USER GUIDE

Smart Paddle Dimmer

THANK YOU

We appreciate the trust and conﬁdence you have placed in Commercial Electric

through the purchase of this Smart Dimmer. We strive to continually create quality

products designed to enhance your home. Visit us online to see our full line of

products available for your home improvement needs. Thank you for choosing

Commercial Electric!

Table of Contents

Need help?

Do you have a question about the HPDA110NWBP and is the answer not in the manual?

Questions and answers

Summary of Contents for Commercial Electric HPDA110NWBP

Page 1 Smart Paddle Dimmer THANK YOU We appreciate the trust and conﬁdence you have placed in Commercial Electric through the purchase of this Smart Dimmer. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Page 2: Table Of Contents
Table of Contents Safety Information .......... FCC Regulation ..........Wireless Protocol ..........6 Warranty ..............Package Contents .......... Installation ............. Operation ............... Speci cation ............14 Troubleshooting ..........15...
Page 3: Safety Information
Safety Information WARNING: • Not compatible with standard 3-way or 4-way. Do not exceed the load power rating limit of the device. Maximum total wattage rating: Up to 150 total watts for LED and CFL; 600W/120V for Incandescent/Halogen. • This product is to be installed or used in accordance with electrical codes and regulations.
Page 4: Fcc Regulation
Responsible Party Leedarson America, Inc. 300 Technology Court SE Suite 100; Smyrna, GA 30082 1-678-293-8382 Unique Identiﬁer: HPDA110NWBP (SKU # 1011 847 111) Contains FCC ID: 2AB2Q-LA02305 This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
Page 5 FCC Regulation (continued) This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
Page 6: Wireless Protocol
Wireless Protocol Apple and the Apple logos are trademarks of Apple, Inc., registered in the U.S., and other countries. App Store is a service mark of Apple Inc. Google and Google Play logo are trademarks of Google LLC. Warranty 1 YEAR LIMITED WARRANTY This product is guaranteed to be free of defects in materials and workmanship for 1 year from the date of purchase.
Page 7 HUBSPACE APP QUICK START GUIDE THANK YOU We appreciate the trust and conﬁdence you have placed in Commercial Electric through the purchase of this Smart Dimmer. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Page 8: Installation
Installation Install the dimmer in a single gang application. Turn power off at the circuit breaker or fuse for the dimmer that you are replacing. Remove the old dimmer by disconnecting all wires. Connect the new dimmer wires as follows. If the wires are different than the diagram shown, or you are uncomfortable with the installation, call a licensed electrician for help.
Page 9 Installation (continued) □ Loosen terminal screw and insert wire into through hole to make contact behind copper terminal. □ Tighten terminal screw to compress copper terminal onto wire. □ Double check and pull on wire to verify it is securely held in place. 120V POWER SUPPLY 120V POWER SUPPLY ROMEX(BOX TO LIGHT)
Page 10 Installation (continued) Turn power ON at the circuit breaker or fuse. Installation is complete. Install the dimmer in a multi-gang application. In multi-dimmer installations, the reduction of the dimmer’s capacity may be required. Refer to below chart for maximum load per dimmer. -10-...
Page 11: Operation
Installation (continued) Maximum Load Per Dimmer for Multi-gang Load Bulb Single Two-Gang Three-Gang LED/CFL 150W 150W 150W Incandescent/ 600W 400W 400W Halogen NOTE: □ No derating is required for LED or CFL bulb applications. Operation Download the Hubspace™ app from the App Store or the Google Play Store.
Page 12 Operation (continued) Tap the ‘+’ button in the upper-right corner on the app screen to add your dimmer. My Home NOTE: Bluetooth access is required for product setup. Android phones must also enable Location functions to allow for Bluetooth scanning. Scan the QR code on the dimmer or in the Quick Start Guide.
Page 13 Operation (continued) Using your Smart Dimmer □ To turn your dimmer on or off, tap the On/Off button on the Home Page. □ Tap the name of your Smart Dimmer on the Hubspace Home Page to display the control screen, then you can: Dim light from 1-100%.
Page 14: Specification
Operation (continued) Set up your Voice Assistant You can connect your smart dimmer to Google Home and Alexa from the Hubspace app. Or, you can sign in to Alexa app or Google Home and connect to your Hubspace products from there. Speciﬁcation Input 120VAC, 60Hz...
Page 15: Troubleshooting
Troubleshooting Problem Possible cause and action Dimmable function works only with dimmable bulbs. What products can be Maximum total wattage rating: controlled with the -Up to 150 total watts for LED and CFL Smart dimmer? -600W/120V for Incandescent/Halogen Circuit breaker or fuse has tripped. Light or LED indicator Load bulb is burned out.
Page 16 Troubleshooting (continued) Problem Solution I cannot nd the It is on the dimmer housing. A copy of the QR code QR code. is also included in your product’s documentation. The QR code has become Under the QR code are numbers. You can enter those in manually instead of scanning the code.
Page 17 Questions, problems, missing parts? Before returning to the store, call Hubspace Customer Service 8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday 1-877-592-5233 HOMEDEPOT.COM/Hubspace Retain this manual for future use.
