INFINITY LIVING AIR HANDLER & SINGLE-ZONE CONDENSER
WITH DIYCOOL TECHNOLOGY
SERVICE MANUAL
Models Covered:
EZ-12WPL-HP115
EZ-18W-M*
EZ-24W-M*
EZ-36W-M*
EZ-12ZPL-HP115
EZ-18ZPL-HP230
EZ-24ZPL-HP230
EZ-36ZPL-HP230
*This manual also includes service information for 18K-36K air handlers used in Infinity Living multi-zone systems
with DIYCOOL technology. For 9K (EZ-09W-M) & 12K (EZ-12W-M) multi-zone air handler service information, please
refer to the separate manual specifically for them.
VERSION DATE: 05-13-24
