- Page 1 Congratulations on the purchase of your n+ Mercedes AMG-PETRONAS Formula One Team Track eBike...
-
Page 2: Table Of Contents
Table of contents Your Track eBike Helmet lights Basic riding technique Safety and Disclaimer Frame size, saddle height adjustment Pedal assistance Legal Bed in your disc brakes Safe riding Before every ride Maximum system weight Range Different riding conditions Seat tube battery Liability and waivers Trailers and carriers Maintaining your Track eBike Assembly Servicing Storing your eBike How to ride your Track eBike Tires Your Track eBike Remove your tire... -
Page 3: Your Track Ebike
Your n+ Mercedes-AMG PETRONAS Formula One Team Track eBike Your Track eBike is the sleekest commuter eBike on the market with an aluminium alloy frame in the iconic Mercedes-AMG PETRONAS Formula One Team matte black livery with PETRONAS green highlights. A custom one-piece handlebar features a 5.5” colour custom display to match your Mercedes-AMG dashboard and keep you updated on all the details of your ride. The Track features a downtube integrated battery, 27.5” urban tires and front and rear lights for safety. -
Page 4: 2/ Safety And Disclaimer
2/ Safetly and Disclaimer Safety and Disclaimer Legal The word ! WARNING indicates a potentially hazardous situation that, if not (1) “Electric bicycle” and “eBike” shall mean a bicycle equipped with fully avoided, could result in serious injury or death. operable pedals, a saddle or seat for the rider, and an electric motor of less The word ! CAUTION indicates a potentially hazardous situation or unsafe than 750 watts that meets the requirements of one of the following three practice that, if not avoided, could result in minor or moderate injury, serious classes: damage to your eBike and the voiding of your warranty. (a) “Class 1 electric bicycle” shall mean an electric bicycle equipped with a motor that provides assistance only when the rider is pedaling, and that Maximum system weight (bike, accessories, and rider): 130kg/286Lbs ceases to provide assistance when the bicycle reaches the speed of 20 Adhere to local regulations regarding children using this product. Adult miles per hour. supervision is required. No person under the age of sixteen (16) may operate a class 3 electric bicycle. A person under the age of sixteen (16) may ride as (b) “Class 2 electric bicycle” shall mean an electric bicycle equipped with a motor that may be used exclusively to propel the bicycle, and that is not a passenger on a class 3 electric bicycle that is designed to accommodate passengers. capable of providing assistance when the bicycle reaches the speed of 20 miles per hour. Adhere to local regulations regarding eBike use. It is the customer’s sole (c) “Class 3 electric bicycle” shall mean an electric bicycle equipped with responsibility to ensure that the eBike is at all times used in accordance with all relevant laws, regulations and rules (as updated or amended from time to a motor that provides assistance only when the rider is pedaling, and that time) which may vary depending on the location where the eBike is used. ... -
Page 5: Different Riding Conditions
2/ Safetly and Disclaimer Safety and Disclaimer Different riding conditions A bicycle can be dangerous, especially if you try to ride beyond the limits of your ability. Know your skill level and don’t ride beyond it. Take extra precautions when you ride in wet or snowy weather, because the grip of your tires is greatly reduced. Braking distances increase in wet weather. Apply your brakes earlier and use extra caution than when riding in dry conditions. Liability and waivers It’s always important to ride safely, no matter your skill or experience level. Helmet Always wear a fully certified and approved helmet (as per local regulations) when riding your eBike. Be sure to affix the helmet properly using the chin strap and follow the manufacturer’s instructions for proper use. All operators and passengers of class 3 electric bicycles shall wear a properly fitted and fastened bicycle helmet that meets the standards provided by either the United States Consumer Product Safety Commission or the American Society for Testing and Materials, or standards subsequently established by those entities. Other safety equipment It’s a good idea to wear appropriate clothing when riding your eBike. Avoid wearing loose clothing or accessories that may get caught in your wheels or other moving components. It’s also a good idea to wear bright, fluorescent and reflective clothing to increase visibility to other trail and road users. Ensure you use your integrated front light and provided rear light on all rides. Make sure that your reflectors are clean and correctly positioned. Trailers and carriers Trailers, bicycle passenger seats and carriers are not permitted on the Mercedes Track Edition eBike. The manufacturer will not assume liability or provide guarantee for the use of trailers, child seats and luggage carriers. -
Page 6: 3/ Assembly
