Leakwise PS-220 User Manual

Any id-220 sensor analog controller
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
LEAKWISE
®
Oil on Water Detection & Monitoring
ID-220 SERIES MODEL
PS-220
Analog Leakwise Controller
Connected to
Any ID-220 Sensor
USER GUIDE
Rev. 8
November 2017
With Rev. D1 Main Board

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PS-220 and is the answer not in the manual?

Questions and answers

Related Manuals for Leakwise PS-220

Summary of Contents for Leakwise PS-220

  • Page 1 LEAKWISE ® Oil on Water Detection & Monitoring ID-220 SERIES MODEL PS-220 Analog Leakwise Controller Connected to Any ID-220 Sensor USER GUIDE Rev. 8 November 2017 With Rev. D1 Main Board...
  • Page 2 PS-220 RD1 USER GUIDE Revision 8 November 2017...

  • Page 3: Important Notes For Using A Leakwise System

    Important notes for using a Leakwise system • Refer to the relevant Sensor User Guide for specific information about sensor certification, installation and operation. • Consider the following during operation: Beware of high voltage 110 or 220 ±5% VAC inside the enclosure of the controller unit! Only qualified personnel may service the System.
  • Page 4 PS-220 RD1 USER GUIDE Revision 8 November 2017...

  • Page 5: Table Of Contents

    Contents Important notes for using a Leakwise system ............... 3 Warnings ..........................7 English ..........................7 Français ........................... 8 System Description ......................9 Installation and Wiring ....................11 Maximum Cable Length between Sensor and PS-220 ..........13 Laboratory Calibration and Tests ..................15 Typical Signals of Leakwise Sensors ................16...
  • Page 6 PS-220 RD1 USER GUIDE Revision 8 November 2017...

  • Page 7: Warnings

    Leakwise sensors are floating devices. The installation must allow their free floatation and avoid submergence. Leakwise sensors are delicate instruments. Handle with care! Do not drop. Avoid damages to the cable/s during installation and operation, as this will void the IP67 sealing.

  • Page 8: Français

    Les détecteur Leakwise sont des dispositifs flottants. L'installation doit permettre leur flotation libre et éviter toute submersion. Les détecteur Leakwise sont des instruments délicats a manipuler avec soin! Ne pas lacher! Tout dommage créé au câble/s lors de l'installation et de l’utilisation, annulerait automatiquement l'étanchéité...

  • Page 9: System Description

    PS-220. The PS-220 signal processor is housed in a NEMA 4 (IP65) weather-proof or NEMA 7 or Exd Ex- proof enclosure, and powered by either 110 VAC or 220 VAC or 24 VDC or 12 VDC, at choice.
  • Page 10 PS-220 RD1 USER GUIDE Revision 8 November 2017...

  • Page 11: Installation And Wiring

    SENSOR CABLE CAN BE EXTENDED THROUGH AN IP65 JUNCTION BOX. REFER TO DETAILS IN THE NEXT SECTION. Pass a power cable through the conduit from PS-220 to the local power source. Option: Pass the appropriate cable via the conduit between PS-220 and the central control room or remote controlled equipment.
  • Page 12 PS-220. BEWARE OF HIGH VOLTAGE 110 or 220VAC INSIDE ENCLOSURE! Turn power on. AIR / HIGH OIL light on the PS-220 should be on. If FAIL / DETECTOR DISCONNECTED light is on, refer to Section 5. Install the sensor properly in the sump. If there is water, WATER light on the PS-220 should be on.

  • Page 13: Maximum Cable Length Between Sensor And Ps-220

    Maximum Cable Length between Sensor and PS-220 The integral cable supplied with the sensor can be extended with another cable after a connection inside an IP65 junction box. ID-221 and all ID-223 sensors: 1. For Gas Group IIC hazardous area (Hydrogen): 150 meters maximum if 20 AWG wires (or thicker wires) are used.
  • Page 14 Select such a cable from a catalog or test its capacitance and inductance. A shielded cable is not required in most cases. Zener Safety Barriers for installation in hazardous area: Note: MTL 715+ and 710+ are obsolete. Use MTL 7715+ and 7710+. PS-220 RD1 USER GUIDE Revision 8 November 2017...

