USB Smart Cable
User Manual
UM018116-0622
®
Copyright ©2022 Zilog
, Inc. All rights reserved.
www.zilog.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the zilog ZUSBSC00100ZACG and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Littelfuse zilog ZUSBSC00100ZACG

  • Page 1 USB Smart Cable User Manual UM018116-0622 ® Copyright ©2022 Zilog , Inc. All rights reserved. www.zilog.com...
  • Page 2 USB Smart Cable User Manual Warning: DO NOT USE THIS PRODUCT IN LIFE SUPPORT SYSTEMS. LIFE SUPPORT POLICY ZILOG’S PRODUCTS ARE NOT AUTHORIZED FOR USE AS CRITICAL COMPO- NENTS IN LIFE SUPPORT DEVICES OR SYSTEMS WITHOUT THE EXPRESS PRIOR WRITTEN APPROVAL OF THE PRESIDENT AND GENERAL COUNSEL OF ZILOG CORPORATION.
  • Page 3: Revision History

    2022 ® applications; customers are encouraged to instead use The Encore! Smart Cable, ZUSBESC0200ZACG. Updated logos to Littelfuse branding Updated Connecting to the Target Board. Added 2016 Disconnecting from the Target Board section. Updated maximum System Clock value, Supported Target 2013 Environments table.
  • Page 4: Usb Smart Cable

    USB Smart Cable User Manual USB Smart Cable Zilog’s USB Smart Cable device, part number ZUSBSC00100ZACG, ® ® allows you to connect ZNEO and eZ80Acclaim! development boards to a high-speed or full-speed USB port on a Zilog Developer Studio II (ZDS II) host system.
  • Page 5: Kit Contents

    USB Smart Cable User Manual Kit Contents The contents for the USB Smart Cable kit are: • USB Smart Cable • Six-conductor ribbon cable • This USB Smart Cable User Manual (UM0181) Supported Host Environments The supported host environments are: •...
  • Page 6: Installing The Usb Smart Cable And Driver

    USB Smart Cable User Manual Table 2. USB Smart Cable Firmware Compatibility CPU Family Firmware ® ® ZNEO , eZ80Acclaim! Installing the USB Smart Cable and Driver Before connecting the USB Smart Cable to your system, Windows loads the appropriate driver from the ZDS II installation director. You can download ZDS II software for a specific device family for free from Zilog Store.
  • Page 7 USB Smart Cable User Manual should appear in the list of returned items in your search; click this item to launch the Device Manager. 4. A selection labeled should appear in the list of hard- Other devices ware devices currently running in the Device Manager. Click the arrow to the left of to display these additional devices.
  • Page 8 USB Smart Cable User Manual 4. Select Browse my computer for driver software (advanced). 5. Browse to one of the following driver directories: 32-bit Vista systems: <ZDS II Installation Directory>\device drivers\USB\x32 <ZDS II Installation CD>\device drivers\USB\x32 64-bit Vista systems: <ZDS II Installation Directory>\device drivers\USB\x64 <ZDS II Installation CD>\device drivers\USB\x64 6.
  • Page 9: Connecting To The Target Board

    USB Smart Cable User Manual Connecting to the Target Board Important! Observe the following steps to complete the power-on sequence before connecting to the target board. 1. Connect the USB Smart Cable to the host PC. 2. Attach one end of the six-conductor ribbon cable to the Smart Cable six-pin DBG connector, as shown in Figure 1.
  • Page 10 USB Smart Cable User Manual To learn more about connecting the USB Smart Cable to your target board, refer to the eZ80Acclaim! Design for Debug Technical Note (TN0035). Disconnecting from the Target Board Observe the following steps to complete the power-down sequence before disconnecting from the target board.
  • Page 11: Troubleshooting Tips

    USB Smart Cable User Manual Troubleshooting Tips If a hardware failure is suspected, contact support.zilog.com for assis- tance. Before submitting a problem report to Zilog Customer Support, fol- low the instructions in this section. USB Smart Cable Not Recognized Disconnect all other USB devices (including your keyboard and mouse if you can use PS2 ports instead).
  • Page 12: Customer Support

    USB Smart Cable User Manual Customer Support To share comments, get your technical questions answered, or report issues you may be experiencing with our products, please visit Zilog’s Technical Support page at support.zilog.com. To learn more about this product, find additional documentation, or to discover other facets about Zilog product offerings, please visit the Zilog Knowledge Base...
