The Beacon LED Tower: Vertical Mast
Model Number: LE980LEDV
(and suffixes including, T4 etc)
Operating Manual
Operating video: www.beaconledtower.com/beacontowercarecentre
145 Renfrew Drive, Unit 150 • Markham, ON, CA • L3R-9R6
300 International Drive, Suite 100 • Williamsville, NY, USA • 14221
T: 877.475.LIND (5463) • F: 877.475.2030 • info@lindequipment.net
www.lindequipment.net
Advertisement
Table of Contents
Summary of Contents for Lind Equipment LE980LEDV
- Page 1 The Beacon LED Tower: Vertical Mast Model Number: LE980LEDV (and suffixes including, T4 etc) Operating Manual Operating video: www.beaconledtower.com/beacontowercarecentre 145 Renfrew Drive, Unit 150 • Markham, ON, CA • L3R-9R6 300 International Drive, Suite 100 • Williamsville, NY, USA • 14221 T: 877.475.LIND (5463) •...
-
Page 2: Table Of Contents
Step 2: Position and Stabilize the Beacon LED Tower Step 3: Extend the Light Heads Step 4: Power the Light System Step 5: Lowering the Mast Transporting the Beacon LED Tower 12-14 Electrical Information Replacement Parts LIND EQUIPMENT LTD. LIND EQUIPMENT LTD. www.beaconledtower.com www.beaconledtower.com... -
Page 3: Safety Precautions
Operating Manual Safety Precautions FAILURE TO FOLLOW THESE PRECAUTIONS COULD RESULT IN SERIOUS INJURY OR DEATH • Keep clothing, hair and appendages clear of all moving parts • Do not deploy the mast if there is expectation of heavy winds •... -
Page 4: Transportation Precautions
• Mast must be fully retracted and light head assembly lowered and removed entirely prior to transport • Beacon LED Tower must be tied down during transportation LIND EQUIPMENT LTD. LIND EQUIPMENT LTD. www.beaconledtower.com www.beaconledtower.com... -
Page 5: Electrical Precautions
Operating Manual Electrical Precautions FAILURE TO FOLLOW THESE PRECAUTIONS COULD RESULT IN ELECTROCUTION • Ensure that the unit is clear of overhead wires and obstructions before deploying the mast • Do not use unit if electrical cords are cut or worn through •... -
Page 6: Assembling The Beacon Led Tower
Beacon LED Tower. Pull up on the spring loaded pins and push the outriggers into the receivers. Let go of the spring pins and allow the pins to lock into the hole in the outriggers. Spring pin and receiver for outriggers LIND EQUIPMENT LTD. LIND EQUIPMENT LTD. www.beaconledtower.com www.beaconledtower.com... -
Page 7: Step 3: Attaching Light Head Assembly To Mast
Operating Manual Assembling The Beacon LED Tower Step 3: Attaching Light Head Assembly to Mast Using two people, line up the mounting hole on the t-bar with the corresponding hole on the mast. Secure the t-bar to the mast using the nylon lock nut and bolt provided. -
Page 8: Preparing The Beacon Led Tower For Use
WARNING: Failure to properly inspect the light tower and surrounding area and remedy any maintenance or safety issues could result in serious injury to the user and damage to the light tower LIND EQUIPMENT LTD. LIND EQUIPMENT LTD. www.beaconledtower.com www.beaconledtower.com... -
Page 9: Step 2: Position And Stabilize The Beacon Led Tower
Operating Manual Preparing The Beacon LED Tower for Step 2: Position and Stabilize the Beacon LED Tower Position the cart on a solid surface and a flat incline. Pull up on the spring loaded pins and extend the outriggers. Release the pin and allow it to lock into place in the final locking hole on the outrigger (see picture below to see the outriggers in fully deployed position). Extend the feet of the stability jacks using the crank handles until they are firmly on the ground. If necessary, use the jacks to ensure that the Beacon LED Tower is completely level before deploying the mast. -
Page 10: Step 3: Extend The Light Heads
STOP sign will show on the second stage of the mast. Do not attempt to force the winch further once it has reached the stop. LED Light Tower with light heads deployed LIND EQUIPMENT LTD. LIND EQUIPMENT LTD. www.beaconledtower.com www.beaconledtower.com... -
Page 11: Step 4: Power The Light System
Operating Manual Preparing The Beacon LED Tower for Step 5: Power the Light System If using a generator, position the generator in the cabinet with the exhaust pointed toward the GENERATOR EXHAUST HERE sticker on the side of the cabinet. Exhaust should be positioned directly in front of the large ventilation slots in the side of the cabinet. -
Page 12: Transporting The Beacon Led Tower
Adjust light heads to an inclined position (see picture) so that the sides are in line with the widest part of the frame Line the Beacon LED Tower up to go straight through the door Retract the outriggers all the way in LIND EQUIPMENT LTD. LIND EQUIPMENT LTD. www.beaconledtower.com www.beaconledtower.com... - Page 13 Operating Manual Transporting The Beacon LED Tower Ensure the Mast Is All the Way Down Before Moving the Light The Beacon LED Tower is a man-portable light and can be maneuvered around the jobsite by way of the included handle and casters. The Beacon LED Tower can be lifted into a vehicle such as a pick-up truck for transporting long distances.
- Page 14 WARNING: The Beacon LED Tower is NOT meant to be towed. Do NOT attempt to tow on roads of any type. LIND EQUIPMENT LTD. LIND EQUIPMENT LTD. www.beaconledtower.com www.beaconledtower.com...
-
Page 15: Electrical Information Replacement Parts
Operating Manual Electrical Information & Replacement Parts Electrical Information The LED light heads can run off any power source supplying voltage from 90V – 277V. The Beacon LED Tower is wired with a 120V, NEMA 5-15P plug. Always observe local electrical codes when supplying power to the Beacon LED Tower. - Page 16 For more information about Lind’s Beacon LED Tower and its variations, please visit: www.BeaconLEDTower.com...
