PORTABLE CD PLAYER WITH EXTERNAL SPEAKER
Item No:
M879
Instructions for Use
Please read and retain these instructions for future reference
Specification:
Power Requirement:
Speaker Output Power:
FM Receiver Frequency:
Bluetooth:
Accessories: 1pc earphone and 1pc USB-C charging cable
Please read this instruction manual thoroughly before starting and ensure you are familiar with
the operation of your new PORTABLE CD PLATER WITH EXTERNAL SPEAKERS.
•
Play CD, CD-R, CD-RW, MP3 discs
•
A-B Repeat function
•
Anti-skip protection CD 60S /MP3 120S
•
FM radio
•
Bluetooth transmit
•
LCD display
•
Built-in lithium-ion rechargeable battery (3.7V/1000mAh)
•
Earphone socket
•
Input connectors: USB-C jack
•
Speaker Output Power: 0.25W+0.25W (8 ohms, 1 kHz, THD 10%)
5V DC (1.0A) USB-C (USB-C charging cable supplied)
Built-in lithium-ion rechargeable battery (3.7V/1000mAh)
AC Adaptor (not included): Input: AC 230V ~ 50Hz
0.25W+0.25W (8 ohms, 1 kHz, THD 10%)
87.5 – 108 MHz
Version 4.0 & 5.0
v001: 04/07/24
Output: DC 5V
1000mA
Advertisement
Table of Contents
Related Manuals for Bergstrom M879
Summary of Contents for Bergstrom M879
- Page 1 PORTABLE CD PLAYER WITH EXTERNAL SPEAKER Item No: M879 Instructions for Use v001: 04/07/24 Please read and retain these instructions for future reference Specification: Power Requirement: 5V DC (1.0A) USB-C (USB-C charging cable supplied) Built-in lithium-ion rechargeable battery (3.7V/1000mAh) AC Adaptor (not included): Input: AC 230V ~ 50Hz...
- Page 2 CAUTION SAFETY Before you use read the following safety instructions. 1. As the laser beam used in this compact disc player is harmful to the eyes, do not attempt to disassemble the casing. 2. Stop operation immediately if any liquid or solid object should fall into the cabinet. 3.
- Page 3 16. To reduce the risk of electric shock, do not remove any screws. The product does not contain any user-service able parts inside. Product repairs should only be carried out by authorized personnel. To prevent possible hearing damage, do not listen at high volume levels for long periods of time. Consistent exposure to high volumes when using headphones can damage your hearing.
-
Page 4: Location Of Controls
LOCATION OF CONTROLS FM PRESET- BUTTON L- SPEAKER FOLDER- BUTTON FM PRESET+ BUTTON MODE BUTTON FOLDER+ BUTTON BUTTON POWER OFF BUTTON BATTERY CHARGING INDICATOR CD STOP BUTTON POWER ON BUTTON EARPHONE JACK CD / BUTTON / TUNER- BUTTON EQ/BBS ON/OFF BUTTON / TUNER+ BUTTON VOLUME + BUTTON LCD DISPLAY... -
Page 5: Power Source
POWER SOURCE Built-in Lithium Battery This unit operates on a built-in Li-ion battery that can be recharged either by using DC 5V, 1A USB charger (not included) or from an AC adaptor (not included) with a rated output of DC 5V, 1000mA. The internal battery may not be fully charged out of the box, even if the Red charging LED turns off. - Page 6 NOTE 1. You can use an USB AC adaptor with an output current of 500 mA or computer USB port as well, but it may take a very long time (10 hours or more) before charging completes. When using such a USB AC adaptor, it’s recommended that you turn off power before charging the battery.
- Page 7 CD OPERATION PLEASE READ THIS IMPORTANT INFORMATION: CD mechanisms used in devices like this are designed to fully read all commercial CDs. They will also read self-compiled CD-R/CD-RW discs but it may take up to 10 seconds for playback to start. If playback does not start, it is likely due to the quality of the CD-R/RW disc and/or the compatibility of the CD compilation software.
-
Page 8: Radio Operation
If you’re listening to the player at volume level 7 or lower and turn the unit off, the volume will be at the same level when the unit is turned on again. FOLDER UP (MP3 CD only) Tap the FOLDER+/- BUTTON (#12/#13) repeatedly to select MP3 CD folder location in the upward direction. - Page 9 repeatedly. Use the manual tuning method to tune in weaker stations that are bypassed during Automatic Tuning. 5. To automatically tune to the next available radio station, press and hold the TUNER- or TUNER+ BUTTON (#12 or #13) for 1-2 seconds until frequency readout on the display begins to scan and then release the button.
- Page 10 CD will be heard on the connected Bluetooth device. 7. If you move out of Bluetooth range (10m) with the M879, the “BT TX” indicator on the LCD Display (#7) will begin flashing. Move the M879 or your Bluetooth device back within range and reconnect the Bluetooth device if necessary.
-
Page 11: Hold Function
BBS FUNCTION 1. Press and hold the BBS BUTTON (#16) to turn on the BBS to enhance the bass effect of the music. Display will show “BBS ON” once. 2. Press and hold the button again to turn off the BBS. Display will show “BBS OFF” once again. Note: EQ will be reset to “FLAT”... -
Page 12: Troubleshooting Guide
TROUBLE SHOOTING GUIDE SYMPTOM POSSIBLE SOLUTION Fully recharge the built-in Battery no power No Sound rechargeable battery. Volume set at minimum Increase Volume. Noise or sound distorted Earphone cord is not Extend earphone cord on FM broadcast extended The unit is not in RADIO (FM) Switch to FM mode mode Radio no sound... - Page 13 DISPOSAL • Coopers of Stortford use Recyclable or recycled packaging where possible. • Please dispose of all packaging, paper, cartons in accordance with your local authority recycling regulations. • At the end of the product’s lifespan please check with your local council authorised household waste recycling centre for disposal.
