Orbic Telstra 4GX USB Modem 2 User Manual

Orbic Telstra 4GX USB Modem 2 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
TELSTRA VERSION
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Telstra 4GX USB Modem 2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Orbic Telstra 4GX USB Modem 2

  • Page 1 TELSTRA VERSION...

  • Page 2: Table Of Contents

    Table of Contents Overview ............4 Getting Started ................4 System Requirements ............4 Internet Connection ..............5 Device Overview ................6 LED Overview ................6 Setting up your Device ......... 7 Installing the SIM Card ............7 Using Your Device .......... 8 Connecting your PC to the Internet ........8 Connecting a Wi-Fi enabled device to the Internet ................8 Logging into the Device Management...
  • Page 3 Q&A ..............31 Product Specifications .......32 Wireless Communication ......33 Safety Hazards ..........34 Caring for your device ........ 36 Cleaning and Maintenance ......37 Disposal of Product and Batteries ..38...

  • Page 4: Overview

    NOTE: Screenshots, icons, labels, and visuals, are simplified for illustrative purposes only. They can vary slightly from your product. Getting Started Using the Telstra 4GX USB Modem 2, you can upload and download data connecting to the internet. System Requirements The Telstra 4GX USB Modem 2 is: 1.

  • Page 5: Internet Connection

    This powerful USB device can be simply plugged into your computer for internet access, and/or connect additional devices to the Wi-Fi network that the Telstra 4GX USB Modem 2 hosts. 4G Mobile Broadband* 1. Download: maximum download speeds up to 150Mbps.

  • Page 6: Device Overview

    Device Overview USB Cap Front Bottom cover Middle cover frame LED indicator LED Overview LED Status Indication Solid Blue Registered to 4G network with no data transfer Blinking Blue Data transfer in progress over 4G network Solid Green Registered to 3G network with no data transfer Blinking Green Data transfer in progress over 3G network Purple...

  • Page 7: Setting Up Your Device

    Setting up your Device Installing the SIM Card To insert the SIM Card 1. Disconnect the USB from your PC. 2. Slide the back cover to open the device. 3. Gently insert your SIM card in the slot with the gold contacts facing down, and click it into place.

  • Page 8: Using Your Device

    Connecting your PC to the Internet 1. Ensure that the Wi-Fi on your PC is turned OFF. 2. Insert the Telstra 4GX USB Modem 2 in the USB slot of your 3. Your device will automatically be connected to the internet.

  • Page 9: Logging Into The Device Management Website

    Logging into the Device Management website Log in to http://192.168.1.1 or in the address bar. Enter the Username and Password. Click Login. You can modify the user credentials if required. Note: The default username and password can be found on the sticker inside your back cover.

  • Page 10: Home

    The Internet Info displays the key information of your device. Wi-Fi Status This section allows you to view Wi-Fi status, name and password. Clients This section allows you to view all the devices that are connected through the Telstra 4GX USB Modem 2 .

  • Page 11: Messages

    Messages From the Home screen, select Messages. This screen displays a list of all messages in the Inbox, Outbox, and Draftbox associated with your service.

  • Page 12: Settings

    Settings Internet Mobile Connection • From the Home screen, select Settings > Internet > Mobile Connection. • You can choose the status of the Mobile Data and Data Roaming. • This screen displays information about the Carrier that provides your service. •...

  • Page 13: Wireless

    Wireless WLAN Settings If your terminal supports WPS, you do not have to input the password manually once your WPS has been set up. Push Button Connection (PBC) Using this method, the router will enter discovery mode. Set the device you want to connect to the same mode, this may be achieved by a physical button on your device or as a software button through your device menu.
  • Page 14 Wi-Fi • From the Home screen, select Settings > Wireless > WLAN Settings. • You can do the following in this section: • Enable/disable a band and its network. • Change the SSID. • Set the required Security Mode. • Change the Wi-Fi password.
  • Page 15 Changing the SSID & Password • From the Home screen, select Settings > Wireless > WLAN > Settings. You will see “Name(SSID)” and “Password”. Delete the old information you want to replace, and enter a new name and password. • Select the Apply button, wait for the screen to display Success, and then log out.

  • Page 16: Wlan Mac Filter

    WLAN MAC Filter • From the Home screen, select Settings > Wireless > WLAN MAC Filter. • This section allows you to include or exclude i.e. Whitelist or Blacklist devices based on their Wi-Fi MAC Address. • If you do not want to Whitelist or Blacklist a Wi-Fi MAC Address, set the Status to Disable.

  • Page 17: Network

    Network DHCP (Dynamic Host Configuration Protocol) • From the Home screen > select Settings > Network > DHCP. • In this section you can configure DHCP settings. The default inputs are: • DHCP Server: Enable • IP Address: 192.168.1.1 • DHCP IP Range: 192.168.1.2 to 192.168.1.200 (the IP pool is 200) •...

