Summary of Contents for SMARTWINGS Drapery Double Rod
- Page 1 Quick Installation Guide Drapery INS-102-C034 A-09 November 2024...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Track Splicing.............4 2. Track Runner Removal........8 3. Fabric Hook Installation ........9 4. Track Installation..........10 ..........10 4.1 Ceiling Mount ..........14 4.2 Wall Mount 5. Valance Installation........17 6. Motor Installation..........18 7. Fabric Installation...........19 8. Remote Holder Installation ......21... - Page 3 Single Rod kit accessory list: Fabric Hooks Fabric Hooks Fabric Clips Extension Bracket Fixed Bracket...
- Page 4 Double Rod kit accessory list: Fabric Hooks Fabric Hooks Fabric Clips Double Rod Kit Extention Bracket...
-
Page 5: Ceiling Mount
Ceiling Mount Double rod kit Single rod kit Wall Mount Double rod kit Single rod kit... -
Page 6: Track Splicing
Track Splicing Peel off the protective plastic film from both ends of the track. If the track length is less than 98.4" (2500mm), you may skip this step and proceed to page 9. Tracks under this length are supplied as a single piece and do not require joining. For tracks longer than 98.4"... - Page 7 3. Use the belt buckle (Fig 1-d) at the end of the belt to thread it through the overlap arm (Fig 1-e). Fig 1-d Fig 1-e 4. Insert the belt buckle and overlap arm into the track (Fig 1-f). Align the combined belt buckle and overlap arm with the designated position on the track (Fig 1-g), then slide them into place (Fig 1-h, Fig 1-e).
- Page 8 5. Splice the overlap arm with the sliding component on the track. Pull the overlap arm and the sliding part together by hand (Fig 1-j). Fig 1-j 6. Put the screws from the kit into the overlapping round holes. Fig 1-k Fig 1-l 7.
- Page 9 Step 2 Loosen Screws 1. Loosen the four screws on the track joint bracket connecting the two tracks (Fig 1-o). Fig 1-o Step 3 Align Tracks 1. Flip the track over and align the two tracks (Fig 1-p). Fig 1-p Step 4 Adjust Position 1.
-
Page 10: Track Runner Removal
Track Runner Removal If you consider the number of runners on the track to be excessive, please follow the steps outlined below to remove them. If removal is not required, please turn to page 10. Step 1: Loosen the locking nut Use a screwdriver (not included) to loosen the locking nut at the end of the track, allowing access to remove the excess track runners. -
Page 11: Fabric Hook Installation
Fabric Hook Installation Important!: Insert the fabric hook with the hooked end facing upward into one of the two smaller holes on the end before securing the track to the ceiling or wall, as the hook cannot be attached afterward. Fig 2-a Fig 2-b With Fabric Hook... -
Page 12: Track Installation
Track Installation Choose between ceiling or wall installation for your drapery. If installing on the ceiling, fixed brackets should be used, then the installation steps refer to page 10. For wall installation, install both fixed brackets and extension brackets according to page 14. Ceiling Mount Install the track, the fixed brackets should be used. - Page 13 Step 2 Install track to the Wall Single rod kit with valance installation method: Tips: Leave at least 10cm of space for single rod kit installation. 1. Mark the holes for securing the brackets. Keep the brackets parallel. Maintain a distance of at least 6cm from the wall corner to the middle hole of the first fixed bracket.
- Page 14 Double Rod kit with valance Installation method: Tips: Leave at least 18cm of space for double rod kit installation. 1. Mark the holes for fixing the brackets. Ensure the brackets are parallel. Maintain a distance of at least 6cm from the wall corner to the middle hole of the first fixed bracket. Maintain a distance of at least 8cm from the middle hole of the first fixed bracket to the holes of the second fixed bracket.
- Page 15 When you have the curtain box Tips: The internal width of the curtain box should be at least 18cm. 1. Mark the holes for securing the brackets. Ensure the brackets are parallel. Maintain a distance of at least 6cm from the wall corner to the middle hole of the first fixed bracket .
-
Page 16: Wall Mount
Track Installation Wall Mount Install the drapery on the wall, extension brackets should be used. Secure the Fixed Bracket to the Extension Bracket by fastening screws through the center hole, completing the assembly of the Single Rod Kit Extension Brackets. Fig 3.2-a Step 1 Install the Extension Bracket Before installing the brackets on the wall, first... - Page 17 Install the drapery on the wall, extension brackets should be used. （Double rod kit extention brackets） Fig 3.2-b Install the Extension Bracket Double rod kit Step 1: Draw a horizontal line at the appropriate position to ensure the brackets are parallel. Step 2: Mark the hole positions on the brackets to keep them level.
- Page 18 Step 2 Install track to Extension Bracket Single rod kit Rotate the lower metal buckle of the fixed bracket clockwise to the right. Snap the bracket onto the track. Return the metal buckle to its original position. Tighten the screws securely, ensuring they are firmly in place.
-
Page 19: Valance Installation
Valance Installation If you didn’t purchase a valance, skip this step and proceed to page 18. Step 1 Install Valance Fixed Brackets Install the valance fixed brackets by aligning the screw with the mounting hole and securing it with a bolt (Fig 4-a, Fig 4-b). The installation method for the double rod kit is identical to that of the single rod kit. -
Page 20: Motor Installation
Motor Installation Align the holes at the end of the track and insert the motor (Fig 5-a). Pull the lock knob downward to secure the motor in place (Fig 5-b). To unlock, simply return the knob to its original position (Fig 5-c). Fig 5-a Fig 5-b Fig 5-c... -
Page 21: Fabric Installation
Fabric Installation Installation Diagram: First, identify the front and back sides of the shade before installation. When installing, make sure to attach the Fabric Clips to the designated holes on the Fabric Carrier. The opposite edge should be secured in the fixed hole at the end of the track. Fig 6-a Fig 6-b... - Page 22 Fabric Installation Fig 6-c Insert the Fabric Clips one by one into the middle seam of the shade. Then, attach the clips in sequence to the metal rings of the track rollers. Fig 6-d Match the hooks on the drapery fabric with the hanging wheels on the track one by one. Additionally, you have the flexibility to fine-tune the drapery by adjusting the hooks up or down.
-
Page 23: Remote Holder Installation
Remote Holder Installation...
