Summary of Contents for Mooer AIR P05

  • Page 1 Owner's Manual...
  • Page 2 CONTENT PRECAUTIONS ..........................1 - 2 PANEL LAYOUT ........................... 3 - 4 QUICK START ..........................5 - 6 SPECIFICATIONS ..........................7...

  • Page 3: Precautions

    PRECAUTIONS Please read carefully before use. Warning To reduce the risk of fire and electric shock, non-professionals should not disassemble this product, nor should it be exposed to rain or placed in a humid environment for a long time. Power Supply This product is powered by a built-in 400 mAh battery.
  • Page 4 Electrical interference This product uses a 2.4GHz wireless RF scheme and may experience interference in environments close to wireless RF signals (such as wireless routers or other wireless transmission devices). Cleaning Please clean the unit with a dry, soft cloth. If necessary, a slightly damp cloth may be used. Do not use abrasive cleaning powders, alcohol, paint thinner, wax, solvents, cleaners, or chemical agents to soak the cloth.

  • Page 5: Panel Layout

    PANEL LAYOUT TRANSMITTER Instrument Plugin Jack Power Switch Channel Indicator RECEIVER Effect/Amplifier Plugin Jack Power Switch Channel Indicator...
  • Page 6 USB-C Charging Port Battery Indicator...

  • Page 7: Quick Start

    QUICK START Device Connection AIR P05 is divided into TRANSMITTER and RECEIVER. The TRANSMITTER connects to the output of musical instruments/effects units; the RECEIVER connects to the input of effects units/amplifier. Power On/Off Press and hold the switch button; the light on the button indicates successful power on; when the light goes out, the device is turned off.
  • Page 8 AIR P05 has a built-in battery. After powering on, please check the battery indicator light next to the USB port. When the light turns red, AIR P05's battery is low; charge it promptly to avoid affecting later use. Please use the USB charging cable provided with the product. During charging, the indicator light will turn red and blink;...

  • Page 9: Specifications

    SPECIFICATIONS  Effective Transmission Distance: 20 meters (outdoors)  Latency: About 7 milliseconds  Frequency Response: 20-20 kHz, +1 dB/-3dB  Total Harmonic Distortion: <0.05% (1 kHz@-10dbFS)  Input Dynamic Range: >95 dB  Signal Frequency Band: 2.4 GHz ISM Worldwide ...