3/ Assembly Assembly Your Mercedes Track Edition eBike has been fully assembled and tested at the factory. The bicycle is fully functional without any further adjustments being made once the assembly steps explained below have been completed. After carrying out assembly work, always do a test ride in an unfrequented place or on a quiet road. Before your first ride, carry out the checks described in the section “Know before you ride”. On receiving your Mercedes Track Edition eBike, carefully open the cardboard outer and inner packaging using a box cutter or knife with a very short blade. Never use any kind of knife on the bike itself. The packaging includes your partially-assembled Mercedes Track Edition eBike, with the rear wheel already installed. The front wheel is included in the product packaging and must be installed. In addition, the packaging includes basic tools for use during assembly. Correct assembly is essential for a safe and enjoyable riding experience. Be sure to carefully follow all directions in this manual. If you are unsure or have concerns, please consult you local bicycle dealer, repair shop, or contact our support team for further assistance. Tools Required: • Provided allen key multi-tool. • Torque wrench. - Page 7 3/ Assembly Assembly Headset adjustment / Handlebar installation • I nstall the headset top cap and bolt. • S lide the axle into the hub from the right side There should not be more than 5mm of spacers of the bike (opposite the brake caliper). Tighten above the stem as the stem requires full support from • T ighten the top cap to 2Nm, while ensuring that the axle. the expander plug inside the fork to function safely. the stem remains straight. • C heck for alignment of disc rotor and disc brake • N ext, tighten both handlebar stem bolts to 6Nm Your Mercedes Track Edition eBike features an pads by slowly spinning the front wheel by hand (incremental tightening for top and bottom bolts). integrated one-piece handlebar and stem. Handlebar whilst bike remains upside down (*note - do not height can be increased or decreased with install or • T ighten both handlebar stem bolts to 8N. engage brakes whilst bike is upside down to avoid removal of spacers provided. Minimum fork steerer • I nstall the handlebar to the steerer tube by sliding any risk of hydraulic brake malfunction).
- Page 8 3/ Assembly Assembly Seat post installation Charging your bike • L oosen the seat post collar bolt. • O nly charge your down tube battery system using the provided battery charger or certified • I nstall a thin covering of provided carbon replacement purchased from Mercedes eBikes. assembly paste to the seat post. • ! WARNING: Using a third-party battery charger • I nstall the seat post to seat tube and fit to risks the life of the battery and presents a preferred height (ensure maximum and minimum potential fire hazard. seat post insertion points on the rear of the seat post are not exceeded). • T o charge your bike, connect the provided battery charger to the wall socket (ensuring wall socket • T ighten the seat post collar bolt to 6Nm. is switched off). Connect the charger plug to the • Tighten the seat post collar bolt to 8Nm. charging port, located at the internal face of the seat tube, just above the bottom bracket. ...
- Page 9 3/ Assembly Assembly Battery warnings Keep your battery away from fire and heat. ! WARNING: Risk of explosion! Keep the rechargeable battery and the charger out of the reach of children. This equipment is not intended to be used at ambient temperatures less than 0°C (32°F) and greater than 40°C (104°F). Never charge the battery when ambient temperatures are outside this range. If the Mercedes Track Edition eBike is not used for a long period (one month or more) the battery pack is best stored separate from the bike, with between 40- 60% charge level.
-
Page 10: 4/ How To Ride Your Track Ebike
4/ How to ride How to ride your Track eBike 1. Saddle/Seat. 2. Stem Cap. 3. Handlebar assembly. 4. Head Tube. 5. Disc Rotor. 6. Brake Caliper. 7. Rear Hub Motor. 8. Bottom Bracket. 9. Seatpost. 10. Down Tube Battery. 11. Charging Port. -
Page 11: Know Before You Ride
4/ How to ride How to ride your Track eBike Know before you ride Hand brakes The rear derailleur moves your chain from one gear to another. You shift gears by pressing the The rechargeable battery (or batteries if you have The front brake provides more stopping power handlebar mounted shifter which controls the purchased the optional seat post battery) of your than the rear brake, so do not use it too forcefully derailleur. eBike must be charged before you set off for the or too abruptly. Gradually add pressure to both first time. brakes until you slow to the desired speed or stop. Shift gears only when the pedals and chain are If you must stop quickly, shift your weight back as moving forward. Before you set off, check that your battery is fully you apply the brakes to keep the rear wheel on the charged and is properly mounted. Refer to Shimano user manual for further ground. information. Turning and handling ! WARNING: Brake force applied to the front wheel Riding spares Be careful of toe overlap when turning the suddenly or too fully could lift the rear wheel off handlebar at low speeds. Do not pedal when riding... -
Page 12: Using The Display
4/ How to ride How to ride your Track eBike Using the display Menu operation When the bike is stationary, hold the “i” button on the Your Mercedes eBike is equipped with a custom integrated handlebar display. To switch on the display, handlebar mounted control switch for two seconds to enter the user menu interface screen. To change menus, hold the power button at the base of the display for short press the “+” or “-“ buttons on the control switch. two seconds. To edit an interface setting, select the setting using the The dashboard screen offers speed, power assist power button on the display. Short press the “+” or “-“ setting and power applied. To switch to view a different buttons on the control switch to modify selection. Short data display, short press the power button. press the power button on display to confirm setting change. Long press the “i” button on handlebar control switch for two seconds to exit user menu interface. -
