- Page 1 ADVANCED SAFETY VISION SYSTEMS AVM10S 10" HEAVY DUTY QUAD VIEW WIRELESS SMART AI MONITOR USER MANUAL USER MANUAL 24-09-2024...
-
Page 2: Table Of Contents
ADVANCED SAFETY VISION SYSTEMS Contents Introduction................1 Product installation ..............2 Home screen................3 System settings icons.............4 System settings...............5 Audio output settings ( Speaker ) ..........12 Audio output settings ( FM transmitter )........12 Audio output settings (CarPlay & Android Auto)....12 Connecting via Apple CarPlay..........13 Connecting via Android Auto..........14 Bluetooth music..............15... -
Page 3: Introduction
Bluetooth & WiFi, you can effortlessly sync your smartphone to the AVM10S, and enjoy audio playback using a variety of options such as the FM transmitter function using your car's sound system. You can even utilise the inbuilt speaker. Plus, for added convenience and safety, this exceptional device is able to input up to 4 reverse cameras (sold separately). -
Page 4: Product Installation
ADVANCED SAFETY VISION SYSTEMS Product installation 1. Fix the monitor to a flat surface using the adhesive base. Making sure it is safely away from the steering wheel. 2. The monitor is hardwired to the vehicle using 12-24V constant , accessory and ground connections. -
Page 5: Home Screen
ADVANCED SAFETY VISION SYSTEMS Home screen 1. Fix the monitor to a flat surface using the adhesive base. Making sure it is safely away from the steering wheel. 1. Volume control 2. Brightness control 3. Screen display On/Off 4. Smartphone connection: CarPlay/Android Auto/Bluetooth 5. -
Page 6: System Settings Icons
ADVANCED SAFETY VISION SYSTEMS System settings icons Select the Setting icon on screen you want to enter, then press the screen again to select the setting options. -
Page 7: System Settings
ADVANCED SAFETY VISION SYSTEMS System settings Carplay position - This changes the viewing position of the CarPlay screen. Camera format - This changes the input resolution of the camera connected to the monitor. All cameras attached must be the same resolution, you cannot mix different camera resolutions. - Page 8 ADVANCED SAFETY VISION SYSTEMS System settings cont..Lapse record - A sequence of pictures captured then compiled into a video when in parking record mode. Parking time - This setting allows for a set time of recording while the car is in Parking record mode.
- Page 9 ADVANCED SAFETY VISION SYSTEMS System settings cont..Screen saver - Set the amount of time the screen displays before turning off. Setting Guideline - Manually the user can change /align the guidelines displayed on screen. Move the guidelines by re-positioning the X / Left & Right arrows. Turn the guidelines On / OFF.
- Page 10 ADVANCED SAFETY VISION SYSTEMS System settings cont..Channel delay - How long the screen stays on once triggered in reverse. Language - Select from multiple languages to suit your requirements. Time Setting - Set the Time/Day/Month/Year and Zone settings.
- Page 11 ADVANCED SAFETY VISION SYSTEMS System settings cont..Date Format - Set the date format configuration. Pedestrian detection - The user gets a visible alert, with a red rectangle around the detected pedestrian. Pedestrian detection alarm - The user gets an audible alert warning of the detected pedestrian.
- Page 12 ADVANCED SAFETY VISION SYSTEMS System settings cont..Blind zone calibration - Allows the user to adjust the area for detection. This can be done for each camera. Select the cameras icon on the left to adjust the detection area. Select the circle to the right to turn the detection On / Off. Audible and visual alarm - This function is in development and not currently used.
- Page 13 ADVANCED SAFETY VISION SYSTEMS System settings cont..Reset factory - Select to restore the monitor to original factory settings. Version - Displays the current software/firmware version...
-
Page 14: Audio Output Settings ( Speaker )
ADVANCED SAFETY VISION SYSTEMS Audio output settings (Monitor speaker) Use the internal speaker to output audio from the monitor. 1. Tap the Audio Output icon on the home screen and select the Speaker icon along the bottom. NOTE: In this mode, you can adjust the volume by pressing the speaker icon along the side on the home screen. -
Page 15: Connecting Via Apple Carplay
3. Before using Apple CarPlay wirelessly, turn on the Bluetooth and WiFi function on the compatible device. 4. Navigate to the Bluetooth settings on your compatible device and select AVM10S followed by some numbers and letters for pairing. 5. A pair message and a pairing request code may appear on your compatible device and head unit. -
Page 16: Connecting Via Android Auto
3. Before using Android Auto wirelessly, turn on the Bluetooth and WiFi function on the compatible device. 4. Navigate to the Bluetooth settings on your compatible device and select AVM10S followed by some numbers and letters for pairing. 5. A pair message and a pairing request code may appear on your compatible device. Click allow to accept. -
Page 17: Bluetooth Music
4. Here you will be able to see and edit the Bluetooth device name. The default name is typically AVM10S followed by a string of numbers and letters. You can turn the Bluetooth On/Off, see if a device is currently paired, unpair the current device or disable bluetooth auto-connect. -
Page 18: Connecting A Camera
ADVANCED SAFETY VISION SYSTEMS Connecting a camera The AVM10S Wireless Smart Ai Monitor supports up to 4 cameras with quad view display. Cameras sold separately. Visit our website for compatibility. All cameras connected must be of the same resolution, 720P or 1080P. -
Page 19: Specifications
• Power Supply: 11-36V (Hardwired) • Dimensions (WxHxD): • Monitor: 245 x 98 x 32mm (Excluding Mount) Inclusions: • 10" IPS monitor AVM10S • 1 x Monitor Mount • 1 x 1.5m Monitor Cable Additional Information: • This is a monitor only, cameras are sold separately. -
Page 20: Technical Assistance
ADVANCED SAFETY VISION SYSTEMS Technical assistance If you need assistance setting up or using your Aerpro product now or in the future, call Aerpro Support. Australia TEL: 03 – 8587 8898 FAX: 03 – 8587 8866 Mon-Fri 9am – 5pm AEST or EMAIL: service@tdj.com.au If you would like to download a digital copy of this manual, or other Aerpro manuals/software, please visit the Aerpro.com website and search for the product...
