Summary of Contents for Zenitel VAF-2
- Page 1 VAF-2 Console Mount FXS Station Quick Guide A100K12283...
- Page 2 Overview This document serves as a quick guide for theVAF-2 Console Mount FXS Station Item Number: 1022100100. VAF-2 A100K12283...
-
Page 3: Item Description
Cable clamp Flash time selector K2 Handset contact Mounting Cut out 140 x 250mm in console and mount the VAF-2 with four M4 counter sunk screws according to the cut out view in image below. SIDE VIEW REAR VIEW CUT OUT VIEW... -
Page 4: Connecting The Terminals
1. Thread the cable (s) through the cable clamp, and tighten with the two screws. 2. Connect the telephone line, twisted cable and 24 VDC (for back light only) to the terminal block. 3. “Relay contact Pot.Free” = Optional for extra signal device (Current limit 150mA) VAF-2 A100K12283... -
Page 5: Further Information
Timing Pin 3 Pin 4 30ms Pulse Ringer frequency HIGH 60ms DTMF Ringer frequency LOW 100ms 150ms Further Information Go to https://www.zenitel.com/product/vaf-2-fxs-station or scan the QR-code below for more instructions on how to set up and configure theVAF-2. VAF-2 A100K12283... - Page 6 A100K12283 Zenitel and its subsidiaries assume no responsibility for any errors that may appear in this publication, or for damages arising from the information therein. Zenitel, Vingtor-Stentofon and Phontech products are developed and marketed by Zenitel. The company’ s Quality Assurance System is certified to meet the requirements in NS-EN ISO 9001.
