Page 1 CED M2 CHRONOGRAPH Competitive Edge Dynamics Ltd. Printed in China...
Page 2 Main Unit Sensor MC015 M2002 CED Millennium Replacement Sensor CED M2 Chronograph MC002 Main Unit M2015 Infrared Screen Set With incredible accuracy, the Patented Infrared Screen Set eliminates the need for sunlight when using the CED Millennium Chronograph system, and gives you the free-...
Page 3 CED M2 Chronograph Instruction Manual CED proudly introduces the new CED M2 Chronograph System. Building on the original CED Mil- lennium Chronograph, which has been an industry standard for the past eight years, the new CED M2 Chronograph begins where its predecessor leaves off.
Page 4: Table Of Contents
Contents Symbols / Abbreviations – Descriptions for use ....3 - 4 Keypad Organization / Keypad Layout ........4 Keypad Explanation ...............5 Quick Steps to easy use ............6 Features & Functions continued ..........7 - 12 Detailed Functions..On / Off ...............7 Meter / Feet (M/F) ............7 Store Current String ............7 Clear Current String ............7 Clear All Memory ............7...
Page 5: Symbols / Abbreviations - Descriptions For Use
Symbols / Abbreviations – Descriptions for use Missed Start Sensor This means that a bullet went over the Stop sensor but not over the Start sensor. Missed Stop Sensor A bullet went over the Start sensor but never went over the Stop sensor.
Page 6: Keypad Organization / Keypad Layout
Symbols / Abbreviations – Descriptions for use (Continued …) High Three Shot Average The High Three Shot Average is being displayed Extreme Spread The difference between the Highest and Lowest velocities is being displayed. Standard Deviation The Standard Deviation is being displayed. (See U5 below) Under 5 shots captured in the string This will be displayed when the user has requested the Standard Deviation but there have not been sufficient shots captured to perform the calculation.
Page 7: Keypad Explanation
Keypad Explanation Button Function Description Calc On/Off Power Button Turn the unit on and off Alt-Calc Calculator Enter and exit the calculator Feet/Meters Toggle between FPS and MPS modes Allows the user to select a string for review or omit- Select String ting Alt-CLRA...
Page 8: Quick Steps To Easy Use
Place the 2 ft. mounting bracket so that the fixed end is facing forward (the portion of the arm with the hinge that folds up should be facing away from you). Open the CED M2 Chronograph and press the "ON/OFF" button to activate the chronograph. You will see "0000" along with "0" shots and "2.0 F" or “0.6M”...
Page 9: Features & Functions Continued
& functions, read on..On / Off On / Off button turns the chronograph on and off. The CED M2 Chronograph has an Auto-Shut Off mode, which activates when no activity (input) occurs for a 30-minute period of time. There is no memory loss and the chronograph can be re-started by pressing the ON button once again.
Page 10: Omit Entire Shot String (Om)
Recalling a Specific String (STR) (Continued…) When the user is reviewing strings it is not necessary to reselect the current string before recording more velocities (firing more shots). When a shot is detected the chronograph will change back to the current string automatically.
Page 11: Standard Deviation
Standard Deviation of the combined shots / velocities in that string. The larger the number of data entries in the string, the more accurate the SD becomes. The CED M2 Chronograph requires a minimum of 5 shots / velocities to be received in order to calculate SD. However, it should be noted that the more data entries used in SD calculations, the more reliable the SD will actually be.
Page 12: High Three Velocity Average (Alt - Av3)
High Three Velocity Average within a String (ALT – AV3) The Alt-AV3 button is used to average the highest 3 velocities (values) in the current shot string or the shot string under review and display the result. Calculator Function (CALC) This function will implement a Multiplication, Division, Addition, and Subtraction (MDAS) calcula- tor in the chronograph.
Page 13: Advanced Error Warning Function (Er)
The system gives ample warning to allow sufficient time for the battery to be changed. Additionally, the CED M2 Chronograph has a spare battery compartment to allow the user to store an extra battery on hand. It is located next to the battery compartment and can be accessed by re- moving the panel which separates the two compartments, inserting a spare battery and then replacing the panel.
Page 14: Skyscreen Sensors / Diffusers
Shotgun / Bows The CED M2 Chronograph can be used for shotshells. The system measures the velocity of the front pellets in the shot string. A closer screen spacing of the tripod of 3 to 4 ft. from the muzzle of the shotgun should be used.
Page 15: Pc Installation Process
Installation Process Windows XP Program Installation 1. Insert the CED USB Data Collector CD in the CD drive. Wait for the installer program to start. If the installer does not start automatically, change the working folder to the CD and manually run the program USBCED.exe.
Page 16 USB Installation (Continued…) There might be multiple sets of other devices already installed. Many Human Interface Devices (HID Devices) have the same entry titles. To find the chronograph device you need to concentrate on the USB Human Interface Device entries. Find the first USB Human Interface Device entry.
Page 17: Un-Installation Process
OK button. The CED USB Data Collector will be removed from the computer. ALL NEW RELEASES of the CED M2 Data Collector software program are also available for FREE download from http://www.shootingsoftware.com or http://www.CEDhk.com web sites.
Page 18: In Case Of Trouble
IN CASE OF TROUBLE Things to check - a. Unplug the "start" & "stop" jacks and plug them in once again, making sure they are completely inserted and tight in their fitting. b. Check the sensor bracket to confirm it is pushed all the way into each sensor. The sensor bracket is designed to fit precisely into the back wall of each sensor cavity.
Page 19: Chronograph Results And Variables
IN CASE OF TROUBLE (Continued…) j. Verify your sensors are mounted so that the front sensor and screen cannot swing upward. The hinged portion of the mounting bracket should be positioned between the tripod head and the furthest sensor. The skyscreen side supports may move due to muzzle blast, but for best results the sensors must not move.
Page 20: Frequently Asked Questions
Q & A Sheet for the CED M2 Chronograph Q. I recently used my CED M2 Chronograph for the first time. It would not register any shots I fired with my 30.06 rifle. I set it up according to the book and stood a couple of feet behind it. Nothing happened.
Page 21 Thus, it can be located close to the screens themselves. Q. Will my CED M2 Chronograph register shots if I put it down range further than the specified 7 to 10 feet? A.
Page 22: Guarantee
WARRANTY ** TWO YEAR LIMITED WARRANTY ** If the CED M2 Chronograph breaks due to defective parts or workmanship, we will replace it for you. This warranty does not cover any failures attributable to abuse, mishandling, failure to follow op- erating instructions, alterations, or accident.
Page 23: Chronograph Accessories
Chronograph Accessories (Continued…) Infrared Sidearm Replacement Replacement Set Skyscreen Set Set consists of four side- The Replacement arms, two of which include Skyscreen set includes cable and jack connections two top screens and four for the infrared screens. sidearms. MC014 MC003 Replacement 2 ft.
