe recycling. ® Lotus Tool Group... -
Page 11: Exploded View And Parts List
EXPLODED VIEW AND PARTS LIST ® Lotus Tool Group...
