Network Services Processor
Installation Manual
0450-0439
Rev. C

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NSP and is the answer not in the manual?

Questions and answers

Summary of Contents for ESI NSP

  • Page 1 Network Services Processor Installation Manual 0450-0439 Rev. C...

  • Page 2: Table Of Contents

    Outlook are registered trademarks of Microsoft Corporation. Information contained herein is subject to change without notice. ESI products are protected by U.S. Patents No. 6,067,349 and 6,252,944, and others pending. ESI is an ISO 9001:2000-certified company. Visit ESI on the Web at www.esi-estech.com.

  • Page 3: Overview

    All NSP models support maintenance and programming via TCP/IP with Esi-Access version 2.6.1 or higher. If you’re at the customer site and wish to connect Esi-Access to an E-Class system through the NSP: 1. At the Site Connection screen in Esi-Access, select the communication type Network.

  • Page 4: Unified Messaging

    System hardware The NSP circuit card is about the size of a credit card. A mounting bracket is included with the NSP card for mounting to any E-Class system cabinet. An 8-pin modular jack provides the 10/100Base-T connection to the IP network.

  • Page 5: Installation

    The NSP requires only two screws to mount in the E-Class cabinet. We also supply two cables for connection to the E-Class main board: The gray, flat cable is the NSP data cable; the four-wire “Y” cable is the NSP power cable.

  • Page 6: Ip E-Class

    5. Remove the LNC by disconnecting the cables and removing the screws. Place the card to the side. 6. Remove the cover plate from the NSP mount opening, which is on the upper-right corner of the front panel. 7. Follow the instructions in “Installing the NSP” (page 6).
  • Page 7 Note: From the front of the IP 40e, the LNC is the top card on the right. 4. Remove the cover plate from the NSP mount opening, which on the upper-right corner of the front panel. 5. Follow the instructions in “Installing the NSP,” page 6.

  • Page 8: Installing The Nsp

    Figure 2 4. Connect the other end of the gray NSP data cable to J6 of the NSP. The red wire must face toward the eight-pin Ethernet connector.

  • Page 9: Programming The Nsp

    Range: 0.0.0.0 through 255.255.255.252 The subnet mask is used to define the network to which the NSP is connected. If using the standard ESI IP addressing scheme, set the subnet mask to 255.255.255.0. Otherwise, consult with the site network administrator to obtain the correct subnet mask.
  • Page 10 Appendix A (page 11) for instructions about how to determine the gateway address. Note: The gateway address must always be on the same network as the NSP; i.e. if using the standard ESI IP address scheme, the gateway router’s LAN (or inside) address must be in the range of 192.168.100.1 to 192.168.100.254.

  • Page 11: Tcp/Udp Service Port Numbers

    TCP/UDP service port numbers The NSP TCP/UDP port numbers are included within the range specified by the prefix assigned in program Function 821. For example, if the UDP port prefix entered in Function 821 were 59, the port number for connecting via Esi-Access would be 59002.

  • Page 12: Esi-Mail Programming

    Function 824. • NSP Port Number — The IP services port that the NSP uses to communicate with Esi-Mail. The first two digits must match the UDP Port Number prefix assigned in Function 821 (59 is the default).

  • Page 13: Appendix A: Checking Existing Address Information

    NSP Installation Manual Appendix A: Checking existing address information Important: The procedure shown below is for use within Windows 95 and 98. However, if you’re using Windows NT, Windows 2000 or Windows XP: 1. Click on the Windows Start button and select Run. The Run window will appear.
  • Page 14 In either case, you usually will be able to pick a very high IP address in the range, and use that as the NSP’s IP address. To ensure that the IP address you choose is not in use by another host on the network, PING the IP address you choose for the NSP.

  • Page 15: Appendix B: Using Ping To Verify The Nsp Connection

    This Appendix provides a quick method for verifying the NSP connection. If you find a problem, you must correct it before installing Esi-Mail. On a user PC on the customer’s network, you can quickly verify the IP path to the NSP by using the ®...
  • Page 16 NSP Installation Manual Another possible display indicating a problem is shown here: Pinging 192.168.100.2 with 32 bytes of data: Reply from 206.205.233.145: TTL expired in transit. Reply from 206.205.233.145: TTL expired in transit. Reply from 206.205.233.145: TTL expired in transit.

  • Page 17: Appendix C: Using Tracert

    NSP Installation Manual Appendix C: Using TRACERT The MS-DOS command TRACERT (short for trace route) can be used to determine the location of the problem. At the DOS prompt type tracert followed by the address of a known Internet web site, such as www.ietf.org.

  • Page 18: Appendix D: Discovering The Nsp Gateway Address And Public Ip Address

    NSP. To find the IP address of the gateway the NSP will use, you can run the TRACERT command (for more information on using this command, see Appendix A, page 11) on one of the PCs that is on the main office network and has access through the router.
  • Page 19 N O T E S...
  • Page 20 Visit us on the Web at www.esi-estech.com.

This manual is also suitable for:

Nsp-0Nsp-5Nsp-25Nsp-u
