WALLYS DR5332 User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
1.IPQ5332 UI settings
2.DR5332 UART configuration
3.How to set up the card slot
DR5332
THIS DOCUMENT CONTAINS PROPRIETARY TECHNICAL INFORMATION, WHICH IS THE PROPERTY OF
THE WALLYSTECH AND SHALL NOT BE DISCLOSED TO OTHERS IN WHOLE OR IN PART, REPRODUCED,
COPIED, OR USED AS THE BASIS FOR DESIGN, MANUFACTURING, OR SALE OF APPARATUS WITHOUT
WRITTEN PERMISSION OF WALLYSTECH.

Advertisement

loading
Need help?

Need help?

Do you have a question about the DR5332 and is the answer not in the manual?

Questions and answers

Summary of Contents for WALLYS DR5332

  • Page 1 1.IPQ5332 UI settings 2.DR5332 UART configuration 3.How to set up the card slot DR5332 THIS DOCUMENT CONTAINS PROPRIETARY TECHNICAL INFORMATION, WHICH IS THE PROPERTY OF THE WALLYSTECH AND SHALL NOT BE DISCLOSED TO OTHERS IN WHOLE OR IN PART, REPRODUCED, COPIED, OR USED AS THE BASIS FOR DESIGN, MANUFACTURING, OR SALE OF APPARATUS WITHOUT WRITTEN PERMISSION OF WALLYSTECH.
  • Page 2 Wallys | User Manual | DR5332 IPQ5332 UI setting 1.Input the IP 192.168.1.1 and login 2.Input the username “admin” password “password” then press the button “Login” 3. Network setting • IP Setting: setting IP in the path "network->Interfaces->LAN- >IPV4 address"...

  • Page 3: Wireless Setting

    Wallys | User Manual | DR5332 IPQ5332 UI setting 4. Wireless setting Login the path network->Interfaces->WIFI, Then choose wifi 1,we select the red marked as example,click the button “ Edit ” www.wallystech.com...
  • Page 4 Wallys | User Manual | DR5332 IPQ5332 UI setting The detail information show in the picture as below: • Channel:for channel select; • Transmit Power:signal chain power setting; ESSID:for ID • Mode:it support 4 mode AP,AP(WDS),client,client(WDS) Wireless • Security: for Encryption setting...
  • Page 5 Wallys | User Manual | DR5332 IPQ5332 UI setting In advance setting you can select which chain do you need,which BW do you need and so on In the end, you need click the button “Save & Apply”, and wait for 2 minutes, then you can enjoy it.
  • Page 6 Wallys | User Manual | DR5332 IPQ5332 UI setting 5. Backup archive Login System->Backup/Flash Firmware; Then click the button “Generate archive” Then download the archive www.wallystech.com...
  • Page 7 Wallys | User Manual | DR5332 IPQ5332 UI setting 6.Update new image Login System->Backup/Flash Firmware; Then click the button “ flash image” Then click the button “Proceed” warning don't power off wait for about three minutes Then the system will reboot automatic.

  • Page 8: Wireless Encryption

    Wallys | User Manual | DR5332 IPQ5332 UI setting 7. wireless encryption Login System->Network/wifi/Edit->Choose 5G radio Country Coad choose “ US ” click the button“Wireless Security” Then choose “WPA3” and set password Notice:SAE/SAE PWE/SAE MFP click “ √ ” www.wallystech.com...
  • Page 9 Wallys | User Manual | DR5332 IPQ5332 UI setting 7. wireless encryption www.wallystech.com...
  • Page 10 Wallys | User Manual | DR5332 DR5332 UART configuration 1. Introduction The photo below shows how to use the Uart for DR5332 www.wallystech.com...
  • Page 11 Wallys | User Manual | DR5332 DR5332 UART configuration 2. Device connect Step 1:Connect the cable to the DR5332 As the picture as above,the sequence of the signal in the UART Connector:GND,TX,RX,VCC, And we need use GND connect black cable,TX connect to white cable,RX connect to Green cable VCC don't use.
  • Page 12 Wallys | User Manual | DR5332 DR5332 UART configuration 2. Device connect Step 3 Login with the software You can use putty,Xshell or some others,enjoy it. www.wallystech.com...
  • Page 13 Wallys | User Manual | DR5332 How to set up the card slot 4x4 single radio setenv machid 8050e01 setenv bootargs 'console=ttyMSM0,115200n8 cnss2.enable_qcn9224_support=1 cnss2.bdf_pci2=0x0002 cnss2.bdf_pci3=0x0004 cnss2.enable_mlo_support=0' saveenv 2x2 dual radio setenv machid 8050e01 setenv bootargs 'console=ttyMSM0,115200n8 cnss2.enable_qcn9224_support=1 cnss2.bdf_pci2=0x1006 cnss2.bdf_pci3=0x1003 cnss2.enable_mlo_support=0'...
  • Page 14 Wallys | User Manual | DR5332 You can configure the DR9274 card slot 0-1 as desired pcie 0 pcie 1 For example set one card if you want pcie 0 support DR9274-5G; you can under uboot enter cnss2.enable_qcn9224_support=1 cnss2.bdf_pci0=0x0002 cnss2.enable_mlo_support=0' than saveenv than reset.
  • Page 15 Wallys | User Manual | DR5332 You can configure the DR9274 card slot 0-1 as desired pcie 0 pcie 1 For example set one card if you want pcie 1 support DR9274-5G; you can under uboot enter cnss2.enable_qcn9224_support=1 cnss2.bdf_pci1=0x0002 cnss2.enable_mlo_support=0' than saveenv than reset.
  • Page 16 Wallys | User Manual | DR5332 You can configure the DR9274 card slot 0-1 as desired pcie 0 pcie 1 For example set two card if you want pcie 1 support DR9274-5G; pcie 0 support DR9274-6G; you can under uboot enter setenv bootargs 'console=ttyMSM0,115200n8 cnss2.enable_qcn9224_support=1...
  • Page 17 DR5332 THIS DOCUMENT CONTAINS PROPRIETARY TECHNICAL INFORMATION, WHICH IS THE PROPERTY OF THE WALLYSTECH AND SHALL NOT BE DISCLOSED TO OTHERS IN WHOLE OR IN PART, REPRODUCED, COPIED, OR USED AS THE BASIS FOR DESIGN, MANUFACTURING, OR SALE OF APPARATUS WITHOUT...