  • Page 15: Laboratory Calibration And Tests

    Laboratory Calibration and Tests Laboratory Calibration is a basic adjustment procedure to ensure correct operation of the system. Laboratory Calibration is carried out while the PS-220 enclosure is open, by adjusting the potentiometers inside. This procedure should be performed either as the next step after installation, when fast field calibration cannot be performed, or when trouble is suspected in the system.

  • Page 16: Typical Signals Of Leakwise Sensors

    Typical Signals of Leakwise Sensors Each Leakwise sensor has a cable with three wires named: DET+, DET-, DET Sig. DET+ : +12VDC supply in reference to DET-. Supplied current is the sum of the currents through the other two wires.
  • Page 17 Water / Oil Set Point. A larger distance means detection of a thicker oil layer (less sensitivity). 4. Oil / Air Set Point can be set as an Air indication threshold or as a Second Oil Alarm threshold. For Air indication set TP5 to 0.5V. PS-220 RD1 USER GUIDE Revision 8 November 2017...

  • Page 18: Laboratory Calibration Procedure

    Laboratory Calibration Procedure Calibration is carried out on the main board of PS-220 inside the open enclosure. All voltages measured in PS-220 board are DC. The negative probe of voltmeter is connected to TP2 (GND). NOTE: TP3 and TP4 measure the same signal, but TP4 is located after an additional buffer.
  • Page 19 • Sensor in the air: AIR / HIGH OIL light on. • Sensor in water: WATER light on. • Sensor in water with an oil layer of 2mm (or a different thickness to which the Sensor was calibrated): OIL light on PS-220 RD1 USER GUIDE Revision 8 November 2017...

  • Page 20: Calibration Procedure For Optional 4-20Ma Output And Bar-Graph

    Calibration Procedure for OPTIONAL 4-20mA OUTPUT and BAR-GRAPH This procedure should be implemented after calibration of PS-220 main board. All adjustments are performed on the accessory board with open enclosure. The accessory board is mounted on the backside of the front panel.
  • Page 21 The 4-20mA output can be wired to the control room through the contacts of the Fail relay. During a failure, the control room will receive 0 mA as an indication of the failure. PS-220 RD1 USER GUIDE Revision 8 November 2017...
  • Page 22 PS-220 RD1 USER GUIDE Revision 8 November 2017...

  • Page 23: Field Calibration

    Field Calibration Turn power on. One of the indicating lights on the front panel of PS-220 should turn on, and the FAIL / DETECTOR DISCONNECTED light should be off. The System has been pre-calibrated at the factory. The following is a fast field calibration procedure for small on-site adjustments. If only an oil detection sensitivity change is desired, refer directly to Paragraph 5.1.3.
  • Page 24 (For some demo units only: R2 is the calibration screw located next to AIR / HIGH OIL light). If AIR / HIGH OIL light is on: Turn R2 counter-clockwise till OIL light turns on and then slightly clockwise till AIR / HIGH OIL light turns on. PS-220 RD1 USER GUIDE Revision 8 November 2017...

  • Page 25: Built-In Test

    To check the PS-220, push TEST button for a few seconds, then release. The PS-220 will receive a ramping test signal instead of real sensor signal, and the indicating lights will turn on consecutively: AIR / HIGH OIL, OIL, then WATER.
  • Page 26 PS-220 RD1 USER GUIDE Revision 8 November 2017...

  • Page 27: Problems And Solutions (Troubleshooting)

    System is not calibrated. Re-calibrate. Refer to Section 4. Improper voltage to Check voltage between Sensor. points 1 and 2 of TB6, which should be within the range 11.5-12.5 VDC. Otherwise, consult factory. PS-220 RD1 USER GUIDE Revision 8 November 2017...
  • Page 28 Check wiring (refer to output. PS-220 enclosure is wiring diagram). loose. Re-connect loose wire. Blown fuse F1. Replace fuse. Remote recorder does not Load is higher than 400 Reduce load. receive 20mA. ohms. PS-220 RD1 USER GUIDE Revision 8 November 2017...

