Summary of Contents for CORBERO E-CF2PM145W
- Page 1 FRIGORÍFICO 2 PUERTAS MANUAL DEL USUARIO E-CF2PM145W E-CF2PM145X...
- Page 3 Advertencia : riesgo de fuego/materiales in amables Este el cable de alimentación está dañado, debe ser reemplazado por el fabricante, su agente de servicio o personas con c caciones similares para evitar un peligro. almacene sustancias explosivas como latas de aerosol con un carburante ste aparato.
- Page 4 Para EN estándar: o por falta de experiencia y conocimiento si se les ha dado supervisión o involucrados. Los niños no deben jugar con el aparato. La limpieza y el mantenimiento del usuario no deben ser realizados por niños sin supervisión. Los niños de 3 a 8 años de edad pueden cargar y descargar aparatos de refrigeración.
- Page 11 Estantes de acero Termostato Bandeja Estante de vidrio Cubierta de Caja de frutas y verduras Caja de frutas y verduras Pie ajustable...
- Page 12 El polvo detrás del refrigerador y en el suelo deben limpiarse oportunamente para mejorar el efecto de enfriamiento y el ahorro de energía. Revise la junta de la puerta con regularidad para asegurarse de que no haya residuos. Limpie la junta de la puerta con un paño suave humedecido con agua jabonosa o detergente diluido.
- Page 16 16 °C y 38 °C"; Tropical: "este aparato de refrigeración está diseñado para usarse a temperatura ambiente que varía entre 16 °C y 43 °C". Las piezas pedidas en la siguiente tabla se pueden adquirir del canal CORBERO: Pieza pedida Proporcionada por Tiempo mínimo requerido para la provisión...
- Page 17 Corbero CF2PM145W / CF2PM145X 176kWh / year 163L Defrost 2kg/24h N/ST 40dB 550x550x1430mm AC220V-240V 0.5A...
- Page 18 REFRIGERATOR USER MANUAL E-CF2PM145W E-CF2PM145X...
-
Page 19: Table Of Contents
www.midea.com Contents SAFETY WARNINGS ......................1 INSTALLTION ........................3 Location ........................3 Reversing the Door Swing（optionnal） ..............3 Door Handle Install Illumination (optional) ............... 7 Door Space Requirements ..................7 Levelling the Unit ....................... 8 Cleaning Before Use ....................8 Before Using Your Unit .................... -
Page 20: Safety Warnings
1. SAFETY WARNINGS Warning : risk of fire / flammable materials THIS appliance is intended to be used in household and similar applications such as staff kitchen areas in shops, offices and other working environments; farm houses and by clients in hotels, motels and other residential type environments;... - Page 21 flammable. Therefore, when the appliance is scrapped, it shall be kept away from any fire source and be recovered by a special recovering company with corresponding qualification other than be disposed by combustion, so as to prevent damage to the environment or any other harm. FOR EN standard: This appliance can be used by children aged from 8 years and above and persons with reduce physical sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way...
-
Page 22: Installtion
2. INSTALLTION 2.1 Location When selecting a position for your unit you should make sure the floor is flat and firm, and the room is well ventilated. Avoid locating your unit near a heat source, e.g. cooker, boiler or radiator. Also avoid direct sunlight as it may increase the electrical consumption. - Page 23 2) Remove the screws fixed the top-hinge with cross-slot screwdriver. 3) Replace the top-hinge and the top-door limit block and the door bearing bush to the other side. Remove the nut with sleeve.Take off the washer then remove the axes to the other side and fixed.
- Page 24 5) Replace the bottom door bearing bush and the limit block. 6) Replace the bottom hinge to the other side then fix it with screws 7) Replace the mid-hinge. 8) Set the bottom door right position,fix the mid-hinge.
- Page 25 9) Replace the top-hinge. 10) Set the top door right position,fix the top-hinge and the cover. 11) Install the four screw caps and two catches to corresponding position. ·Ensure the Appliance is unplugged and empty. ·Adjust the two leveling feet to their highest position. ·We recommend you have someone to assist you.
-
Page 26: Door Handle Install Illumination (Optional)
2.3 Door Handle Install Illumination (optional) Note: Figures in the user manual are only for reference. The actual product may differ slightly. The refrigerator must be disconnected from the source of electrical supply before attempting the installation of accessory. Step 1: take out two plug pins from the door (Side of door open) Step 2: Install the door handle to the door and fasten it with screws Step 3: Cover screw caps of the handle into screw holes *The picture above is only for reference. -
Page 27: Levelling The Unit
Levelling the Unit To do this adjust the two levelling feet at the front of the unit. If the unit is not level, the door and magnetic seal alignments will not be covered properly. Make sure that the foot touches the ground before use. Look down from the top, clockwise and counterclockwise loosening, tightening. -
Page 28: Product Overview
You should always slide one of the full size glass storage shelves into the lowest set of guides, above the fruit and vegetable containers, and keep it in this position. To do this, pull the storage shelf forward until it can be swivelled upwards or downwards and removed. -
Page 29: Operation
4. OPERATION 4.1 Switching On Your Unit Setting“Off” ：UnitOff Setting“Min” ：Less Cool Temperature Setting“Med” or “MID” ：Normal Operation(adequate for most situations) Setting“Max” ：Coolest Temperature ◆During high ambient temperatures e.g. on hot summer days. It may be necessary to set the thermostat to the Coolest setting(position“Max”).This may cause the compressor running continuously in order to maintain a low temperature in the cabinet. -
Page 30: Cleaning
5. CLEANING Defrosting NOTE THIS UNIT DOES NOT HAVE AN AUTO DEFROST SYSTEM. Please use a plastic ice shovel when clearing the frosting of the evaporator. Do not use metal sharp objects. 5.2 Cleaning the Interior and the Exterior of the Unit ... -
Page 31: Care When Handling / Moving Your Unit
6.2 Care When Handling / Moving Your Unit Hold the unit around its sides or base when moving it. Under no circumstances should it be lifted by holding the edges of the top surface. 6.3 Servicing The unit should be serviced by an authorized engineer and only genuine spare parts should be used. -
Page 32: For Energy Saving
8. FOR ENERGY SAVING Warning for energy 1)Refrigerating appliances might not operate consistently (possibility of defrosting of contents or temperature becoming too warm in the frozen food compartment) when sited for an extended period of time below the cold end of the range of temperatures for which the refrigerating appliance is designed. -
Page 33: Disposal
9. DISPOSAL Old units still have some residual value. An environmentally friendly method of disposal will ensure that valuable raw materials can be recovered and used again. The refrigerant used in your unit and insulation materials require special disposal procedures. Ensure that none of the pipes on the back of the unit are damaged prior to disposal. - Page 35 Equipment(WEEE), the waste WEEE must be collected and treated separately. If in the future you need to dispose of this product DO NOT put it with household waste, send it to the WEEE collec�on points if they exits. Corbero CF2PM145W / CF2PM145X 176kWh / year 163L...
-
Page 36: Certificado De Garantía
CERTIFICADO DE GARANTÍA Imprescindible la presentación de la factura de compra acompañada del presente certi cado de garantía. Riesgos cubiertos. Este aparato está garantizado contra cualquier defecto de funcionamiento, siempre que se destine a uso doméstico, procediéndose a su reparación dentro del plazo de garantía y sólo por la red de SAT autorizados. Excepciones de garantía.
