- Page 1 Operator’s Manual Advancer Simulator Multi-Temperature T T K K 6 6 2 2 3 3 1 1 8 8 - - 1 1 1 1 - - O O P P - - E E N N August 2024...
-
Page 2: Table Of Contents
Table of Contents I I n n t t r r o o d d u u c c t t i i o o n n ....................3 3 C C u u s s t t o o m m e e r r S S a a t t i i s s f f a a c c t t i i o o n n S S u u r r v v e e y y . - Page 3 Introduction This manual is published for informational purposes only and the information furnished herein should not be considered as all-inclusive or meant to cover all contingencies. If more information is required, consult your Thermo King Service Directory for the location and telephone number of the local dealer.
-
Page 4: Customer Satisfaction Survey
Customer Satisfaction Survey Let your voice be heard! Your feedback will help improve our manuals. The survey is accessible through any internet-connected device with a web browser. Scan the Quick Response (QR) code or click Technical Publications EMEA Feedback to complete the survey. TK 62318-11-OP-EN... -
Page 5: Safety Information
Safety Information Danger, Warning, Caution, and Notice Thermo King®/ FRIGOBLOCK recommends that all service be performed by a Thermo King/FRIGOBLOCK dealer and to be aware of several general safety practices. Safety advisories appear throughout this manual as required. Your personal safety and the proper operation of this unit depend upon the strict observance of these precautions. -
Page 6: General Practices
S S a a f f e e t t y y I I n n f f o o r r m m a a t t i i o o n n General Practices Thermo King recommends that all services be performed by a Thermo King dealer. -
Page 7: Electrical Hazards
S S a a f f e e t t y y I I n n f f o o r r m m a a t t i i o o n n Electrical Hazards D D a a n n g g e e r r H H a a z z a a r r d d o o u u s s V V o o l l t t a a g g e e ! ! Risk of fatal injury from electric shocks! Do not touch exposed cables with your bare hands. - Page 8 S S a a f f e e t t y y I I n n f f o o r r m m a a t t i i o o n n W W a a r r n n i i n n g g H H a a z z a a r r d d o o u u s s V V o o l l t t a a g g e e ! ! Never work alone on high voltage circuits in the refrigeration unit.
-
Page 9: First Aid
S S a a f f e e t t y y I I n n f f o o r r m m a a t t i i o o n n First Aid R R E E F F R R I I G G E E R R A A N N T T •... - Page 10 S S a a f f e e t t y y I I n n f f o o r r m m a a t t i i o o n n If the victim must be removed from a live circuit, pull the victim away with a non-conductive material.
-
Page 11: Unit Description
Unit Description The Thermo King "Advancer Simulator" is designed to experience operating an actual Thermo King transportation refrigeration equipment which is controlled by the "A-Series controller”. It is a stand-alone piece of equipment which needs only to be connected to utility power to operate. The "Advancer Simulator"... -
Page 12: Components Description
Description Components Description The different components of the Advancer Simulator is described as follows: Description Item A-Series Controller HMI: The main controller for the simulator (Refer the later session for more details on the HMI operations). Controller USB PORT: This port is used to insert a USB Type A Storage Device (Pen Drive). -
Page 13: Hmi
D D e e s s c c r r i i p p t t i i o o n n Description Item Adjustment Switches: Switches used to adjust parameters used by the HMI to simulate the Advancer unit operation. (Individual switch functions and LED indication are detailed in later.) Triple Combo Display: The Triple Combo Display, shows the current fuel level by lighting up the bar on the right, shows the current Return Air Temp, and lights... -
Page 14: Adjustment Switches
D D e e s s c c r r i i p p t t i i o o n n Description Item Defrost Key: Once pressed, the key will initiate a Manual Defrost cycle. Display: The LCD Display, displays the output of the HMI on the screen. Powered ON when the HMI ON key is pressed. - Page 15 D D e e s s c c r r i i p p t t i i o o n n Description Item Discharge Air Temp: Adjust the Discharge Air Temperature up or down by 0.5° C/0.9°F (by default). Evap Coil Temp: Adjust the Evaporator Coil Temperature up or down by 0.5°C/ 0.9°F (by default).
-
Page 16: Door Open Switches
D D e e s s c c r r i i p p t t i i o o n n Door Open Switches Door Open switches allows for switching the door status to OPEN or CLOSED. By default, it is CLOSED, and the LED backlight for the switches is OFF. -
Page 17: Hpco Switch
D D e e s s c c r r i i p p t t i i o o n n HPCO Switch The High Pressure Cut Out switch allows to switch between HIGH and NORMAL pressure levels. On HIGH position, generate a RED alarm in HMI. Other Ports Figure 1. -
Page 18: Method Of Operation
Operation Instructions Method of Operation 1. Plug in the mains power into the simulator. 2. Turn ON the “Main Power Switch” part of the main power plug of the simulator. 3. Wait for the “PRG RUNNING” LED to light up before pressing the HMI ON button. - Page 19 Electronic Module Diagnostic using the Simulator The different electronics modules used in the Advancer unit, like the HMI, HPM, LPM, and BlueBox2, can be replaced with the modules to be tested in the simulator and checked for normal operation. To allow this, the simulator enclosure can be easily opened to access the internal electronics modules.
-
Page 20: Specification
Specification P P o o w w e e r r S S o o u u r r c c e e : : The “Advancer Simulator” is intended to be operated indoors from the following power source: AC Input Power: 85 ~ 264 VAC and 47 ~ 63 Hz. S S i i m m u u l l a a t t e e d d P P a a r r a a m m e e t t e e r r s s : : The “Advancer Simulator”... -
Page 21: S S P P E E C C I I F F I I C C A A T T I I O O N
S S p p e e c c i i f f i i c c a a t t i i o o n n Telematics The Telematics connections available with the “Advancer Simulator” are the iBOX and the TouchLog connections. N N o o t t e e : : The Touchlog connection is available through using the 424725 Touchlog Serial Port Harness. -
Page 22: Touchlog Connector
S S p p e e c c i i f f i i c c a a t t i i o o n n TouchLog Connector Description Code TX2-01 RS232 Receive line RX2-01 RS232 Transmit 2 Line Signal 2 Ground COM2-01 RX-01 RS232 Receive 1 line... - Page 23 N N o o t t e e s s TK 62318-11-OP-EN...
- Page 24 Thermo King – by Trane Technologies (NYSE: TT), a global climate innovator – is a worldwide leader in sustainable transport temperature control solutions. Thermo King has been providing transport temperature control solutions for a variety of applications, including trailers, truck bodies, buses, air, shipboard containers and railway cars since 1938.
