Unit Overview Unit Overview Translucent Door Graphic Cabinet Door Door Programmable Latch Dispense Buttons Dispensing Nozzles Legs Drip Tray and Drain Assembly...
Page 3
Unit Overview Unit Overview Cabinet Installation Instructions Programming Instructions Pump Assemblies Whipper Assemblies Display Board...
Page 4
Unit Overview Unit Overview Plastic Tubing Holder Pump Housing Pump Rotor BIB Product Tube Water Supply Tube Whipper Dosing Head Note: Pump Rotor should only be rotated counter-clockwise Whipper Chamber Dosing Whipper Restrictor Heads Expresso...
Drip Tray Assembly Drip Tray Assembly 103426 Cup Rest 103415 Drain Pan 103425 Drain Pan Fitting 02-0158 O-Ring 103420-BPC Drip Tray Housing 103417 Drain Support Bracket 103424 Drain Receptacle 103455 Drain Hose 103452 Hose Clamp...
Page 8
511027 Water Filter Water Filter 100054 Accessories Bag Accessories Bag 103382 100754 103457 Product Labels Nozzle Brush 111622 Shut-off Assembly Water Filter Water Filter Bracket Filter to Unit Water Line Bracket (Unit) Mounting Screws (2) 100626 103485 Bracket (Filter) Mounting Screws (4) 107038 Espresso Product Packing Adapter 107018...
Page 9
New Water New Water Bracket Filter Assembly Filter Assembly New units will be shipped with an upgraded water filter assembly. The installation will Shut-off be exactly the same as the previous filter assembly, however some of the parts (shutoff, filter, & bracket) may look slightly different.
Page 10
Plastic Legs, Fluorescent Tubes and Plastic Legs, Fluorescent Tubes and Translucent Door Graphic 100542 103377 102062...
Machine Setup Machine Setup Leg Installation 1. Install two rear unit legs. 2. Align Drain Support Bracket holes with those in bottom front of unit and install front legs.
Page 12
Machine Setup Machine Setup Fluorescent Tube Installation Install two (2) fluorescent tubes in door face and rotate ¼ turn to lock in holder.
Page 13
Machine Setup Machine Setup Preparing the Graphic Both the translucent graphic and the clear plastic cover shield are shipped with a protective film. Translucent Graphic Start at a corner, and carefully pull the protective film diagonally to remove. Clear Plastic Cover...
Page 14
Machine Setup Machine Setup Graphic Installation Unscrew and remove three (3) brass thumbscrews from inside top of door panel, then lift and remove door cap. Peel clear plastic on front, and white paper on rear of Graphic. Slip Graphic into slide guides and lower until sign is seated at bottom of guides.
Page 15
Machine Setup Machine Setup Water Filter Installation Overview The water filter will require some assembly and preparation prior to installing. The filter bracket will need to be mounted to the top of the filter, the cartridge will need to be removed from the protective bag and the filter installation instructions must be removed from the canister.
Page 16
Machine Setup Machine Setup Water Filter Bracket Mounting Mount water filter bracket to filter Screws with four (4) screws provided in accessories bag. Assure that “outlet” is on the right of bracket so the pre- formed tubing (installed in future step) will reach unit water inlet.
Page 17
Machine Setup Machine Setup Mounting Water Filter Bracket Locate water inlet at upper rear of unit. Install filter bracket using two (2) #8 screws and star washers provided in accessories bag.
Page 18
Machine Setup Machine Setup To Unit Inlet Tubing & Shutoff Connections Fitting Run pre-formed water supply line between water filter outlet and unit water inlet.
Machine Setup Machine Setup Water Supply Connection Run water supply line between water source and shutoff inlet. It is highly recommended to leave enough extra tubing length to allow for serving unit. Equipment should be installed to comply with all federal, state and local plumbing codes.
Page 20
Machine Setup Machine Setup Drip Tray Housing Installation Align Drip Tray Housing guides with Drain Support Bracket arms and slide toward rear of unit.
Machine Setup Machine Setup Drip Tray Installation Align Drip Tray drain with Drain Support Bracket drain receiver and push down until seated. Route Drain Support Bracket hose into location drain assuring a downward pitch to allow for proper drainage. Equipment should be installed to comply with all federal, state and local plumbing codes.
Machine Start up Machine Start up Turn on water to unit and check for leaks Plug unit into electrical supply (120V,3 pole, 4 wire grounding type receptacle). Hot water will begin filling. Activate the Light Switch (toggle up) located on the inside of the door panel. The LCD window will display self test message briefly, then sanitation indicators will light.
Page 24
Moo BIB Installation Instructions Moo BIB Installation Instructions Rear BIB Alignment Guide Flap Front BIB Guide Round Closure Lay BIB on back and remove round Lift up front cardboard flap and Assure front and rear BIB alignment guides perforated cardboard closure remove BIB tubing, then re-close flap are in place before installing packaging Front BIB Guide...
Page 25
Expresso BIB Installation Instructions Expresso BIB Installation Instructions Rear BIB Alignment Guide Expresso Flap Product Adapter Front BIB Guide Round Closure Shipping Lift up front cardboard flap, remove BIB Lay BIB on back and remove round Assure that front and rear BIB alignment connector, then re-close flap.
Page 26
Machine Calibration Instructions Machine Calibration Instructions Overview: Machine H2O settings are calibrated at the factory and normally do not need adjustment unless a dispensing valve is replaced or the measured dispense volume does not match the displayed setting. Concentrate settings should be performed at initial set-up and each time the product density (or viscosity) changes.
Page 27
Machine Calibration Instructions Machine Calibration Instructions Concentrate Calibration Concentrate Calibration Step 1 - - - Press & hold “Settings” (middle) button After approximately 5 seconds, display will change to “- - -” Step 2 Continue holding button until display - - - changes to “Con”...
