- Page 1 2 & 3 BIN RECYCLING CENTER 471-02-SERIES / 471-03-SERIES USER GUIDE...
- Page 2 THANK YOU FOR YOUR PURCHASE. Known in the industry for excellent products, Alpine Industries is a manufacturer of innovative, solution-based products for the commercial and institutional markets worldwide. Combining commitment to the customer, design innovation and skilled, dedicated workforces, they have produced a range of products that are an essential part of every commercial facility.
- Page 3 Table of Contents Parts List Assembly Instructions Limited Warranty 12 Disclaimer...
-
Page 4: Parts List
Parts List A Bins (x3) B Base C Top D Rings (x3) E Stickers (x3) - Page 5 Assembly Instructions STEP 1 To assemble the Base (B) of the recycling center, lay it on a flat surface, fold forward the four smaller tabs on the board’s two longer sides. STEP 2 Fold both of the longer pieces up, and the tabs should almost meet.
- Page 6 Assembly Instructions STEP 3 Fold the two other sides up. STEP 4 Fold the side again, over the tabs, on the designated line.
- Page 7 Assembly Instructions STEP 5 Press down into the notches to lock in place. STEP 6 To assemble the Bins (A), grab and hold the Bins (A) so that the handles face the ground. Open them up and fold all four tabs down until they lock into place.
- Page 8 Assembly Instructions STEP 7 Once all the Bins (A) are assembled, set them in the Base (B).
- Page 9 Assembly Instructions STEP 8 To assemble the Top (C) of the recycling center, lay it on a flat surface, fold forward the four smaller tabs on the board’s two longer sides. STEP 9 Fold both of the longer pieces up, and the tabs should almost meet.
- Page 10 Assembly Instructions STEP 10 Fold the two other sides up and then fold one more time over the tabs. STEP 11 Press down into the notches to lock in place.
- Page 11 Assembly Instructions STEP 12 STEP 13 Place the Top (C) on the Bins (A).
- Page 12 Assembly Instructions STEP 14 Select your desired Labels (E) and place them on the Rings (D).
- Page 13 Assembly Instructions STEP 15 Place your Rings (D) with desired Labels (E) on the Top (C).
-
Page 14: Limited Warranty
27 Selvage Street • Irvington, NJ • 07111 • © 2020 Alpine Industries. alpineindustries.com 1. Alpine Industries (the company) warrants to the purchaser that the product will be free from defects in workmanship and materials for a period of one (1) year from the date of purchase. - Page 15 PERMITTED BY APPLICABLE LAW, EVEN IF ANY REMEDY FAILS ITS ESSENTIAL PURPOSE. If any provision of this Agreement is declared invalid or unenforceable, the remaining provisions of this Agreement will remain in effect. Alpine Industries has the right to modify these terms and conditions at any time.
- Page 16 471-02-SERIES / 471-03-SERIES 27 Selvage Street • Irvington, NJ • 07111 • © 2020 Alpine Industries. alpineindustries.com...
