Lumena PROSOLAR DURASOL User Manual

PLEASE READ THESE INSTRUCTIONS CAREFULLY PRIOR TO INSTALLATION / MAINTENANCE
SPECIFICATIONS
Output: 9-12v DC - Constant Voltage
Max Wattage: 30W
Max Cable Run: 20m
Sensor: Light / Charge Sensor
IP Rating: IP65
Battery Type: Lithium - LiFePO4 3.2v/42Ah (replaceable)
Battery Charge Time: 4-8 hrs full sunshine (approx.)
Max Illumination Time at Full Charge: Up to 12hrs
Solar Panel: 5v / 50W Monocrystalline Solar Panel – Grade A
Solar Panel Size: 540 x 510 x 25mm
Cable Length Supplied: 0.2m (approx.), 3m plug & play cable w/splitter (optional)
Materials: 6053 Aluminium, 304 Stainless Steel, Tempered Glass
Weight (excluding mount): 5KG (approx.)
Mounting: Free standing A-Frame (pegs), Surface Mounting Bracket (optional)
Remote Control: up to 3m range (infrared)
Function: Dusk to Dawn, 4hr, 6hr, 8hr, 10hr Timers, On/Off (NOTE: Mode / Dim NOT IN USE)
Memory Function: Yes (excludes OFF Override which only overrides 1 cycle)
Short Circuit Protection: Yes
Working Temperature: -25˚C ~ 60˚C
Included: Panel, Panel Mount, A-frame, Battery Box, Receiver, 8x M4 SS Bolts / Flat Washers / Lock Washers / Nuts, 11x
M6 SS Bolts / Flat Washers / Lock Washers / Nuts, M3 Socket Wrench, M6 Socket Wrench, Twin Spanner, 4x Pegs,
Remote Control, In-line Connector, Plug & Play Cable & Splitters (optional)
•
If any component is found to be damaged, cease use immediately.
•
Components may get warm whilst on for a period of time.
•
Always take care when installing your solar panel.
•
Fitting must be mounted in accordance with selected specialist mount and instructions.
•
This Solar System will not charge correctly if the panel is behind glass or artificial light is used.
•
Ensure all connections are fully fastened and secure with no damage or short circuit.
•
Ensure the panel is fully secure when mounting: secure with pegs when freestanding / minimum 30mm M6 for wall
mounting (out of head height). Anchor Bolts recommended where possible.
CLEANING & MAINTENANCE:
Occasional cleaning and care is recommended for this product. Wipe with a soft, slightly damp cloth to remove any surface dirt.
To maintain efficiency, specifically clean the solar panel and receiver on a regular basis. Also, keep the solar panel free of debris
and snow to prevent reduced battery life or malfunction. Do not use abrasive cleaners or a lot of water as this could damage
the fitting. Please refer to our website for more information on the best way to clean different materials.
DISPOSAL / RECYCLING: Waste Electrical Products & Batteries should not be disposed of with household waste. Please
check with your local authority or contact us for more information. Please recycle packaging.
Producer Registration Numbers: WEE/KC3440XY / BPRN0843
RETURNS:
If purchased from a 3 rd
Lumena Lights Ltd, Centre 33 Long March, Daventry, NN11 4NR
Our full returns policy is available on our website.
THANK YOU FOR YOUR PURCHASE
party, please contact your supplier. If purchased direct, contact us by phone or email:
Full product range & more information: www.lumenalights.com
DURASOL 12v Solar Panel System
WARNINGS
Tel: +44 1327 871161
USER MANUAL
✔✔✔✔✔
5 YEAR
GUARANTEE
see website for
more details
Email:
