- Page 1 HD - TVI Camera Quick Guide...
- Page 2 The lightning flash with an arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
-
Page 3: Table Of Contents
Contents Contents General Features Precautions Safety Instructions How to set up the camera menu ▶ Set Up Menu Menu Set Up ▶ ▶ Lens ▶ Exposure White Bal ▶ Backlight ▶ ▶ Day & Night ▶ Image ▶ Motion ▶ System ▶... -
Page 4: General Features
General Features ▣ Transfer Video Interface The combination of a 2MP CMOS image sensor and TVI DSP provides an excellent resolution of TVI picture. ▣ 3D-DNR Smart 3DNR prevents the image blurring of moving object and activates only if moving objects are appearing on the scene. ▣... -
Page 5: Precautions
Precautions Do not install the camera in Do not install or use the camera in an Do not install the camera under extreme temperature environment where the humidity is unstable lighting conditions. conditions. high. Do not install or use the camera in Severe lighting change or flicker Only use the camera under an environment where the... -
Page 6: Safety Instructions
Safety Instructions ▣ Precaution for use This camera should be installed by qualified personnel only There are no user serviceable parts inside Do not disassemble this camera other than to make initial adjustments Use appropriate low voltage power cable to prevent fire or electrical shock Please insure that your installation area can support the weight of the camera ▣... -
Page 7: How To Set Up The Camera Menu
How to set up the camera menu ▣ set up menu www.costarvideo.com... - Page 8 How to set up the camera menu ▣ set up menu www.costarvideo.com...
-
Page 9: Menu Set Up
Menu set up Menu setting can be selected by the button inside the camera. 1. Press the set button. * The Set Up menu will be displayed on the monitor. 2. Move and select the required function using the Up and Down button. 3. -
Page 10: Lens
4. After Changing the setting , move to EXIT and press the SET button to EXIT. NOTE * Move to the available submenu by moving arrow to desired feature. LENS 1. On the Set Up menu, Select LENS by using the Up or Down button. 2. -
Page 11: Exposure
EXPOSURE 1. On the Set Up menu, Select EXPOSURE by using the Up or Down button. 2. Press the SET button to access the sub-menu items listed below. BRIGHTNESS ◆ BRIGHTNESS : The brightness can be adjusted. The brightness control range is 1~20. ◆... -
Page 12: White Bal
◆ SENSE-UP : The bright screen can be displayed by sensing the degree of the darkness automatically under the circumstance of low light condition or at night. à Off ~x32 Level Adjustable. ◆ AGC (Auto Gain Control) : The higher the AGC level is, the more noises appear. à... - Page 13 ◆ MANUAL : Manual compensation make the more detailed control possible. First, after adjusting the white balance using the ATW or AWB mode, change the mode into the manual compensation mode and then press Set button. While looking at the color change of the subject seen on the screen after setting up the proper color temperature, increase the each value of the blue and the red.
-
Page 14: Backlight
BACKLIGHT On this menu, backlight image can be compensated by users selecting one of modes. (HLC, BLC, WDR) 1. Move to BACKLIGHT on the SETUP menu screen using the Up and Down button. 2. Select the desired mode by using the left or Right button. ◆... - Page 15 ◆ BLC : This function is used to counterbalance the screen image by increasing the brightness so that a subject which appears dark due to a strong backlight can be displayed in more detail. If you select BLC, a submenu appears where you can make finer adjustments.
-
Page 16: Dnr
This function is used to improve the picture quality by filtering the noise which is generated under low brightness conditions. You can set different levels here. 1. Move to DNR by using the Up and Down button. 2. Select the desired mode to use by pressing the left or Right button and LOW/MIDDLE/HIGH level selectable. - Page 17 ◆ AUTO : Automatically, It shifts into the color mode in the bright environment and the B/W mode in the low light condition. It can adjust the delay time, starting brightness and end brightness according to the ambient conditions by pressing the Set button. SMART IR - SMART IR : 0~20 smart IR level adjustable.
-
Page 18: Image
SMART IR - EXTERN S/W [LOW/HIGH] : Set the external signal for switching between COLOR and B/W. - DELAY [LOW/MIDDLE/HIGH] : Set the delay time for switching between color and B/W . IMAGE When selecting, the following submenu will appear. - 18 - www.costarvideo.com... - Page 19 Here you can optimize the image quality by adjusting different options. SHARPNESS - SHARPNESS [1 ~ 20] : Adjusts the image sharpness. If the level goes up excessively, it may affect the video image and generate a noise. - GAMMA [0.45 ~ 0.65] : Changes the gamma curve of the camera. - COLOR GAIN [0 ~ 20] : Changes the color gain of the camera.
- Page 20 ◆ PRIVACY [ON, OFF] : This is used to hide certain areas on the monitor. You can designate each different 16 area. The size of a designated area can be adjusted. The color of a privacy area can be selected various colors.
-
Page 21: Motion
MOTION This function is used to detect moving objects in the monitored area. When choosing ON, the following submenu will appear where you can adjust the settings for the MOTION function. SENSITIVITY SENSITIVITY [0~20] : The higher the setting value is, the higher the sensitivity gets, even though the movement of a subject. -
Page 22: System
- DET H-POS [0~60] : Define the horizontal start position of the monitoring area. - DET V-POS [0~34] : Define the vertical start position of the monitoring area. - DET H-SIZE [0~60] : Define the horizontal size of the monitoring area. - DET V-SIZE [0~34] : Define the vertical size of the monitoring area. -
Page 23: Exit
- COM. : This menu id used for RS-485 communication. Users are able to select CAM ID(0~255) and BAUD RATE (2400/4800/9600/57600/115200). - IMAGE RANGE [FULL/COMP/USER] : Adjust the rate of YC signal to 100%(FULL), 75%(COMP) or 100%~75%(USER). - OUTPUT MODE [720P/1080P] : Choose output type. - COLOR SPACE [YUV/SD-CBCR/HD-CBCR] : Select different color settings for a warmer or a colder image. -
Page 24: Specifications
Specifications - 24 - www.costarvideo.com... -
Page 25: Trouble Shooting
Trouble Shooting - 25 - www.costarvideo.com... - Page 26 - MEMO - - 26 - www.costarvideo.com...
