Summary of Contents for LEGRAND Raritan T1700G2-LED
- Page 1 T1700G2-LED User Guide Copyright © 2024 Raritan T1700G2-LED-UG-1A-v1.0.0-E September 2024...
-
Page 2: Fcc Information
This document contains proprietary information that is protected by copyright. All rights reserved. No part of this document may be photocopied, reproduced, or translated into another language without the express prior written consent of Raritan, Inc. © Copyright 2024 Raritan, Inc. All third-party software and hardware mentioned in this document are registered trademarks or trademarks of and are the property of their respective holders. -
Page 3: Table Of Contents
Contents What's New in the T1700G2-LED User Guide Rackmount Procedure Introduction Overview................. 9 Features. -
Page 4: What's New In The T1700G2-Led User Guide
What's New in the T1700G2-LED User Guide • • Support digital video interfaces: HDMI/DP/DVI-I. • • 2 x USB3.0 Type-A port on front panel and Type-B on rear panel. • • Improve video quality and performance for digital video devices. •... -
Page 5: In This Chapter
Read all these instructions carefully before you use the device. Save this guide for future reference. In This Chapter What the Warranty Does Not Cover........5 Safety Instructions. - Page 6 • • Keep all liquids away from the equipment to minimize the risk of accidental spillage. Liquid spilled on to the power supply or on other hardware may cause damage, fire or electrical shock. • • Only qualified service personnel should open the chassis. Opening it yourself could irreparably damage the equipment and invalidate its warranty.
-
Page 7: Rackmount Procedure
Rackmount Procedure 1. Adjust the length of both brackets to match the mounting depth of your rack. * Adjustable depth from 523 to 908 mm 2. Fasten the brackets to the rack pillars securely with the screws and cage nuts. 3. - Page 8 4. Fasten the LCD console drawer to the rack pillars by using screws.
-
Page 9: Introduction
Introduction In This Chapter Overview............9 Features. -
Page 10: Package Content
• • Supports up to 1920x1080@60Hz, and 1080p video resolutions • • Built in DVI-I, HDMI and DisplayPort interfaces • • Two front USB 3.0 ports • • USB console • • Embedded 12V, 5.42A power supply • • Supports rack cabinet depth of 52.3 to 90.8 cm (20.5 to 35.8 inch) with adjustable mountable brackets •... -
Page 11: Resolution Support
Item Description Connectors front-of-the-rack • • 2x USB 3.0 Type A Female rear-of-the-rack • • 1x Power Socket • • 1x USB 3.0 Type B Female • • 1x DVI-I • • 1x HDMI • • 1x DisplayPort • • Input: Auto-sensing 80 to 264VAC, MAX 50 / 60Hz Power Supply •... -
Page 12: Structure Diagram
S/N Pixel Format Refresh Rate Horizontal Frequency Pixel Frequency H/V sync Polarity Remark 1024 x 768 50 Hz 39.7 KHz 52.0 MHZ UEFI/BIOS 1024 x 768 60.0 HZ 48.4 KHz 65.000 MHz VESA 1024 x 768 70.1 HZ 56.5 KHz 75.000 MHz VESA 1024 x 768... - Page 13 Component Description LCD display Display the OSD and the source devices' video output. OSD buttons, power LCD power indicator lamp: The indicator is lit when the LCD power button is button and indicator turned on. lamp LCD power button: Turn on or off the power supply to the LCD display. (Please see Chapter 4 for OSD buttons: Display and operate the OSD menu, which adjusts the video or detail settings)
- Page 14 Open/ Close the LCD console drawer. Lock Lock or unlock the LCD console drawer when it is closed. Rear View Component Description Grounding Terminal The grounding wire (used to ground the unit) attaches here. Power Socket This is a standard 3 prong AC power socket. The power cord from an AC source plugs in here.
-
Page 16: Using The Console Drawer
Using the Console Drawer After finishing the rack mounting, you can start to use the console drawer. Note: Do not place any object or lean on the console drawer when it is pulled out. This may cause personal injury and/or property damage. Do not apply force to the monitor screen or scratch it. -
Page 17: Closing The Console Drawer
3. Flip up the console drawer. Closing the Console Drawer 1. Fold down the console drawer. 2. Push both latches with your index fingers in the direction as indicated before sliding the console drawer into the rack. - Page 18 3. Keep pushing the latches and slide the console drawer in evenly until the device is back into the rack completely. Warning: • • Keep your hands clear when closing the drawer. • • Use caution when pressing the device rail release latches and sliding a device into or out of a rack; the slide rails can pinch your fingers.
