67" European Ledge Propane Outdoor Fireplace

Model Number: FPDV-LP-002

Customer Assistance (spare/ replacement parts): 1-877-419-2598 or

Email:support@1800acs.com/ prokansupport@1800acs.com

THIS ASSEMBLY MANUAL CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.

WARNING

1. Improper installation,

adjustment, alteration, service

or maintenance can cause

injury or property damage.

Read the installation,

operating and maintenance

instruction thoroughly before

installing r servicing this

equipment.

2. If the information in this

manual is not followed exactly,

a fire or explosion may result

causing property damage,

personal injury or loss of life.

WARNING

1. Do not store or use

gasoline or other flammable

vapors and liquids in the

vicinity of this or any other

appliance.

2. Installation and service

must be performed by a

qualified installer, service

agency or gas supplier.

3. For Outdoor use only

OPERATOR'S MANUAL

DANGER

WHAT TO DO IF YOU SMELL

GAS.

1. Do not try to light any

appliance.

2. Do not touch any electrical

switch; do not use any phone

in your building.

3. Immediately call your gas

supplier from a neighbor's

phone. Follow the gas

supplier's instructions.

4. If you cannot reach your

gas supplier, call the fire

department.

Manual # PK000642024A- Date: 2024 / 07

801480

1 |

P a g e

Table of Contents

Need help?

Do you have a question about the FPDV-LP-002 and is the answer not in the manual?

