Electric Drain Cleaner - AE50
User Manual
[Revision 3.1 March 2019]
READ THIS MANUAL CAREFULLY BEFORE USE – FAILURE TO DO SO MAY RESULT IN INJURY, PROPERTY
DAMAGE AND MAY VOID WARRANTY. • KEEP THIS MANUAL FOR FUTURE REFERENCE. • Products covered by
this manual may vary in appearance, assembly, inclusions, specifications, description and packaging.
E&OE
© 2019 Drain Master

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AE50 and is the answer not in the manual?

Questions and answers

Summary of Contents for Drain Master AE50

  • Page 1 Electric Drain Cleaner - AE50 User Manual [Revision 3.1 March 2019] READ THIS MANUAL CAREFULLY BEFORE USE – FAILURE TO DO SO MAY RESULT IN INJURY, PROPERTY DAMAGE AND MAY VOID WARRANTY. • KEEP THIS MANUAL FOR FUTURE REFERENCE. • Products covered by this manual may vary in appearance, assembly, inclusions, specifications, description and packaging.

  • Page 2: Safety

    Electric Drain Cleaner - AE50 Safety Safety messages are designed to alert you to possible dangers or hazards that could cause death, injury or equipment or property damage if not understood or followed. Safety messages have the following symbols: You WILL be KILLED or...
  • Page 3 Electric Drain Cleaner - AE50 Electrical Safety Product Use and Care Product Use and Care When using electric appliances, basic • This product is for domestic use only. • Do not wear cloth gloves or loose precautions should always be followed, clothing, or use a rag to grasp the cable •...

  • Page 4: Table Of Contents

    Electric Drain Cleaner - AE50 Table of Contents Safety ..............................2 Parts Identification ..........................5 Assembly ............................6 Set-Up ..............................7 Tool Set-Up ..............................7 Work Area Set-Up ..........................7 Operation ............................9 Controls ..............................9 Cutting Tools .............................. 9 Using the Cable Power-Feed ........................

  • Page 5: Parts Identification

    Electric Drain Cleaner - AE50 Parts Identification Name Name Name Power-Feed Flat Washer Handle Front Post Rear Hub Belt Guard Screw / Washer Bolt Drum Shaft V-Belt Pulley Bolt Rubber Foot Bolt Cable Bolt V-Belt (A1118) Drum-Connect Cable Frame Belt Guard Bolt 8”...

  • Page 6: Assembly

    Electric Drain Cleaner - AE50 Assembly E&OE © 2019 Drain Master...

  • Page 7: Set-Up

    Electric Drain Cleaner - AE50 Set-Up Tool Set-Up Place the motor switch in the "OFF" position and disconnect the machine from the electrical supply before assembling or making any adjustments to the tool. • Do NOT operate the equipment with the belt guard or any safety device removed. • Use appropriate personal protective equipment while handling and using the equipment.
  • Page 8 Electric Drain Cleaner - AE50 • Choose a firm, stable location for the machine and operator that will remain relatively dry. Do not use the appliance while standing in water. If needed, remove water from the work area. • Verify the electrical outlet is properly grounded. If there is any doubt regards proper earthing of the electrical supply, have a qualified electrician inspect and verify it.

  • Page 9: Operation

    Electric Drain Cleaner - AE50 Operation Controls Motor Switch Cutting Tools There are several cutting tools included. Select the appropriate tool for the cleaning job and attach to Cable. Each is described below. E&OE © 2019 Drain Master...

  • Page 10: Using The Cable Power-Feed

    Electric Drain Cleaner - AE50 If the cutting tool becomes lodged and the cable is still rotating, the cable will start to twist – release the foot switch to stop the motor immediately to help prevent damaging the cable (the cable drum may rotate backwards somewhat as tension in the cable releases).

  • Page 11: Working Through Blockages And Preventing Cable Twist

    Electric Drain Cleaner - AE50 Working Through Blockages and Preventing Cable Twist If the cutting tool becomes lodged and the cable is still rotating, the cable will start to twist – release the foot switch to stop the motor immediately to help prevent damaging the cable (the cable drum may rotate backwards somewhat as tension in the cable releases).

  • Page 12: Maintenance

    Electric Drain Cleaner - AE50 Maintenance Procedures not specifically explained in this manual must be performed by qualified technicians only . • Before performing any inspection, maintenance, or cleaning procedure, place the motor switch in the "OFF" position and disconnect the machine from the electrical supply.

  • Page 13: Troubleshooting

    Electric Drain Cleaner - AE50 Troubleshooting The following information may assist in identifying a problem and rectifying it. Some maintenance activities described may be beyond the scope of some users. For procedures that you are not comfortable with or have the tools or experience for, have the unit serviced by a service centre or qualified technician.

  • Page 14: Specifications

    Electric Drain Cleaner - AE50 Motor does not operate or the foot switch sticks Possible Fault Action Foot switch may be leaking Check for leaks in air line leading to foot switch and for tears or holes in the foot switch bladder.
  • Page 15 ©2019 Drain Master. All rights reserved. No part of this document, including descriptive content, concepts, ideas, diagrams or images may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying, scanning or recording, or any information storage and retrieval system, without express permission or consent from the publisher.
