- Page 1 Please read the user manual thoroughly before using www.sherpapower.co.uk...
-
Page 2: Table Of Contents
Box Contents ································ 01 Specifications ································ 02 Function Overview ································ 03 How to use the PEAK 3.0-EB ····························· 04-10 Notes Before Cascading With a Host ····················· 05 Stacking and Securing Batteries ·························· 06 Connect and Remove the Cascade Cable ················ 07 Cascading Process ···························... -
Page 3: Box Contents
BOX CONTENTS PEAK 3.0-EB 3072Wh Output adapter from XT60 to MC4 solar charging cable (LSMC4-5GX16) *1 PEAK 3.0-EB *1 Aux and 5525 port *1 Input cable to Car charge cable to Anderson adapter cable *1 MJ32 cascade cable *1 5521 connector *1... -
Page 4: Specifications
SPECIFICATIONS Capacity Battery Type Protections Temperature Dimension Net Weight Over-Voltage, 3072Wh LiFePO4 Battery 0℃~45℃/32°F~113°F Overheat, L441*W312*H200 (240Ah) Retains 80%+ (Charging) 26kg Overload, Original Capacity -20℃~45℃/-4°F~113°F Short-Circuit, At 3500 Cycles (Discharging) Self-Recovery OUTPUT SPECS INPUT SPECS XT60 Output *1 USB-A *1 GX16MF-5 *1 USB-C *1 DC 12V-30A... -
Page 5: Function Overview
FUNCTION OVERVIEW ① ② ⑤ ③ 75% 100% ④ EXTRA BATTERY PORT 1 EXTRA BATTERY PORT 2 ⑨ ⑥ DC ON/OFF ⑩ ⑦ DC INPUT 12V-30A PD 100W 12~95V-400W ⑧ ① ⑤ ⑨ LED Capacity Indicator Capacity Display Switch DC ON/OFF ②... -
Page 6: How To Use The Peak 3.0-Eb
DC INPUT 12V-30A PD 100W 12~95V-400W Note: The operating temperature range of the PEAK 3.0-EB is -20 to 45℃. If the operating temperature is not within this range, it will fail to work. Light press to show battery capacity 100%... -
Page 7: Notes Before Cascading With A Host
NOTES BEFORE CASCADING WITH A HOST 1 ： Before use, check that the PEAK 3.0-EB module and the host have similar battery levels, with a difference of no more than 10%. Turn the extra battery module and the host units OFF. -
Page 8: Stacking And Securing Batteries
STACKING AND SECURING MULTIPLE BATTERIES 1 ： First, remove the protective corners from the adjacent sides of the extra batteries you want to stack. Align projections underneath with the notches on top, then stack. 2 ： Use screws and metal connecting piece to secure the stacked batteries from top to bottom. -
Page 9: Connect And Remove The Cascade Cable
1 ： First power the module OFF. Set the identification numbers on the dial. Each ID number should be unique to each PEAK 3.0-EB module. 2 ： After completing the cascade connection, the host will calculate their combined battery level. -
Page 10: Charging The Peak 3.0
Generator Car Charger (sold separately) (via AC-DC adapter) Approx 8 h Approx 8 h Approx 30 h (via aux port) or 7-8 h (via Sherpa Charge-500) Solar panel Solar panel 200W 400W 19-20 Hours 10-11 Hours Note: Charging time depends on tilt of panel and weather conditions. -
Page 11: Solar Charge Configurations
SOLAR CHARGE CONFIGURATIONS Single panel setup MC4 Solar Charging Cable*1 The Voc of a single solar panel should be less than 95V, and the Vmp should be greater than 12V. Two panels in series setup MC4 Solar Charging Cable*1 The Voc of each solar panel should be less than 48V, and the Vmp should be greater than 6V. Series wiring effectively combines voltages, not the amperage. -
Page 12: Vehicle Charging
Note: Start the vehicle engine before connecting the charge cable to the PEAK to avoid draining the crank battery. MC4 Solar Charging Cable The Sherpa CHARGE-500 has MC4 connectors allowing you to use the MC4 Solar Charge Cable adapter to charge the PEAK 3.0-EB at a maximum rate. Please refer to the CHARGE-500 manual for installation instructions. www.sherpapower.co.uk... -
Page 13: Faqs
Q2 ： What machines can the PEAK 3.0-EB power pack be cascaded to? A ： PEAK 3.0-EB can be cascaded to Sherpa Peak power units with MJ32 cascade port. Q3 ： Once PEAK 3.0-Extra Batteries are cascaded, can they be used to charge or discharge? A ：... -
Page 14: Disclaimer
6. It's prohibited to be used as car jump starter, only can be used as a slow car battery charger. 7. Do not use accessories or parts other than those provided by Sherpa. Please visit our website www.sherpapower.co.uk or reach our support team for a complete list of accessories and parts. -
Page 15: Disposal
10. Do not block the air vents during use, or leave the device in a non-ventilated or dusty space. 11. Avoid impacts and violent vibration to the unit. Please turn off the device immediately and stop using it in the event of major exterior impact. -
Page 16: Warranty Exclusions
9. Warranty period expired. 10. The battery model on the warranty certificate does not match the actual item. 11. Unauthorised alteration on the warranty certificate. 12. Product wear and tear from general use. CUSTOMER SUPPORT ： www.sherpapower.co.uk www.sherpapower.co.uk Sherpa Tek Ltd. www.sherpapower.co.uk... - Page 18 www.sherpapower.co.uk...