Page 13: Unit1 Helmet Pairing
4/ How to ride How to ride your Track eBike Unit1 helmet pairing Your Mercedes eBike is shipped complete with a custom Unit1 Faro helmet. To pair your helmet with your eBike, select the helmet settings page from the user menu interface. Select “Add New Helmet”. This will enable Bluetooth connectivity and search for nearby devices. Select the Unit1 helmet using the display power button to confirm. The Smart Helmet is customizable using the associated smart phone application. Download the Smart Helmet app here: Android: Google Play Store > U1FARO iOS: App Store > U1FARO or scan the QR code... -
Page 14: How To Wear Your Smart Helmet
4/ How to ride How To Wear Your Smart Helmet How to wear your smart helmet To lock the magnetic buckle bring the two parts To tighten or loosen the fitting system, dial to fit the together until they snap. To unlock them, slide them circumference of your head as required. A correctly fitted helmet should sit comfortably on sideways as shown below. your head without pressing or chafing and should not move forward to obscure your vision or rearward to expose your forehead. Please make sure that the helmet is positioned in the right way. Be sure to position the buckle under the chain and back against the throat. The straps should fit comfortably around your ears. Test these adjustments before every ride. -
Page 15: Menu Functions
4/ How to ride How to ride your Track eBike Menu functions Clear trip Backlight brightness setting Automatic headlight Trip mileage, trip total time, maximum speed, Screen brightness can be manually adjusted Auto headlight mode can be set. When set to ON, average speed, total calories can be cleared. or set to automatic which will adjust screen it will turn on or turn off headlight automatically brightness according to the ambient light. according to the ambient light and set OFF will turn off auto headlight function. Switch display unit Automatic power off time Switch between metric or imperial Display automatic power off time can be display units. predetermined. - Page 16 4/ How to ride How to ride your Track eBike Menu functions Set time Set password System information The display time can be set. Default modified Display four-digit passcode can be set. Current system information. option is hour after entering the setting. Setting order is hours / minutes.
-
Page 17: Turning Your Ebike On And Off
4/ How to ride How to ride your Track eBike Turning your eBike on and off Helmet lights Ensure the fully charged battery is locked into place. When connected to your Mercedes eBike, the Unit1 Faro helmet allows brake light and indicator light illumination. Brake lights automatically illuminate when the Tektro brake system is engaged. Press and hold “power” for two seconds to turn on The indicator lights on your Unit1 Faro helmet are controlled via the handlebar-mounted control your display. switch. To switch on the indicator, choose either right-hand side or left-hand side. An indicator signal will illuminate on the handlebar display. To turn off the indicator signal, select the indicator Switching Power Assist (PAS) levels button on handlebar-mounted control switch again. Using the handlebar control switch, short press the “+” button to increase the assist level; short press the “-” button to decrease the assist level. Lights Auto headlight mode can be set. When set to ON, it will turn on or turn off the headlight automatically according to the ambient light and set OFF will turn off auto headlight function. Light settings are manually controllable (sequentially) via handlebar control switch. Single press the control light switch to cycle between low and high beam settings. -
Page 18: Basic Riding Technique
4/ How to ride How to ride your Track eBike Basic riding technique assist levels as you become accustomed to the which you can just reach the pedal in its lowest power application. Practice typical riding actions position (crank arms positioned vertically) whilst Your bike is designed to be used like a conventional (starting off, turning the bike, stopping the bike) to seated on the saddle. Also check that when seated bicycle. When power assist is switched on, your become accustomed to the different handling from on the saddle your toes can just reach to the ground. eBike will accommodate strain on the pedals to that of a conventional bicycle. To avoid damage to the seat post or bike frame, provide power assistance. do not position the saddle beyond the minimum Frame size, saddle height adjustment The functions of your eBike are operated with the insertion line on the seat post. Riding with too big a buttons of the control switch on the handlebar. Prior to riding your eBike for the first time, you frame can cause discomfort and injuries. should take care to adjust and personalize your Front light control and power assist levels are position on the bike. Stand over the top tube of controlled via the handlebar control switch. your eBike and confirm there is sufficient clearance Set off for your first ride in the lowest power assist between the top tube and your crotch (at least one setting (“Comfort”). Gradually increase power... -