  • Page 29: Additional Information

    If such a problem is experienced with low power AC loads, the solution is to remove (un-solder) these capacitors from the Main board. The capacitors are located between the relays and TB2, and are marked C8, C9, C18, C19. PS-220 RD1 USER GUIDE Revision 8 November 2017...
  • Page 30 PS-220 RD1 USER GUIDE Revision 8 November 2017...

  • Page 31: Appendix A: Ps-220 Options

    Optional Audio Alarm (Ex-proof available) Operating Power, 6 VA consumption • /12 VDC • /24 VDC • /110 VAC • /220 VAC Other • /CEN/ Set of Zener Safety Barriers for Hazardous Area installation PS-220 RD1 USER GUIDE Revision 8 November 2017...

  • Page 32: Appendix B: Installation In Hazardous Area

    Appendix B: Installation in Hazardous Area PS-220 RD1 USER GUIDE Revision 8 November 2017...
  • Page 33 PS-220 RD1 USER GUIDE Revision 8 November 2017...
  • Page 34 PS-220 RD1 USER GUIDE Revision 8 November 2017...

  • Page 35: Appendix C: Ferrites For Emc Compatibility

    NOTE: Addition ferrite/s should be installed closer to the sensor – Refer to Sensor User Guide. Ferrite type: Laird 28A5131-0A2 Qty: 1 Number of turns (as seen inside the ferrite core): 4 PS-220 RD1 USER GUIDE Revision 8 November 2017...

  • Page 36: 10. Appendix D: Ps-220 Drawings

    10. Appendix D: PS-220 Drawings PS-220 RD1 USER GUIDE Revision 8 November 2017...
  • Page 39 CONTAINS INTRINSICALLY SAFE CIRCUITS Air/ High Oil DETECTOR DISCONNECTED Water TEST OPTIONAL BAR-GRAPH MATERIAL: TOLERANCES UNLESS NAME DATE USED ON: PS-220/Exd CORTEM CAT. No.: OTHERWISE SPECIFIED GUB-03V* LINEAR DESIGN H. KOREN 02/07/17 FINISH: ANGULAR 02/07/17 DRAWN H. KOREN TREATMENT: TITLE:...
  • Page 41 GE Analytical Instruments Ionics Agar Environmental Ltd. AIR / SETTING APPROVED BY: S. DAVID LIGHT HIGH OIL Title PS-220 Rev. D1 Wiring Diagram for 110 / 220VAC LIGHT RED LED YELLOW LED CHECKED BY: S. DAVID Size Document Number R e v...
  • Page 42 RY1 & RY2: OMRON G2RL-24 24VDC; RY3: OMRON G2RL-14 12VDC Title 230VAC: Short B to C only. PS-220 Rev.D1 Main Board, 115 / 230 VAC Powered NOTE 2: TRIMMERS R2 AND R5 MAY BE INSTALLED OFF BOARD, ON A PANEL. CHECKED BY: S.
  • Page 43 GE Analytical Instruments Ionics Agar Environmental Ltd. AIR / SETTING APPROVED BY: S. DAVID LIGHT HIGH OIL Title PS-220 Rev. D1 Wiring Diagram for 12 to 24VDC LIGHT RED LED YELLOW LED CHECKED BY: S. DAVID Size Document Number R e v...
  • Page 44 RY1 & RY2: OMRON G2RL-24 12VDC; RY3: OMRON G2RL-14 12VDC Title AC Transformer not installed. PS-220 Rev.D1 Main Board, 12 VDC to 24 VDC Powered NOTE 2: TRIMMERS R2 AND R5 MAY BE INSTALLED OFF BOARD, ON A PANEL. CHECKED BY: S.
  • Page 45 LM339N Green LED GE Analytical Instruments Ionics Agar Environmental Ltd. 0.1uF APPROVED BY: S. DAVID Title BUILT IN TEST BOARD for PS-220 Rev. Dx 2.2K CHECKED BY: S. DAVID Size Document Number R e v DWGS PSX 004 3 DRAWING BY: S.
  • Page 47 LOAD #3 will be activated whenever AIR/HIGH OIL light is on. FAIL indication will be activated whenever FAIL light is off or PS-220 power is interrupted. Relays RY1 & RY2 have "dry" contacts rated 4 Amp. at 30VDC and 250VAC. RY3 is rated 3 Amp.
