WWW.CELL-PHONE-SIGNAL-BOOSTER.COM
REPEATER
Nikrans NS-13K-Voice, 3G & 4G PRO
Calls/GSM / 3G / 4G/LTE
Indoor coverage: 13000 ft²
Frequency bandwidth of 850, 1900, 1700, 700 MHz
https://www.cell-phone-signal-booster.com/
repeater-82/
Nikrans NS-13K-
Voice, 3G & 4G PRO
Free Support
We've extended your warranty
up to 3 YEARS
We accept returns
within 30 days
3-7 business day delivery
Chat with us
info@cell-phone-signal-booster.com
+18883705270
(Sales)
Indoor Antennas /
Outdoor Antennas
SPECIFICATION
Indoor coverage: 13000 ft²
Up-link freq: 698-716MHz, 776-787MHz,
824-849MHz, 1850-1915MHz, 1710-1755MHz MHz
Down-link freq: 728-746MHz, 746-757MHz,
869-894MHz, 1930-1995MHz, 2110-2155MHz MHz
Up-link Gain: 65 dB
Down-link Gain: 70 dB
Power supply: AC 90~264V, DC9V/7A, 24W
Working t °C: -25/+55
IP-Code:
Humidity: 5 - 95%
Size (mm): 250 × 360 × 52
Booster Weight: 4.5 kg
dBm: 17 dBm
PACKAGE
Cables
Safety for Human Health
Conformity to CE and RoHS standarts
All components
in one package
Full duplex mode (improvement of outcoming and incoming signal)
Power supply
User Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the NS-13K-Voice 3G & 4G PRO and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Nikrans NS-13K-Voice 3G & 4G PRO

  • Page 1 WWW.CELL-PHONE-SIGNAL-BOOSTER.COM REPEATER Nikrans NS-13K-Voice, 3G & 4G PRO SPECIFICATION Indoor coverage: 13000 ft² Up-link freq: 698-716MHz, 776-787MHz, 824-849MHz, 1850-1915MHz, 1710-1755MHz MHz Down-link freq: 728-746MHz, 746-757MHz, 869-894MHz, 1930-1995MHz, 2110-2155MHz MHz Up-link Gain: 65 dB Down-link Gain: 70 dB Power supply: AC 90~264V, DC9V/7A, 24W Working t °C: -25/+55...
  • Page 2 PRODUCT DESCRIPTION These sophisticated signal boosters Nikrans NS-13K-Voice, 3G & 4G PRO cater for the needs of large buildings in excellent and non-fluctuant cell signal. Thus, the phone repeater NS-13K-Voice, 3G & 4G PRO is capable of covering up to 13,000 ft². It’s a penta band signal booster that is designed to support the US carriers’...
  • Page 3 INSTALLATION SCHEME 1. Find the best position of an outdoor antenna (on the roof/ outside the window where your mobile phone displays 2-3 bars of mobile coverage). Choose the best direction of the antenna – it’s recommended to direct it towards the nearest GSM base station.
