Summary of Contents for Buddy ZEPTO
- Page 1 FOOD WASTE DISPOSER USER MANUAL...
- Page 2 Thank you for choosing our Food Waste Disposer 1. Please read the User's Manual before using the Food Waste Disposer (FWD). 2. Please ensure that there are no children nearby when operating the FWD, to prevent any potential hazards & misfortunes. 3.
-
Page 3: Product Introduction
PRODUCT INTRODUCTION The Food Waste Disposer (FWD) is installed under the sink. Turn on the tap and switch, put the foods waste in it, which is all you need to do. Then, food waste will be ground into small pieces and to be drained with water directly. -
Page 4: Installation Step
INSTALLATION STEP (Read completely before starting) A. Separate the hopper from mount ring by turning mount ring clockwise and remove. B. Remove cushion mount from the sink flange and remove mount ring. C. Unscrew support ring from sink flange and remove fiber gasket. D. -
Page 5: Product Data
PRODUCT DATA MODEL BUDDY FOOD WASTE DISPOSER ZEPTO BUTTON REMOTE CONTROL HORSEPOWER 1/2 HP INPUT POWER 390W VOLTAGE/FREQUENCY 110/220V , 50/60HZ RATED ROTARY SPEED 3300/3500 RPM GRINDING CAPACITY 1000 ML GRINDING ABILITY <2.5 MM NOISE LEVEL 55-65dB MATCHED SINK HOLE SIZE... -
Page 6: Malfunction Trouble Shooting
MALFUNCTION TROUBLE SHOOTING 1) LARGE NOISE Perhaps something is stucked in the FWD. Turn off the FWD and running tap water. Remove the removable splash guard and remove the stem (stucked item). Finally, please put the removable splash guard back on its original place. (2) DISPOSER NOT WORKING If your disposer doesn’t make any noise when it's turned on, fixing it may be as simple as pressing the reset button.