Page 19: Pedal Assistance
4/ How to ride How to ride your Track eBike Pedal assistance Do not step on the pedals before being fully seated which could lead to serious injury or death. If you are on the bike. If any of the power assistance modes unfamiliar with disc brakes, you should have the bed- When power assistance is engaged, the rear hub are engaged, pressure on one pedal will engage the in process performed by your bike shop. motor will automatically apply power during pedaling. mid drive motor and could cause an accident. Always Sensors within the motor measure your pedaling and 1. O n a flat surface, while sitting on the have the brakes ready to engage when you first set control the automated power assistance according to saddle, accelerate the bike to a moderate speed. off with power assist levels switched on. the power assist setting chosen. The level of power 2. T hen firmly apply the brakes until you are supplied to the drive train depends on power assist Due to the increased power through the drive train, at walking speed. Repeat approximately setting chosen, speed and amount of force applied rear tire traction may be marginally reduced. Keep twenty times. to the pedals. this in mind when riding in adverse conditions (for 3. A ccelerate the bike to a faster speed, then firmly example wet road surfaces, snow or gravel). Always Power assistance switches off when applicable apply the brakes until you are at walking speed. -
Page 20: Before Every Ride
4/ How to ride How to ride your Track eBike Before every ride During production, your bike was quality checked repeatedly. Regardless, be sure to complete the following precautionary safety checks before every ride 1. Check the handlebar 2. Check the wheels 3. Check electrical parts • C heck that the stem is aligned with the • C heck that the thru-axles for both front and rear • C heck that the electrical connections are secure front wheel. wheel are properly installed (threads aligned (rechargeable downtube battery, control switch correctly) and tightened to the correct torque. on the handlebar). • C heck handlebar grips are properly installed and are in good condition (no cuts, tears or wornout • M ake sure that both tires are in good condition • I s the battery fully charged? Remember to fully... - Page 21 4/ How to ride How to ride your Track eBike 4. Test the brakes 6. Bounce test 8. Check pedals • T est the brakes while standing by firmly pulling • T est all componentry and accessories are • C heck that your pedals are correctly attached the brake levers towards the handlebar. You firmly fastened to the bike. Complete a small to the crank arms, spin freely and are free of should feel resistance before the lever touches bounce test, bouncing your bike tires on the any debris that might interfere with the pedal your handlebar. Ensure that the lever does not ground from a small height (10cm above ground system.
-
Page 22: Range
4/ How to ride How to ride your Track eBike Range Seat tube battery The range of your eBike is dependent on a range of To extend your battery range, it is recommended An additional range extending seat tube battery can that low or zero power assistance is applied factors: road or trail condition, weather, weight of be purchased from our online store. Installation of when descending or riding on flat terrain and that the rider, pedal force, power assist settings chosen, the seat tube battery will increase the total battery maximum power assistance is applied only when frequent stops, topography and tire pressure. capacity by 180Wh (250W system) or 240Wh (750W topography or weather requires. system) respectively. The battery charge level can be determined from the handlebar display dashboard page (shown right hand You can take a number of precautions to help extend Accessories: Seat Tube Battery side). battery range: Pay close attention to the battery charge indication 1. C heck tire pressure regularly (before each ride). on screen throughout your ride, ensuring that you will have sufficient battery charge to complete your 2. C hanging gears as appropriate to improve drive journey with the necessary or required assistance. -
Page 23: Maintaining Your Track Ebike
5/ Maintaining your Track eBike Maintaining your Track eBike Tires Servicing Checking your tires and ensuring correct tire Special tools and skills are necessary for servicing Your eBike is equipped with a Presta valve tube. some aspects of your eBike. If a repair or adjustment pressure will help ensure safe and comfortable riding. With a Presta valve, you must loosen the top valve two is not specifically listed in this manual or you require Using a tire pressure gauge or a pump equipped with turns before trying to inflate the tire. Do not over-inflate assistance, please contact Support or get in contact a gauge, inflate your tires to the recommended tire your tires. If your tire is over the recommended range, pressure. with your local bike shop. release air and recheck the pressure. Use a hand pump to inflate your tires to the air Storing your eBike pressure recommended on the sidewall of the tire or Do not leave your eBike unattended in public places. to the pressure recommended for the rim, whichever Whilst your display is equipped with password is lower. control, your bike can still be ridden manually. Ensure your bike is always secured and parked in a safe, dry Make sure your pump is suitable for your valve: place away from the elements where possible. Presta, Schrader, or Dunlop/Woods. -
