REMOTE CONTROLED
VENT-FREE GAS STOVE
OWNER'S OPERATION
AND INSTALLATION
MANUAL
BTSD23RT
WARNING: If the information in this manual is not
followed exactly, a fire or explosion may result causing
property damage, personal injury or loss of life.
— Do not store or use gasoline or other flammable va-
pors and liquids in the vicinity of this or any other
appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any
phone in your building.
• Immediately call your gas supplier from a neighbor's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire
department.
— Installation and service must be performed by a quali-
fied installer, service agency or the gas supplier.
WARNING: This appliance is equipped for Natural and
Propane gas. Field conversion is not permitted other than
between natural or propane gases.
Questions, problems, missing parts? Before returning to your retailer, call
our customer service department at 1-866-762-4050, 8:00 am - 4:30 pm CST,
Monday through Friday or email contact@bluegrassliving.com
CSA/ANS
Z21.11.2 2019
Unvented Room
Heaters
PFS F10-051
Advertisement
Table of Contents
Summary of Contents for Bluegrass Living BTSD23RT
- Page 1 REMOTE CONTROLED VENT-FREE GAS STOVE OWNER’S OPERATION AND INSTALLATION MANUAL BTSD23RT CSA/ANS Z21.11.2 2019 Unvented Room Heaters PFS F10-051 WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety ............3 Operation ..........18 Specifications ..........5 Inspecting Main Burners ......23 Product Features ........5 Care And Maintenance ......23 Local Codes..........5 Troubleshooting ........24 Product Identification ......... 6 Parts ............28 Unpacking..........6 Replacement Parts ........ -
Page 3: Safety
SAFETY IMPORTANT: Read this owner’s WARNING: Do not allow fans manual carefully and completely to blow directly into fireplace. before trying to assemble, op- Avoid any drafts that alter burner erate, or service this heater. flame patterns. Improper use of this heater can cause serious injury or death WARNING: Do not use a from burns, fire, explosion,... - Page 4 SAFETY 12. Do not use this heater as a wood-burning WARNING: The fire screen or heater. Use only the logs provided with the guard designed for this unvent- heater. ed appliance must be installed 13. Solid fuels should not be burned in a stove prior to operation.
-
Page 5: Specifications
SAFETY PILOT THERMOSTATIC CONTROL This heater has a pilot with an Oxygen Deple- Model BTSD23RT: The control automatically tion Sensing (ODS) safety shutoff system. The cycles the burner on and off to maintain a ODS/pilot shuts off the heater if there is not desired room temperature. -
Page 6: Product Identification
PRODUCT IDENTIFICATION Screen Logs Heater Controls (Inside Panel) Figure 1 - Vent-Free Stove UNPACKING 1. Remove top inner pack. 6. Hold the screen, lift, and pull forward. 2. Tilt carton so that heater is upright. 7. Remove log set by cutting plastic ties. 3. -
Page 7: Qualified Installing Agency
QUALIFIED INSTALLING AGENCY Only a qualified agency should install and a) Installing, testing, or replacing gas piping replace gas piping, gas utilization equipment or accessories, and repair and equipment ser- b) Connecting, installing, testing, repairing, vicing. The term “qualified agency” means any or servicing equipment;... -
Page 8: Ventilation Air
AIR FOR COMBUSTION AND VENTILATION VENTILATION AIR Ventilation Air From Inside Building This fresh air would come from an adjoining unconfined space. When ventilating to an 12" adjoining unconfined space, you must provide two permanent openings: one within 12" of the Ventilation ceiling and one within 12"... -
Page 9: Installation
INSTALLATION CHECK GAS TYPE NOTICE: This heater is intended Be sure your gas supply is right for your heat- for use as supplemental heat. er. Otherwise, call dealer where you bought Use this heater along with your the heater for proper type heater. primary heating system. -
Page 10: Gas Selection
INSTALLATION GAS SELECTION This appliance is factory preset Back of Stove for propane gas. No changes are required for connecting to propane. Gas Inlet Gas esté Only a qualified installer or ser- vice technician can perform gas INLET GAS PRESSURE MAX 1/2 PSIG (3.5KPa) selection and connecting to gas supply. - Page 11 INSTALLATION 3. Apply thread sealant to the threads on the connection fitting. While pushing in, rotate the fitting clockwise until the threads engage the regulator. After the fitting has been hand tightened into the regulator use a wrench to complete tightening of the fitting.
-
Page 12: Connecting To Gas Supply
INSTALLATION CONNECTING TO GAS SUPPLY WARNING: A qualified ser- CAUTION: For natural gas, vice technician must connect check your gas line pressure heater to gas supply. Follow all before connecting heater to gas local codes. line. Gas line pressure must be no greater than 9.5"... - Page 13 INSTALLATION For propane installations, apply pipe joint sealant lightly to male threads. This will prevent excess sealant from going into pipe. Excess sealant in pipe could result in clogged heater valves. The installer must supply an external regula- tor. The external regulator will reduce incom- ing gas pressure.
-
Page 14: Checking Gas Connections
INSTALLATION CHECKING GAS CONNECTIONS WARNING: Never use an open WARNING: Test all gas piping flame to check for a leak. Apply and connections for leaks after a noncorrosive leak detection installing or servicing. Correct fluid to all joints. If bubbles form, all leaks at once. -
Page 15: Installing Logs
INSTALLATION PRESSURE TESTING HEATER GAS CONNECTIONS 1. Open equipment shutoff valve (see Figure 12, page 14). Apply a noncorrosive leak 10, page 14). detection fluid to all joints. Bubbles form- ing show a leak. 2. Open main gas valve located on or near gas meter for natural gas or open propane 5. -
Page 16: Installing Batteries
INSTALLATION 4. Place pins on Log #5 into holes in rear 8. Place Log #9 onto the Pin in Log #7; rest bracket as shown in Figures 15. the other end onto the left side of Log #3. 5. Slide screws in Log #6 into slots in the Log 9. - Page 17 INSTALLATION teries should be the same brand for best CAUTION: Do not mix old and results. new batteries. Do not mix alka- • Be sure to observe proper polarity (+/-) line, standard (carbon - zinc), or rechargeable (nickel - cadmium) batteries.
