Wi-Fi DOOR/WINDOW SENSOR
2
OTA upgrade
Tamper protection
Item Code
Battery
AAA1.5V x 2
MS-DS101-WH
Installation
Material
Place
Plastic+PCB
Mount on door
24mm
USB Power Supply
Alexa Compatible
Standby
Protocol
current
≤45uA
IEEE 802.11b/g/n
Power
Source
Battery LR03*2
Dimensions in mm
16mm
DC
Color
3V
white
Wireless
Type
2.4GHz
Wi-Fi
Frequency
2.4GHz
69.5mm
14.8mm
page 1 of 6
Huem
Operating
Humidity
-10ºC~40ºC
20%~85%
Wireless
Communication
Range
method
50m
Wifi
Standby
IP rate
Time
IP22
1 year
40.5mm
16mm
Storage
Temperature
-10ºC~60ºC
Advertisement
Summary of Contents for huem MS-DS101-WH
- Page 1 USB Power Supply Alexa Compatible -10ºC~40ºC 20%~85% -10ºC~60ºC Standby Wireless Wireless Communication Item Code Battery Protocol current Type Range method AAA1.5V x 2 MS-DS101-WH ≤45uA IEEE 802.11b/g/n 2.4GHz Wifi Installation Power Wi-Fi Standby Material IP rate Place Source Frequency Time IP22 Plastic+PCB...
-
Page 2: How To Use
How to use Step 1 Push the mounting bracket upward and take out the bracket, then insert the battery Step 2 Put the battery into the battery bin and place it according to the graphics in the battery bin. After two batteries are loaded, the indicator lights are always on and then off. - Page 3 Register Step 4 If you already have an account, choose “Register with an existing account“ and go to the Login page. The system will automatically determine the current Country/Region you are in. Or you can Choose it yourself. Enter your Mobile number/E-mail and password. - Log in to a Third-party Social account. - If you download QQ on your phone, you can click on the QQ symbol in the Login page.
- Page 4 Step 5 With the card pick-up pin in the accessory package, hold the reset key for more than 5 seconds, and the indicator flashes into the automatic network connection mode. Enter the WiFi password according to the prompt, and click to confirm. 16:07 Add Device Connecting...
- Page 5 Step 6 In the automatic network connection mode, the indicator flashes quickly, holds the reset key for 5 seconds with the card pick-up pin, the indicator flashes slowly, and enters the manual network connection mode. APP chooses compatible mode. According to the prompt, enter "WiFi password" and click confirmation, then switch to the WIFI settings interface.
- Page 6 Step7 Network connection successfully, click on the door magnetic icon to enter the interface, open the door magnetic, APP will remind you the door is open, close the magnet door magnetic APP will remind you the door is closed. page 6 of 6...