Page 24: Remove Your Tire
5/ Maintaining your Track eBike Maintaining your Track eBike Remove your tire Replace your tire Cleaning 1. D eflate the inner tube (follow steps above to 1. P lace a new, slightly inflated inner tube (ensure Clean your eBike with water or a mild neutral loosen the Presta valve). that the inner tube dimensions are correctly detergent and non-abrasive sponge to remove any matched to the tire and rim dimensions – refer excess mud or debris. Never spray your eBike with 2. L oosen the tire from one side of the rim (specific to support or your local bike store for assistance pressurized water, as this can cause damage to tire lever tools may be required). as required) within the tire so it occupies the full seals, bearings and electrical componentry. Only 3. W ith one side of the tire removed, you can remove confines of the tire. Insert the tube valve through use or clean the electrical components (Pinion the inner tube. the valve hole in the rim. E-Trigger, Pinion Smart.Shift gearbox, wiring harness, etc.) with connected cable plugs or 2. U sing only your hands, begin to re-install the tire plug caps. Do not use high-pressure or steam... -
Page 25: Brake Pads And Brake Rotors
5/ Maintaining your Track eBike Maintaining your Track eBike Brake pads and brake rotors Inspect disc brake pads for wear every month. When the thickness of the backing plate and pad material is 3 mm or less, they are worn and need to be replaced with new disc brake pads. Rotor wear will vary by product model and riding conditions. This is normal. Change the rotor when changing the pad material, or when the thickness is less than the minimum stated on the rotor: Tektro Disc Brake Pad Replacement... -
Page 26: Battery
5/ Maintaining your Track eBike Maintaining your Track eBike Battery Charging your bike When the battery is fully charged, disconnect the removing or replacing any original equipment or battery from charging system and disconnect the modifying your bicycle in any way that may change The battery of your eBike will show signs of wear charging system from the wall socket. its design and / or operation. Such changes may over the years. Gradual degradation of the lithium- seriously impair the handling, stability and other ion battery will result in reduced range and charge ! WARNING: As with all mechanical components, aspects of the bicycle, making it unsafe to ride. capacity over time. After a certain period of time it EPAC is subjected to wear and high stresses. Tampering can void the warranty and render your may be necessary to replace the battery. Different materials and components may react to bike not in compliance with the applicable laws and wear or stress fatigue in different ways. If the design A rechargeable battery that has reached the end of regulations. To ensure safety, quality and reliability, life of a component has been exceeded, it may serviceable life must not be disposed of in regular use only original parts or authorized replacements for suddenly fail, possibly causing injuries to the rider. household rubbish. Dispose of the battery responsibly repair and maintenance. Any form of crack, scratches or change of coloring at a relevant battery drop off point. Should your in highly stressed areas indicate that the life of If a Mercedes eBike is tampered with in any way, battery need replacement, be sure to replace it with the component has been reached and it should be both the eBike and components warranty will be... -
Page 27: Warranty
6/ Warranty Warranty The Consumer may have rights in relation to Goods under the relevant consumer. Nothing in these terms and conditions excludes or restricts any of the Consumer’s statutory rights. Where the Goods are not purchased for personal, domestic or household use, we way limit the Consumer’s remedies to replacing or repairing the Goods or reimbursing the Consumer for the cost of repairing or replacing the Goods. 1. T he warranty offered by us applies in the event of a i. N eglect of Goods (lack of care and 4. W e may refuse to remedy defective Goods in the structural defect in the workmanship or materials maintenance); manner requested by the Consumer if such remedy at the time of receiving the delivered Goods, the would result in unreasonable costs. ii. F ailure to properly install or assemble Consumer shall be entitled to request from us to the Goods or use a properly qualified 5. W e reserve the right to repair Goods or replace repair the defect or to supply replacement Goods technician for repairs or maintenance; them with a new model. In the event that it is (as ordered) which is free from those defects. necessary to change the model, we will endeavour iii. U se of any of the battery or electrical This warranty is limited to defective workmanship, to replace them in the original colour subject to systems in a manner which is not materials or Goods and excludes normal wear and availability. Should the original colour no longer be expressly specified;... -
Page 28: Manuals
7/ Manuals Manuals You can find component manufacturer manuals online via our website, which detail use, maintenance, care Shimano Tektro Bedding Pads and Rotors Hydaulic Disc Brake System... - Page 29 Contact us AUSTRALIA +61 1800 319 714 USA +1 833-631-0071 UK / Europe +44 808 304 8296 EMAIL support@nplusbikes.com Get social @nplusbikes @n+bikes...