-
Page 19: Connecting A Server Or Kvm Switch
Connecting a Server or KVM Switch Follow the installation drawings and instructions below for standard connections. After the installation is completed, the LCD console drawer can be powered on. Then power on connected the equipment. Note:Please pay attention to the grounding of the equipment. You have to choose the same type of video interface and cable on the local console and the server console to connect the equipment, such as a server, monitor, KVM switch, and KVM extender. - Page 20 Connecting a Server USB 3.0 Type A Male to Type B Male USB cable DVI-I, HDMI or DisplayPort cable Connecting a KVM Switch USB 3.0 Type A Male to Type B Male USB cable DVI-I, HDMI or DisplayPort cable...
-
Page 21: Connecting An External Usb Device
Connecting an External USB Device Connect any USB device to the front panel USB-A port of the LCD console drawer. Note: The server should detect the connection of the external USB device. If necessary, install the driver for the detected USB device. Grounding Terminal To prevent damage to your installation it is important that all devices are properly grounded. -
Page 22: Adjusting The Video Settings
Note: Once the relevant signal cables and power cords are properly connected, you can power on the computer and this LCD console to begin using them. Adjusting the Video Settings The on screen display (OSD) menu controls the video quality. Use the buttons on the LCD panel to fine- tune the LCD display settings. -
Page 23: On-Screen Display Interface
On-Screen Display Interface In This Chapter OSD Buttons............23 OSD Menus. -
Page 24: Osd Menus
MENU This button has two functions: When OSD is not displayed, pressing this button triggers the OSD menu. When the OSD is displayed, this button functions as the Back key for going back to the last action. SELECT This button has two functions: When OSD is not displayed, this button is used to select the video input source (VGA, DVI, HDMI or DisplayPort). - Page 25 No. Setting Explanation Brightness Make the screen image brighter or darker. Contrast Adjust the difference between the background black level and the foreground white level. Sharpness Fine tune the sharpness of the screen image. Aspect Ratio Set the Aspect Ratio Ultra Vivid On/off the Ultra Vivid function.
- Page 26 Setting Explanation Color Effect Choose the Color Effect. Saturation Adjusts the Saturation setting. Gamma On/off the Gamma function. Temperature Select the screen color temperatures. Red/Green/Blue Adjust red, green, and blue colors respectively. ▶ To set Input source: No. Setting Explanation...
- Page 27 Input Select the video input source – VGA, DVI, DislayPort or HDMI. ▶ To set OSD: No. Setting Explanation Language Selects the language that the OSD displays its menus in. (only available in English) Menu Time Set the time duration in seconds for which the OSD remains visible after the last button is pressed.
- Page 28 *The adjustments are only for VGA signal input. No. Setting Explanation Auto Adjust Optimize the visual settings. Auto Color Perform analog auto color setup. H Position Move the screen image left or right. V Position Move the screen image up or down. Clock Adjust the clock to synchronize the sampling clock of the display with the pixel clock of the connected equipment.
-
Page 29: Disclaimer
Display the current video input information on the screen. Disclaimer Information in this document is subject to change without notice. The manufacturer does not make any representations or warranties (implied or otherwise) regarding the accuracy and completeness of this document and shall in no event be liable for any loss of profit or any other commercial damage, including but not limited to special, incidental, consequential, or other damages. - Page 30 • • Reorient or relocate the receiving antenna. • • Increase the separation between the device and receiver. • • Connect the computer into an outlet on a circuit different from that to which the receiver is connected. • • Consult the dealer or an experienced radio/TV technician for help.
-
Page 31: Index
Index Adjusting the Video Settings 22 Safety Instructions 5 Specifications 10 Structure Diagram 12 Closing the Console Drawer 17 Connecting a Server or KVM Switch 19 Connecting an External USB Device 21 Using the Console Drawer 16 Connecting the Power Cord 21 What the Warranty Does Not Cover 5 Disclaimer 29 What's New in the T1700G2-LED User Guide 4...