Questions and answers

Summary of Contents for Prokan FPDV-LP-002

Page 1 67” European Ledge Propane Outdoor Fireplace Model Number: FPDV-LP-002 Customer Assistance (spare/ replacement parts): 1-877-419-2598 or Email:support@1800acs.com/ prokansupport@1800acs.com OPERATOR'S MANUAL 801480 THIS ASSEMBLY MANUAL CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. WARNING WARNING DANGER 1. Improper installation, 1.
Page 2: Table Of Contents
Table of Contents Quality Statement ............................. 3 Important Safety Information ........................ 4-5 Natural Gas Safety Instructions......................6 Getting To Know The Outdoor Gas Fireplace .................7 Package Contents ............................8 Product Information ..........................9 Components ............................. 10 Tools ................................11 Assembly Instructions ..........................12-13 Part Diagrams and Lists ........................14-15 Warning ............................
Page 3: Quality Statement
Quality Statement Important Safety Information • Please read all instructions carefully before assembling this product. • Where applicable, and for your safety, assembly by an adult is strongly recommended. • Use only vendor-supplied hardware to assemble this item. Using unauthorized hardware could jeopardize the structural integrity of the item.
Page 4: Pre-Assembly
Important Safety Information PRE-ASSEMBLY CAUTION Read and perform the following pre-assembly instruc-tions: Tools Required for Assembly • protective work gloves Failure to comply with these instructions may result • protective eyewear in a hazardous situation which, if not avoided, may •...
Page 5: Carbon Monoxide Hazard
Important Safety Information Warnings DANGER Solid fuels shall not be burned in this appliance DANGER The maximum inlet gas supply pressure: Max . 250PSI . Min 5PSI DANGER “Do not use this appliance if any part has been under water. Immediately call a qualified service technician to inspect the appliance and to replace any part of the control system and any gas control that has been under water.”...
Page 6: Natural Gas Safety Instructions
Natural Gas Safety Instructions • Your Natural Gas fireplace is designed to operate • WARNING: Do not route the 10 foot Quick on Natural Gas only, at a pressure of 7" water Disconnect Hose under a deck. The hose must column (W.C.) (1/4 psig or 1.75 kpa), regulated be visible and inspected prior to each grill use.
Page 7: Getting To Know The Outdoor Gas Fireplace
Getting To Know The Outdoor Gas Fireplace Turn the knob to light the burner to activate the digital controller. Press the button for 3 secs to unlock the childproof lock. Long press for 3 secs to light the burner. Turn off the flame. . High flame..
Page 8: Package Contents
Package Contents Quantity Component Description Fireplace body Rocks P a g e...
Page 9: Product Information
Product Information Top View Right Side View Front View P a g e...
Page 10: Components
Components Components Rocks Cover Part No.S0240-30 Qty 1 Qty 1 P a g e...
Page 11: Tools
Tools Wrench (included) P a g e...
Page 12: Assembly Instructions
Assembly Instructions Step 1: Place the rocks evenly onto the burner bowl. Before operation, please be sure to read the following NOTES carefully NOTE Please DO NOT pour more than 22lbs (10kg) of rocks. Pour the rocks evenly into the burner bowl (with exception of the ignitor cover.
Page 13: Installing Lp Gas Tank
Step 2: Hook up the propane tank to the designated connection point. Installing LP Gas Tank Connection LP gas tank 1. . Before connecting be sure there is no debris caught in the head of the LP gas tank, head of the regulator valve or in the head of the burner or burner ports.
Page 14: Part Diagrams And Lists
Part Diagrams and Lists 14 | P a g e...
Page 15 Part Diagrams and Lists DESCRIPTION PART# Countertop, Top S0240-01 S0240-33 Fireplace body S0240-03 Countertop, Front Side door S0240-34 Adjustable leg S0240-05 S0240-06 Propane tank storage tray S0240-07 Slider bracket S0205-45 1 set Slider Regulator S0202-23 Burner tray S0240-08 S0240-09 Burner Burner bracket S0240-10 Control panel...
Page 16: Warning
WARNING WARNING WARNING • This appliance, when installed, must be electrically • LPG models must be used with Liquid Propane Gas grounded in accordance with local codes or, in the and the regulator assembly supplied. Natural Gas absence of local codes, with the National Electrical models must be used with Natural Gas only.
Page 17: Danger
Danger DANGER Do not use an open flame to check for gas leaks. Be sure there are no sparks or open flames in the area while you check for gas leaks. This will result in a fire or explosion which can cause serious bodily injury or death, and damage to property.
Page 18: Troubleshooting
Troubleshooting Troubleshooting To purge air from your gas line and/or reset If the Fireplace fails to light : the regulator excess gas flow device: Turn gas off at source and turn Control Knobs to OFF. Wait Turn Control Knobs to the OFF position. at least 5 minutes for gas to clear, then retry.
Page 19 Troubleshooting Answer: Question: The humming sound is gas flowing through the Can I convert my fireplace from propane to natural gas? regulator. A low volume of sound is normal and will not interfere with the operation of your fireplace. Loud or Answer: excessive regulator humming and/ or low flow and i n t e r m i t t ent lighting may be caused by the regulator's...
Page 20 Troubleshooting Routine care and maintenance is required to preserve the Question: appearance and corrosion resistance of stainless steel. The Regulator and Hose supplied with my gas The fact is stainless steel can corrode, rust and discolor fireplace does not fit the older LP Gas tank I’ve used under certain conditions.
Page 21 Troubleshooting Problem Possible Cause Prevention/Cure Check if LP gas tank is empty. If empty, exchange, reﬁll or replace LP gas tank . No gas flow. If LP gas tank is not empty, refer to “Sudden drop in gas ﬂow or reduced ﬂame height”...
Page 22: Care & Use Instructions
Care & Use Instructions CORRECT LP GAS TANK USE Use of alcohol, prescription or non-prescription drugs can impair your ability to properly assemble and safely LP Gas fireplace models are designed for use with a operate your fireplace. standard 20 lb. Liquid Propane Gas (LP Gas) tank (sold sepa-rately).
Page 23 Care & Use Instructions LP Gas Model only: NOTE about LP Gas Tank Exchange Programs To Secure a 20lb LP Gas Tank to tank storage Many retailers who sell fireplaces offer you the option of re-placing your empty LP Gas tank through an exchange Turn your LP Gas Tank Valve clockwise to the closed service.
Page 24 Care & Use Instructions LP Gas Model only: Check all connections for LP Gas Leaks Connect Regulator with Hose to your LP Gas Tank Never test for leaks with an open flame. Prior to first use, at the beginning of each season, or every time your LP Turn all Burner Valves to the OFF position.
Page 25 Care & Use Instructions Main Burner Lighting Instructions Before each use, check all hoses for cracks, nicks, cuts, burns or abrasions. If a hose is damaged in any way, do not use your fireplace before replacing the hose with an authorized part from the Parts List. Also make sure all gas supply connections are securely tightened.
Page 26 Care & Use Instructions Cleaning the burner tubes and burner ports. To reduce the chance of FLASHBACK FIRE you must clean Regardless o f w h i ch B u r n e r c l eaning p r ocedure you use, we recommend t h a t y ou a l s o complete the follow- the Burner Tubes as follows at least once a month in ing c l eaning r e g i m e n s t o h e l p p r o l ong B u r n e r life.
Page 27: Storage Instructions
Storage Instructions Storage Instructions 1. Shut off the gas at the tank. 2. Disconnect the tank and store it in an upright position in an outdoor space away from dryer and furnace vents and play areas. 3. Coat the burners and other metal parts with cooking oil to repel moisture Item 67”...
Page 28: Technical Data
Technical Data SPECIFICATIONS 67” European Ledge Propane Outdoor Fireplace Models/Finish Main Burners 50,000 BTU/ HR Dimensions (L × W × H) 66.93 × 23.06 ×46.12 in. Warranty 1-year limited 28 | P a g e...
Page 29: Limited Warranty
Limited Warranty Should you encounter any problem, Please contact us first. DON’T Return the product to the store. We can help. For assistance, contact customer service at support@1800acs.com; prokansupport@1800acs.com or call 1-877-419-2598 Monday through Friday from 8:00 a.m. to 8:00 p.m. EST. Please note that the limited warranty is given to and covers the Original purchaser only and such coverage is not transferable.
Page 30 30 | P a g e...
Page 31 31 | P a g e...
Page 32 onta t Information P a g e...
