Genki GK-3600 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
G K- 3 6 0 0
| U s e r M a n u a l

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GK-3600 and is the answer not in the manual?

Questions and answers

Related Manuals for Genki GK-3600

Summary of Contents for Genki GK-3600

  • Page 1 G K- 3 6 0 0 | U s e r M a n u a l...
  • Page 3 DISCLAIMER Read all safety tips, warning messages, terms of use, and disclaimers carefully. Users take full responsibility for all usage and operations. Familiarize yourself with the related regulations in your area. You are solely responsible for being aware of all relevant regulations and using GENKIPWR products in a way that is compliant.

  • Page 4: Table Of Contents

    CONTENTS Specifications 2. Safety Instructions 2.1 Usage 2.2 Disposal Guide 3. Getting Started 3.1 Product Introduction 3.2 Product Details 3.3 LCD Screen 3.4 Screen Display Description 3.5 Troubleshooting Sheet 3.6 UPS Mode 3.7 Solar Panel Connection 3.8 Car/Vehicle Charging 4. FAQs 5.

  • Page 5: Specifications

    1. Specifications General Info Net Weight Approximately 89.7 lbs(40.7kg) Dimensions 21.6in x 8.3in x 18.3in(55 x 21 x 46 cm) Capacity 3840Wh(80Ah/48V) Output Ports Pure Sine Wave AC (x5) 100V-120V rated 3300W,220V-240V rated 3600W 100V-120V（US、JP）/220-240V (EU) / 50Hz/60Hz Max Device(s) Power Supported by X-Boost 3000W (Constant power) USB-A(x2) 3A, per port...

  • Page 6: Safety Instructions

    2. Safety Instructions 2.1 Usage 1. Do not use the product near a heat source, such as a fire source or a heating furnace. 2. Avoid contact with any liquid. Do not immerse the product in water or get it wet. Do not use the product in rain or humid environments.

  • Page 7: Disposal Guide

    equipment, please be sure to monitor the power status to ensure that the power does not run out. 18. When in use, power supply products will generate electromagnetic fields, which are likely to affect the normal operation of medical implants or personal medical equipment such as pacemakers, cochlear implants, hearing aids, defibrillators etc.

  • Page 8: Getting Started

    3. Getting Started 3.1 Product introduction This product is a 3840Wh large capacity 3600W high power, 3 hours of high-speed charging portable energy storage power supply, using high safety performance of LiFePO4 battery. It can be used as a backup power supply in case of emergency powercut, disaster, camping and vehicles, and can also provide power for various electric tools.
  • Page 9 ① Power ON/OFF Button Instructions: Press and hold the power button for 3S to turn on/off the whole system. ② USB ON/OFF Button Instructions: Short press the USB button to turn on the USB output port, and short press it again to turn it off. USB-A x 2 TYPE-C x 3 TYPE-C x 1...

  • Page 10: Lcd Screen

    ⑨ XT90 Port (Solar Panel Input) This interface supports solar panel input or car charger input. For details, please refer to "Solar Panel Connection" on page 9 of this manual and "Car/Vehicle Charging" on page 10. ⑩ AC Input To charge the product by a household socket can achieve 1500W(100V-120V)/2200W(220V-240V) fast charging.

  • Page 11: Screen Display Description

    3.4 Screen Display Description Power display: When the product is in the charging state, the battery progress bar rotates continuously in the form of a clockwise marquee, and the battery level percentage gradually increases; when the product battery level is 0, the battery level percentage icon flashes.

  • Page 12: Ups Mode

    3.6 UPS Mode UPS Feature This product has the function of backup uninterruptible power supply. The usage and operation precautions are as follows: As shown in Pic 1 below, when the product is connected between the wall socket and the electrical appliance, and the power supply and AC switch of the product are in the ON state, the product enters the UPS working mode.

  • Page 13: Solar Panel Connection

    3.7 Solar panel connection Under the condition of light, this product can be connected to the solar panel and getting charged. The charging power is determined according to the conditions of light and weather. In this charging mode, we support solar panel input within 2000W, and the input voltage cannot exceed 160V, otherwise the product abnormality caused by it will not be covered by the warranty.

  • Page 14: Car/Vehicle Charging

    3.8 Car/Vehicle Charging When the car is in the process of starting, connect the car charging port on the car and the product through the car charging cable to charge the product. The connection method is shown in the picture below: This product supports 12V/24V car charger charging, please pay attention to the following two points when using this method to charge:...

  • Page 15: Faqs

    4. FAQs 1.What battery does the product use? It uses high-quality LiFePO4 battery. 2. What devices can the product's AC output port power? With 3000W constant power, the product's AC output port can power most household appliances. Before you use it, we recommend that you confirm the power of the appliances first and ensure the power sum of all loaded appliances is lower than the rated power.

  • Page 16: What's In The Box

    5. What’s in the Box G K- 3 6 0 0 0 | U s e r M a n u a l GK-3600 AC Charging Cable User Manual 6. Storage & Maintenance 1. Ideally, use and store the product between 20°C to 30°C(68° to 86), and always keep it away from water, intense heat, and sharp objects.
