Soniclear VT1Q User Manual

Quad Voice Tracker User Guide
Noise Reducing Microphone for Meeting Recording
The Quad Acoustic Magic Voice Tracker kit makes it possible to record meetings in
very large rooms, with high levels of background noise, and audience participation.
The Quad Voice Tracker microphone system is designed to reduce noise using advanced
digital signal processing technology. This makes it possible to capture recordings of large
meetings with greater accuracy than with conventional microphones.
The Voice Tracker microphone incorporates "array microphone" computer technology. The
digital signal processing computer built into the unit instantly switches the microphone pickup
pattern, pointing it in the direction of each person speaking. This helps to reduce background
noise and room resonance.
In addition to pointing, the Voice Tracker uses digital signal noise reduction processing to
reduce background noises such as paper shuffling, air conditioner noise and audience noise.
The Voice Tracker microphone connects to the microphone input of the computer through the
included cables and audio interface device.
Components Included
• Voice Tracker I Microphone and Power Adapter (4)
• HumX Power Conditioner (1)
• 50' XLR Microphone Extension Cable (4)
• XLR Adapter Assembly - SES-AUD-RCA-XLR (4)
• RME Digiface USB Audio Interface with 8-channel digital microphone preamp (1)
Directions for Use
Microphone Placement
Voice Tracker microphones can pick up people speaking up to 20 feet away in a noisy room,
and even further in a quiet setting. Locate each Voice Tracker unit in the room close enough
to the meeting participants for reliable capture of their voices.
NOTE: Be sure to position the Voice Tracker away from sources of constant noise, such as a
laptop, video projector, or air conditioning unit.
The included power adapter must be plugged into standard 110 volt power outlets, using
extension cords, if required (not included).
SKU: VT1Q
