DB-9910T

Smart toilet

Installation/user manual

(including warranty card)

For product improvement, designs and

specifications are subject to change

without prior notice.

Read all instructions and guidelines

thoroughly before installation.

We assume no responsibility for any

safety accident caused by inappropriate

use.

Make sure to keep this user manual

and product warranty card at all times

for installation, operation and

maintenance.

Table of Contents

Need help?

Do you have a question about the DOBIDOS DB-9910T and is the answer not in the manual?

Questions and answers

Summary of Contents for DAELIM DOBIDOS DB-9910T

Page 1 DB-9910T Smart toilet Installation/user manual (including warranty card) For product improvement, designs and specifications are subject to change without prior notice. Read all instructions and guidelines thoroughly before installation. We assume no responsibility for any safety accident caused by inappropriate use.
Page 2: Table Of Contents
Table of contents Safety instruction 1. Warning 2. Caution 3. Name of parts Installer’s manual 4. Installation guide Precautions Components 10~11 Installing toilet with e-bidet Test guide Installing remote controller 5. Preparation and checkpoints before use User’s manual 6. How to replace remote controller battery 7.
Page 3: Safety Instruction
Disclaimer Daelim Trading Co., Ltd. assumes no responsibility for any loss caused by earthquake, lightning, flood, fire not attributable to Daelim Trading Co., Ltd., action of a third party, intentional or unintentional accident of the consumer, and use of the product under an abnormal condition.
Page 4 Warning Warning Please follow all instructions for safety. Be careful of low temperature burn. When the following person uses the heated seat or dry, set the seat temperature to ‘Room temperature’ and the dry temperature to ‘Low’. Children, elderly or others who are unable to control the temperature by themselves. ᆞ...
Page 5 Use AC 220V (60Hz) only. Never use too many Do not install the product in a humid place. electrical goods on a single electrical outlet. This may cause a fire or electric shock. ● This may cause a fire or overheat. Prohibited Prohibited Prohibited...
Page 6 Caution Caution Please follow all instructions for safety. Keep combustibles, such as cigarettes, away Do not bend or distort the water supply hose. from the product. This may cause a leakage. This may cause a deformation of the product or fire. Prohibited Prohibited Prohibited...
Page 7: Caution
Caution Please follow all instructions for safety. After installation, make sure that there is no Do not expose the product to direct sunlight. leakage in the water supply connection. This may cause discoloration or uneven seat temperature. Make sure to put the small packing in the water supply Leakage hose.
Page 8: Name Of Parts
Name of parts DB-9910T Smart toilet Remote controller Remote controller hanger e-bidet Seat Nozzle Toilet bowl Power Flush...
Page 9: Installation Guide
Installation guide Read this installation guide carefully before installing the product. Precautions 1. The product operates with AC 220V (60Hz), and the rated power consumption is 1310W. Make sure to use the appropriate cable. 2. The power cord is 1.5m long. A socket must be located in such a place where you can install and remove the product.
Page 10: Installing Toilet With E-Bidet 10~11
Installation guide Read this installation guide carefully before installing the product. Installing the e-bidet 1. As shown in the figure, insert the large 2. Connect the two flush valve hoses assembled packing into the water supply hose then on the toilet bowl to the lower part of the e-bidet. connect the hose with the product.
Page 11 5. Check the fixing plate at the bottom on the rear 7. After opening the seat and lid, align the front side of the product. hole of the e-bidet with the toilet bowl hole, fix the holes with large screws and assemble 6.
Page 12: Test Guide
Installation guide Read this installation guide carefully before installing the product. Test operation guide 1. Check the voltage 2. Fill the water tank • Plug the power cord to a 220V outlet. • If you touch the Rear button on the remote controller, water will be supplied to the water tank.
Page 13: Installing Remote Controller
Installation guide Read this installation guide carefully before installing the product. Installation of the remote controller Choose a location for installing remote controller and remove any moisture or debris on the surface ▶ Installation using double-sided tape 1. Remove moisture and debris from the 2.
Page 14: Preparation And Checkpoints Before Use
Precautions and checkpoints before use Put the power plug in the outlet 1. Place the 220V outlet (10A or higher) 2. Install the outlet with a cover high enough at the height of 50cm from the floor. from the floor to prevent water from reaching it.
Page 15: How To Replace Remote Controller Battery