  • Page 18: Features

    Features Firewall • From the Home screen, select Settings > Features > Firewall. • This section allows you to enable firewall filter functions. • The IP address filter functions are available only if the firewall is enabled.
  • Page 19 IP Filter • From the Home screen, select Settings > Features > IP Filter. • This screen enables you to define IP addresses that should be filtered either Whitelisted or Blacklisted. • Once you select an option, a Success message will appear. •...

  • Page 20: Port Forwarding

    Port Forwarding • From the Home screen, select Settings > Features > Port Forwarding. • In this section, you can enable external devices to access FTP or other services provided by the LAN. • Click Add and enter the relevant details of the WAN and the LAN of the device.

  • Page 21: Dmz Settings

    DMZ Settings A DMZ is a De-Militarised Zone where both the external network (internet) and the internal network (Wi-Fi) can both access. This is an advanced feature and should only be modified after consulting your network administrator. • From the Home screen, select Settings > Features > DMZ Settings.

  • Page 22: Management

    Management SNTP (Simple Network Time Protocol) • From the Home screen, select Settings > Management > SNTP. • This screen allows you to enable auto-sync with network time which allows you to select multiple time servers and the time zone. •...

  • Page 23: Pin Management

    PIN Management • From the Home Screen, navigate to Settings > Management > PIN Management. • In this section, you can configure a PIN code to make your SIM more secure. • Set a PIN after choosing the Enable option for the PIN Operation.

  • Page 24: Device Information

    Device Information • From the Home screen, select Settings > Management > Device Information. • Device information like the device’s name, its hardware and software version, IMEI and IMSI number and its MAC address can be found in this section. In addition to this, the device's MCC, MNC, ICCID and PLMN number are listed under this section.

  • Page 25: Data Usage

    Data Usage This section displays the approximate data usage. Refer to the My Telstra app/website for the latest data usage. System Admin • From the Home screen, select Settings > Management > System Admin. • This screen allows you to change your username and password.
  • Page 26 Update • From the Home screen, select Settings > Management > Update. • This screen allows you to check for software/hardware updates and versions. • You can click Check for update to obtain the latest software updates, if available.

  • Page 27: Reboot & Reset

    Reboot & Reset • From the Home screen, select Settings > Management > Reboot & Reset. • This screen allows you to remotely reboot and reset the mobile hotspot. • Select Reboot to restart the device. • Click Reset to restore the original factory settings to the device.

  • Page 28: Logout

    Logout To logout of the device, select Logout from the menu options at the top. Select OK if you are sure you want to logout and Cancel if you want to wish to remain logged in.

  • Page 29: Troubleshooting Techniques

    Troubleshooting Techniques If you are having trouble with the device, here are a few troubleshooting tips: 1. If the device is not responsive, disconnect and reconnect it. Make sure that the device aligns well with the USB slot of your PC. 2.
  • Page 30 NOTE : The Factory Reset removes all the user-defined Wi-Fi settings in the device and restores Administrator and Wi-Fi Settings to factory default.

  • Page 31: Q&A

    Q&A Q1. What to do if there is no service? The possible reasons for this issue can be an unstable local signal or a hardware problem. You can try the following solutions: 1. If you are inside a building or near a structure that may be blocking the signal, change the position or location of the device.

  • Page 32: Product Specifications

    Product Specifications General Model Name O4H13 Display LED Indicator (Refer page 6 for more details) 2.4G Wi-Fi SSID 04H13-xxxx Usage This device is intended to give a laptop internet connectivity via USB connection. It can also connect upto 10 devices over the wireless access point it can emit.

  • Page 33: Wireless Communication

    Wireless Communication Warning! Data can occasionally be lost or delayed due to the transmission and reception properties of wireless communications. The data loss can be due to the variation in radio signal strength that results from changes in the characteristics of the radio transmission path.

  • Page 34: Safety Hazards

    Safety Hazards • Electronic devices are sensitive to Electromagnetic Interference (EMI) sent by your device if inadequately shielded. We recommend consulting the manufacturer of the device before using it, if necessary. For example, electronic systems of vehicles. • Operating your device may interfere with medical devices like hearing aids and pacemakers.
  • Page 35 authorised. Using any unauthorised accessories affects your device’s performance and violates related national regulations about telecommunication terminals. • Avoid using your device near or inside metallic structures or establishments that can emit electromagnetic waves; it may influence signal reception. • Your device is not waterproof.

  • Page 36: Caring For Your Device

    Caring for your device Like any electronic device, the device must be handled with care to ensure reliable operation. We recommend the following guidelines: • Protect the device from liquids, dust, and excessive temperatures. • Do not apply adhesive labels to the device; they might cause the device to potentially overheat, and they might alter the performance of the antenna.

  • Page 37: Cleaning And Maintenance

    Cleaning and Maintenance The Product is not waterproof. Do not use it in places with high humidity like a bathroom and also avoid spilling any liquids on it. Use a soft cloth to clean the Product. Do not use alcohol, diluted liquid, or benzene to clean the Product.

  • Page 38: Disposal Of Product And Batteries

    Disposal of Product Follow local regulations regarding the disposal of USB devices. In some areas, the disposal of this item in the household or business trash may be prohibited. Please check your local regulations for the correct method of disposal for the Product.