-
Page 18: Operation
OPERATION FOR YOUR SAFETY READ BEFORE LIGHTING • Immediately call your gas supplier WARNING: If you do not fol- from a neighbor’s phone. Follow the low these instructions exactly, a gas supplier’s instructions. fire or explosion may result caus- • If you cannot reach your gas supplier, call the fire department. -
Page 19: Manual Lighting Procedure
OPERATION Until repairs are made, light pilot with a position, then back to the ON position. match. Note: Please wait one minute after shut- • If control knob does not pop up when ting off fireplace to allow the control valve released, contact a qualified service to reset before starting again. -
Page 20: Remote Control System
OPERATION REMOTE CONTROL SYSTEM Programming the Remote and Receiver Key Settings ON - Operates unit to on position, manually The remote and receiver must be “learned” to one another. operated solenoid ON. OFF - Operates unit to off position, manually To prepare the receiver box for learning, use a pen or small screwdriver to gently press and operated solenoid OFF. - Page 21 OPERATION Setting°F/°C Scale 2. Press and hold the SET key until the de- sired set temperature is reached. The LCD The factory setting for temperature is °F. To screen set numbers will increase from 45° change this setting to°C, press the ON key to 99°...
-
Page 22: Inspecting Burners
INSPECTING BURNERS IMPORTANT: Owner’s should check pilot flame pattern and burner flame pattern often. Incorrect flame patterns indicate the need for cleaning (see Care and Maintenance, page 23 or have serviced by a qualified technician. WARNING: Only a qualified service person should service and repair heater. -
Page 23: Care And Maintenance
CARE AND MAINTENANCE WARNING: Turn off heater and let cool before servicing. CAUTION: You must keep control areas, burner, and circulating air passageways of heater clean. Inspect these areas of heater before each use. Have heater inspected yearly by a qualified service techni- cian. -
Page 24: Troubleshooting
CARE AND MAINTENANCE Use a vacuum cleaner, pressurized air, or a Ignitor Natural Gas Thermocouple Electrode small, soft bristled brush to clean. Burner Propane A yellow tip on the pilot flame indicates dust Gas Burner and dirt in the pilot assembly. There is a small pilot air inlet hole about 2"... - Page 25 TROUBLESHOOTING Problem Possible Cause Corrective Action Using natural gas and I n l e t p r e s s u r e e x c e e d s Bypass pressure switch. See pilot will not light. 9.5" WC. instructions below.
- Page 26 TROUBLESHOOTING Problem Possible Cause Corrective Action When ignitor button is 1. Gas supply is turned off or 1. Turn on gas supply or open pressed in there is a equipment shutoff valve is equipment shutoff valve. spark at ODS/pilot but closed.
- Page 27 TROUBLESHOOTING Problem Possible Cause Corrective Action Burner backfiring during 1. Burner orifice is clogged or 1. Clean burner orifice (see combustion damaged. Care and Maintenance, page 23). 2. Burner is damaged. 2. Contact dealer or customer service. 3. Gas regulator is damaged. 3.
-
Page 28: Parts
TROUBLESHOOTING Problem Possible Cause Corrective Action White powder residue 1. When heated, the vapors 1. Turn heater off when using forming within burner from furniture polish, wax, furniture polish, wax, carpet box or on adjacent walls carpet cleaners, etc., turn cleaner or similar products. - Page 29 PARTS MODEL: BTSD23RT This list contains replaceable parts for your heater. When ordering replacement parts, follow the instructions listed under Replacement Parts on page 30 of this manual. ITEM BTSD23RT DESCRIPTION 161338-01 Piezo Ignitor SL005-01A Blower Bracket BL016-07-03 Blower Access Panel...
-
Page 30: Replacement Parts
REPLACEMENT PARTS Note: Use only original replacement parts. This will protect your warranty coverage for parts replaced under warranty. PARTS UNDER WARRANTY Contact authorized dealers of this product. • Model and serial number of your heater If they can’t supply original replacement •... -
Page 31: Notes
NOTES __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ __________________________________________________________ 200585-01B www.bluegrassliving.com... -
Page 32: Warranty
Bluegrass Living makes no other warranties regarding this product. Bluegrass Living’s liability is limited to the purchase price of the product and Bluegrass Living shall not be liable for any other damages whatsoever under any circumstances including direct, indirect, incidental, or consequential damages.
Need help?
Do you have a question about the BTSD23RT and is the answer not in the manual?
Questions and answers
Why does my brand new stove shut down 10 minutes after being lit. When it shuts down the piolit goes out at the same time?
The Bluegrass Living BTSD23RT stove may shut down after 10 minutes and extinguish the pilot light due to several possible reasons:
1. Dirty Pilot Assembly – A yellow tip on the pilot flame indicates dust or dirt in the pilot assembly, which can affect proper operation. Cleaning the pilot assembly and air inlet hole may resolve the issue.
2. High Elevation Operation – If the heater is being used above 4,500 feet, it could cause pilot outage due to changes in air pressure.
3. Improper Gas Supply – Using a propane fuel tank smaller than 100 lbs. could lead to performance issues, including pilot failure.
4. System Safety Mechanism – If there is an issue with the burner flame pattern or air supply, the system may shut off as a safety precaution.
If the issue persists, a qualified service technician should inspect the stove.
