PANEL-PC-15-A
Quick Installation Guide
SKU: SA-PanelPC-15-00-00
Address of the manufacturer:
SALZ Automation GmbH
Bad Salzu en, Germany
Email: support@salz-automation.com
Please scan for more information:
1. Overview
Panel-PC-15-A is a 15" industrial panel pc with a capacitive 4:3 TFT LCD touchscreen,
1024 x 768 pixels and pre-installed Automation Browser. Power Supply 24V DC.
2. Package Checklist
◦Panel-PC-15-A x 1
◦Mounting Brackets
◦User Manual
◦Quick Installation Guide
3. Port Information
Two power input possiblities: 2-pin terminal: 12-36V DC, and a coaxial power connector,
24V
1*SIM card slot
2* USB 3.0
1*TF/SD card slot
1*HDMI
1*RJ-45 network interface
1*3.5mm Audio output interface
2*com (Serial port)
-1-
4. AutomationBrowser
AutomationBrowser is the default window/homescreen for the panel PC.
INSTALLATION Steps:
Step 1: Power up the PANEL PC with appropriate power source (Two power input
possiblities: 2-pin terminal: 12-36V DC, and a coaxial power connector, 24V)
Step 2: The home screen is the AutomationBrowser:
(+ -)
Step 3: Add your custom stations (using IP addresses) and follow the instructions on the
screen.
Step 4: Expore the Main Menu (Upper Right 3 Dots)
-2-
Enter Android Settings to modify IP
Address and other network related
Andoid Setttings:
parameters. This is useful when the
AutomationBrowser is in Home
Screen mode and the user has no
access to other Apps.
Remove the status bar in the top of
Full-screen:
the screen.
Remove both status bar and the task
bar in the bottom of the screen
Immersive-Mode:
(restore task bar with a swipe up from
the bottom of the screen)
This is only used in HTML 5 mode to
show a control bar in the top of the
Navigation Bar:
screen, to navigate with previous
and next buttons, to refresh the view
or to come back in the home view
Automatically de re-scaled to t
Auto-Scale:
thescreen
width/height ratio)
Enable/disable
Pan & Zoom:
zooming of the view.
Improve the rendering with anti-alias
if the device doesnot already support
Anti-Alias:
this feature in hardware accelerator.
In most devices we don't need to
activate this option.
Either show the Android Keypad to
edit a value or usethe Keypad/alpha-
Android Keypad:
pad TEQ les
Export station list in the into the
Download/AutomationBrowser/M-
Export:
B_STATION.xml
-3-
(isotropic,
keep
panning
and
