Installation Manual
Model: 53551 Fresh White
Fan weight ±1 kg: 8.0 kg
©2024 Hunter Fan Company
M4071 r071124

Advertisement

loading
Need help?

Need help?

Do you have a question about the Arete 53551 and is the answer not in the manual?

Questions and answers

Summary of Contents for Hunter Arete 53551

  • Page 1 Arete Installation Manual Model: 53551 Fresh White Fan weight ±1 kg: 8.0 kg ©2024 Hunter Fan Company M4071 r071124...
  • Page 2 • To reduce the risk of personal injury, attach the fan directly to the support structure of the building according to these instructions and use only the hardware supplied. © 2024 Hunter Fan Company 7130 Goodlett Farms Pkwy, Suite 400 Memphis TN 38016 U.S.A.
  • Page 3: Limited Lifetime Warranty

    Please do not ship your fan or any fan parts to Hunter. Delivery will be refused. improper voltage supply or power surge, use of improper parts or accessories, failure to provide maintenance to the fan, or acts of God (e.g.
  • Page 4 Here are the tools you’ll need to complete your installation: IMPORTANT: THIS PRODUCT MUST BE INSTALLED BY A LICENSED ELECTRICIAN. Ladder Pliers Screwdriver 9 mm Wrench Wire Strippers Small Flat Head Screwdriver OPTIONAL If mounting to a support structure, you will also need these tools.
  • Page 5 Here is what comes in your box: Hunter Pro Tip: We recommend that you pull everything out of the box and lay it out. We have grouped the drawn components below with the hardware you’ll need for those Do not discard the hardware bags or mix parts from parts.
  • Page 6: Choosing The Right Installation Location

    A little more information on Angled Mounting: For optimum performance and appearance, a longer downrod should be used with your Hunter ceiling fan when installing on high or angled ceiling. If your ceiling is angled greater than 34° you will also need an Angled Mounting Kit.
  • Page 7: Installing The Ceiling Bracket

    Installing the Ceiling Bracket You have two options for installation. Pick which one works best for your location. Remove any existing bracket prior to installation. Only use the provided Hunter ceiling bracket that came in your fan’s box. FOR CONCRETE CEILINGS...
  • Page 8: Hanging The Fan

    1886 Installing the Downrod Follow below if you are using the downrod that came in your box. Need to install a longer or shorter downrod? Check out the guide at the end of this manual. Back out the pre-installed setscrew (A) Slide the downrod sleeve (A) up the downrod.
  • Page 9: Wiring The Fan

    1886 Wiring the Fan Connect wiring harness from canopy mount (A) to wiring harness Pull the supply mains (A) through the side of the hanger bracket (B). from fan body (C). Thread the end of each wire into the terminal block (A) on the Earth wire (A) (green/yellow) to terminal (B) marked hanger bracket, then secure each supply main (B) by tightening Earth wire from downrod (C) to terminal (B) marked...
  • Page 10: Installing The Canopy

    1886 Installing the Canopy Insert the two canopy screws found in the hardware bag. Canopy Screw Lift the canopy into place so that the screw holes are aligned. Installing the Blades: Put the blade washers found in the hardware bag onto the blade screws found in the hardware bag.
  • Page 11 1886 Assembling the Light 2 of 5 1 of 5 Light Kit Screw Light Kit Screw Partially install two light kit screws, Align the keyhole slots in the top of the found in the hardware bag, through upper switch housing with the partially the gasket halfway into the motor installed light kit screws.
  • Page 12: Preparing The Remote

    1886 Preparing the Remote For your convenience, a remote function card NOTICE : DIMMING MODE is packed in with your remote. To toggle Dimming Mode on or off, long press the “Fan Speed Up” button and “Fan Speed Down” To access the battery compartment, button.
  • Page 13: Troubleshooting

    • Remove batteries from equipment which is not to be used for an extended period of time. Hunter Pro Tip: • Remove used batteries promptly. Cleaning the Fan Use soft brushes or cloths to prevent scratching.