How to replace remote controller battery When replacing the battery, read the instructions below carefully and replace it. How to replace remote controller battery Replacing battery 1. Detach the remote controller from the hager. 2. Open the battery cover in the back of the remote controller, rotating it in the direction of arrow.
Page 16: How To Use The Product
How to use the product Do not touch the buttons too hard in order to prevent malfunction. Connecting the remote controller (pairing) ▶ - Supply power to the product and touch the Stop button for at least 5 seconds. (Must be done within 1 minute after supplying power.) - Pairing is completed when you hear a ‘beep’...
Page 17: Front / Move • Wide Clean • Pressure • Massage • Flush • Oepn / Close
▶ Front function: Touch once for front cleaning for ladies. Touch twice for nozzle oscillating movement for massaging effect. • With a beep sound, the e-bidet discharges the water. • The function stops automatically after the designated time. • To use the function continuously, touch the Front/Move button again. •...
Page 18 How to use the product Do not touch the buttons too hard in order to prevent malfunction.
Page 19: Water Temp. • Seat Temp. • Dry Temp. • Auto Open / Close
▶ Water Temperature Control: The water temperature can be adjusted. • 4 levels (Off: Room temperature, Low: 32℃, Mid: 36℃, High: 38℃) . Room temperature : e-bidet power lamp off / Remote controller status indicator level 1, 2, 3 lamp off. .
Page 20 How to use the product Do not touch the buttons too hard in order to prevent malfunction.
Page 21: Auto Flush • Nozzle Position • Nozzle Cleaning • Child
▶ Auto flush: The product automatically flushes when the user leaves the product. (the user does not have to worry about flushing after using the product.) • If the LED on the remote controller is lighted, the function is activated. If the LED is not lighted, the function is deactivated.
Page 22 How to use the product Do not touch the buttons too hard in order to prevent malfunction.
Page 23: Eco • Deo • Silent Mode
ECO: You can limit power consumption by controlling ▶ temperature of the seat, water and air with the ECO button. ECO level 1: Normal ECO (seat and hot water temperature: 32℃) ▶ e-bidet power lamp and flush lamp are lighted in purple. •...
Page 24: How To Use The Control Panel / How To Use The Emergency
How to use the product Do not touch the buttons too hard in order to prevent malfunction. How to use the buttons on the e-bidet Touch the button for 5 seconds to turn off the e-bidet. ▶ When the power is OFF, touch the button to turn on the e-bidet. ▶...
Page 25: How To Maintain The Product
How to maintain the product Cleaning 1. Cleaning the exterior part of the product • Wipe the exterior part of the product with a soft sponge or cloth soaked with neutral detergent. Do not use hydrochloric detergent, thinner, benzene, lubricant, sand paper, odorant, insecticide, etc.
Page 26: When The Product Will Not Be Used For A Long Time
When the product will not be used for a long time Drain the supplied water for the following cases 1. Leaving home for a long period of time • Water can get dirty and block the water path. 2. Using in a vacation home •...
Page 27 5. Hold the product, disconnect the two flush 6. Open the drain valve at the bottom of the valve hoses by pressing the button on the e-bidet body, and drain water from the connector, and then remove the water water tank. supply hose.
Page 28: Troubleshooting
Troubleshooting Please refer to the following possible solutions before contacting the customer service center. Self-diagnosis display Troubleshooting Display Cause Troubleshooting The flush lamp The water tank is empty. 1. Touch the Rear button to supply water. blinks in blue. 2. If the power lamp is still blinking in blue after 1 minute, water is not supplied yet.
Page 29: Specifications
Specifications Item Description AC 220V / 60Hz, 1310W, Monthly power consumption 22.7kWh/month, frequency 2.4GHz Power saving, Power consumption, General power saving 16.8kWh/month, Rating Energy saving 13.2kWh/month. remote controller specification(2.448GHz(GFSK))& operating voltage(DC 3V(CR2032 2EA)) Water heat type Continuous hot water, 4 levels: OFF, Low (32℃), Mid (36℃), High (38℃) 3-levels water pressure level (Max : 0.7 ℓ/min) Front Temperature fuse (72℃), thermostat (55℃), temperature sensor...
Page 30 Memo...
Page 31: Warranty
Failure attributable to the customer ② Improper handling, repairing or remodeling conducted by the customer. ● Repairing conducted by other than the service engineer of Daelim Trading or of the service provider designated ● by Daelim Trading. Using accessories not provided by Daelim Trading.
Page 32 How can I request after-sales service? Double-check the operation guide in this manual. If the problem continues after checking, stop using the product and contact the customer service center.
