- Page 1 Remote Control Switch Installation and user manual HYDRONIC RSCH REMOTE CONTROL SWITCH This product is only for use with Smith’s SS3, 5, 7 and 9 Space Saver products Issue 002 | November 2024 ENGLISH | UK | IRL | SmithsEP.co.uk Issue 002 - November 2024 | SmithsEP.co.uk | 1...
-
Page 2: Table Of Contents
Contents Introduction Introduction This accessory kit has been designed to easily convert a Smiths Space Saver from unit switching Warning to remote switching providing normal, boost and off selection. Control Switch The accessory kit comes supplied with easy fit Space Saver connectors and a 3m length of power cord. -
Page 3: Control Switch
Control Switch 1. Locate a suitable position adjacent to the Space Saver unit that will allow connection to the 3 metre power cord (supplied). Note: This must be away from water or high humidity. 2. Fix the switch mounting box to suit the required type of installation. Connect the power cord to the remote switch as shown below. -
Page 4: Space Saver
Space Saver Important: If the Space Saver unit is already installed please disconnect or isolate from the electrical supply. 1. Remove the lid fixing screws and remove the lid of the Space Saver unit 2. Push the power cord complete with cable gland from the control switch into the Space Saver chassis in the hole provided adjacent to the earth terminal (see diagram). -
Page 5: Operation
6. Next remove the earth wire (yellow / green) from the chassis tab, fit the earth wire to connector on the incoming lead and securely fix back into place on the chassis earth tab. See diagram below. BLUE BROWN GREY BLACK GREEN 7. -
Page 6: Registering Your Product
Registering your product Disposal As part of the policy of continuous product Thank you for purchasing a Smith’s product. It has improvement, Smith’s Environmental Products LTD been designed and manufactured to the highest reserves the right to alter specification without quality standards to ensure it gives you efficient prior notice. -
Page 7: After Sales And Spares
After sales and spares If you experience any problems with the use of your product, please contact our after-sales office +44 (0) 1245 324560. For product information, customer services or sales support call us on +44 (0) 1245 324900 For the Republic of Ireland, contact MT Agencies on 01 864 3363 Sales: sales@SmithsEP.co.uk General information: info@SmithsEP.co.uk... - Page 8 Happy to help To view the full product information download the datasheet at: Smith’s Environmental Products Ltd is one of the leading manufacturers of heating and cooling www.SmithsEP.co.uk products in the UK. We are committed to achieving the highest standards and our faith is For product information, customer services or supported by a free parts and labour guarantee sales support call us on +44 (0) 1245 324900...