Page 28
Machine Calibration Instructions Machine Calibration Instructions Concentrate Calibration Concentrate Calibration 0.30 Step 3 Press “Settings” (middle) button. Display will change to “0:30” (30 seconds). Place measuring cup (preferably at least a 12 fl oz graduated cup) under the dispensing head to be calibrated as indicated by channel light.
Page 29
Machine Calibration Instructions Machine Calibration Instructions Concentrate Calibration Concentrate Calibration 0.30 Step 4 Press “Settings” button again, machine will pump concentrate into measuring cup for 30 seconds.
Page 30
Machine Calibration Instructions Machine Calibration Instructions Concentrate Calibration Concentrate Calibration Step 4 (continued) When concentrate stops, read concentrate volume (in ounces) from cup. 9.0 ounces Enter measured value into display Toggle left button 0.30 9.00 New Bag (+) to increase value Toggle right button Rinse (-) to decrease value...
Page 31
Machine Calibration Instructions Machine Calibration Instructions Concentrate Calibration Concentrate Calibration Step 5 0.30 9.00 Press “Settings” to store settings. Display will change to 0:30, and “Middle” Channel Indicator light (middle dispensing head) will illuminate. Empty and move the measuring cup under the middle dispensing head.
Page 32
Machine Calibration Instructions Machine Calibration Instructions Water Calibration (if necessary) Water Calibration (if necessary) Step 1 - - - Press & hold “Settings” button, after approximately 5 seconds Display will change to”- - -” Step 2 Continue holding button for approximately 8 more seconds, (display - - - changes to “Con”...
Page 33
Machine Calibration Instructions Machine Calibration Instructions Water Calibration (if necessary) Water Calibration (if necessary) H2O Ambient Calibration is a factory. Settings should not need re-calibration unless the measured dispense volume does not match the displayed setting. Note: Continuing to step #3 begins the calibration the unit for Hot Water settings.
Page 34
Machine Calibration Instructions Machine Calibration Instructions Water Calibration Water Calibration 0.30 Step 3 Press “Settings” (middle) button. Display will change to “0:30” (30 seconds). Place measuring cup (preferably at least a 32 fl oz graduated cup) under the dispensing head to be calibrated as indicated by channel light.
Page 35
Machine Calibration Instructions Machine Calibration Instructions Water Calibration Water Calibration 0.30 Step 4 Press “Settings” button again, machine will pump water into measuring cup for 30 seconds.
Page 36
Machine Calibration Instructions Machine Calibration Instructions Water Calibration Water Calibration Step 4 (continued) When concentrate stops, read 24.0 ounces water volume (in ounces) from cup. Enter measured value into display Toggle left button 0.30 24.0 New Bag (+) to increase value Toggle right button Rinse (-) to decrease value...
Page 37
Machine Calibration Instructions Machine Calibration Instructions Water Calibration Water Calibration Step 5 0.30 9.00 Press “Settings” to store settings. Display will change to 0:30, and “Middle” Channel Indicator light (middle dispensing head) will illuminate. Empty and move the measuring cup under the middle dispensing head.
Page 38
Machine Calibration Instructions Machine Calibration Instructions Step 7 9.00 In Hot water calibration mode, when right dispense settings are stored, display changes to “Cld” prompting you to repeat steps 3-5 for Cold Water calibration of each dispensing head. After Hot water programming In Cold water calibration mode, when right dispense settings are stored, display...
Programmable Buttons Programmable Buttons (3 per channel) (3 per channel) Each button on the door switch is programmable for the following: A. Button Enable - Enables or disables each individual button. Example: Enable center button only for a manual dispense, hot or cold product.
Page 40
Programmable Buttons Programmable Buttons B. Portion Control Allows for the ability to set a volume dispense ( in ounces) for any button. Example: Program the 1 button for each dispense for a small cup dispense, the center button for a large cup dispense, and the 3 button for a manual dispense Unsweetened...
Page 41
Programmable Buttons Programmable Buttons C. Hot/Cold Water Dispense Allows customer choice of hot or cold (ambient) dispense per button Example: Program the 1 & 3 buttons on each channel “Hot” & “Iced” (ambient). Unsweetened Sweetened French Vanilla Latte Cappuccino Cappuccino Iced Iced Iced...
Page 42
Multi Level Multi Level Programming Programming Instructions Instructions...
Page 43
Product Ratio Instructions Product Ratio Instructions Step 1 Press and hold Settings Step 4 button until display changes to Toggle Ratio Value with: Step 2 New Bag (+) to increase Press and hold New Bag button until display changes to Rinse (-) to decrease Step 3 When desired ratio value is...
Portion Control Portion Control Step 1 Press and hold Settings Step 4 button until display Toggle Ratio Value with: changes to Step 2 New Bag (+) to increase Press and hold New Bag button until display Rinse (-) to decrease changes to Step 3 When desired volume value is...
Page 45
Button Manual Dispense – Enable/Disable Button Manual Dispense – Enable/Disable Step 1 Press and hold Settings button until display Step 4 changes to Toggle Ratio Value with New Bag (+) or Rinse (-) Step 2 buttons until display reads Press and hold New Bag button until display changes to Step 3...
Hot/Cold Water Selection Hot/Cold Water Selection Step 1 Step 4 Press and hold Settings button until display changes to Press New Bag (+) or Rinse (-) buttons until display reads Step 2 “hot” or “cold (ambient)” water Press and hold New Bag temperature button until display changes to...
Whipper Motor – Enable/Disable Whipper Motor – Enable/Disable Step 1 Press and hold Settings button until display Step 4 changes to Press New Bag (+) or Rinse (-) Step 2 buttons until display reads Press and hold New Bag button until display changes to Step 3 If “off”...
