Samsung HW-S8 B Series Repair Manual

Samsung HW-S8 B Series Repair Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Repair Guide
Basic Model
HW-S800B/ZA
Applicable Model
HW-S8**B*
Ver.1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HW-S8 B Series and is the answer not in the manual?

Questions and answers

Related Manuals for Samsung HW-S8 B Series

Summary of Contents for Samsung HW-S8 B Series

  • Page 1 Repair Guide Basic Model HW-S800B/ZA Applicable Model HW-S8**B* Ver.1.0...

  • Page 2: Table Of Contents

    Contents 1. Precautions 1-1. Safety Precautions ..........................1-1 1-1-1. Warnings ..........................1-1 1-1-2. Servicing the Product ......................1-1 1-1-3. Fire and Shock Hazard ......................1-1 1-1-4. Product Safety Notices ......................1-2 1-2. Servicing Precautions ........................1-3 1-2-1. General Servicing Precautions ...................1-3 1-3. Electrostatically Sensitive Devices (ESD) Precautions ..............1-4 1-4.
  • Page 3 Samsung- authorized service provider. Any damage or defect to product resulting from a repair, or an attempt to repair, the product by any person other than a Samsung certified service provider will not be covered by the warranty.
  • Page 4 Samsung’s liability in any case shall be limited to the greatest extent permitted by law. Samsung reserves the right, at its sole discretion, to change, modify, add or remove portions of any part of this manual at any time. It is your responsibility to check the manual periodically for changes. Your use of the manual...

  • Page 5: Precautions

    Precautions 1. Precautions 1-1. Safety Precautions • Follow these safety, servicing and ESD precautions to prevent damage and to protect against potential hazards such as electrical shock. 1-1-1. Warnings For continued safety, do not attempt to modify the circuit board. Disconnect the AC power and DC power jack before servicing.

  • Page 6: Product Safety Notices

    Precautions 6. Observe the original lead dress, especially near the following areas: Antenna wiring, sharp edges, and especially the AC and high voltage power supplies. Always inspect for pinched, out-of-place, or frayed wiring. Do not change the spacing between components and the printed circuit board. Check the AC power cord for damage. Make sure that no wires or components touch thermally hot parts.

  • Page 7: Servicing Precautions

    Following the repair by a non-authorised service provider, self-repair or non-professional repair of the product, Samsung is not liable for any damage to the product, any injury or any other product safety issue caused by any attempt to repair the product which does not carefully follow these repair and maintenance instructions.

  • Page 8: Electrostatically Sensitive Devices (Esd) Precautions

    Precautions 1-3. Electrostatically Sensitive Devices (ESD) Precautions Some semiconductor (solid state) devices can be easily damaged by static electricity. Such components are commonly called Electrostatically Sensitive Devices (ESD). Examples of typical ESD are integrated circuits and some field-effect transistors. The following techniques will reduce the incidence of component damage caused by static electricity.

  • Page 9: Installation Precautions

    Precautions 1-4. Installation Precautions 1. For safety reasons, more than a people are required for carrying the product. 2. Keep the power cord away from any heat emitting devices, as a melted covering may cause fire or electric shock. 3. Do not place the product in areas with poor ventilation such as a bookshelf or closet. The increased internal temperature may cause fire.

  • Page 10: Disassembly And Assembly

    Disassembly and Reassemble 2. Disassembly and Assembly • As this product has parts that are sensitive to static electricity, be careful when handling them. Warning 2-1. Disassembly • Disconnect the product from the power source before disassembly. • Follow these directions carefully; never use metal instruments to pry apart the cabinet. •...

  • Page 11: Remove Main Pcb

    Disassembly and Reassemble 2-1-2. Remove Main PCB • Detach 4 cables. Remark • Unfasten 4 screws . Remark - P/N:6003-001438 • Detach 2 cables. Remark 2-1-3. Remove Wireless module • Remove a screw. Remark • Remove a screw. Remark - P/N:6003-001561...

  • Page 12: Remove Amp Pcb

    Disassembly and Reassemble 2-1-4. Remove AMP PCB • Detach 2 cables. Remark • Unfasten 8 screws. Remark - P/N:6003-001438 • Detach 2 cables. Remark 2-1-5. Remove WIFI/BT module • Remove a screw and a cable. Remark - P/N:6003-001438 • Separate the WIFI/BT module.

  • Page 13: Remove A Led/Ir Board

    Disassembly and Reassemble 2-1-6. Remove a Led/IR board • Unfasten 8 screws. Remark - P/N:6003-001438 • Separate the LED/IR board. Remark 2-1-7. Remove Touch sheet • Remove 4 screws. Remark - P/N:6003-001438 • Remove 4 screws. Remark - P/N:6003-001438 • Separate Touch sheet. Remark It will be impossible to reuse touch sheet once it is separated...

  • Page 14: Assembly

    Disassembly and Reassemble 2-2. Assembly • Please assemble in reverse order of disassembly steps. • The exterior may differ depending on the product. Note 1. If foot rubber has been detached from Assy cover P-Rear, new foot rubber must be used when assembling.
