Awning drive

Advertisement

Quick Links

Setting instructions and
wiring diagram
WAREMA WMS awning drive
Type WMS-MP
Valid from 2 August 2021
Document number 2009201 [Rev. 7 - en]
For qualified technicians only

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WMS-MP and is the answer not in the manual?

Questions and answers

Summary of Contents for WAREMA WMS-MP

  • Page 1 Setting instructions and wiring diagram WAREMA WMS awning drive Type WMS-MP For qualified technicians only Valid from 2 August 2021 Document number 2009201 [Rev. 7 - en]...
  • Page 2: Table Of Contents

    Table of contents Table of contents Information on safety......................3 Commissioning........................3 Information on the limit positions......................... 3 Aids for commissioning..........................4 Setting the motor limit positions........................5 Trial run................................. 7 Programming a hand-held transmitter into the product............8 Drive description......................11 Drive type..............................11 Function of the drive...........................11 Learning/moving to the comfort position................
  • Page 3: Information On Safety

    Window awning Conservatory The basic safety instructions awning with drop arm awning D3 can be viewed under (www.warema.de/Sicherheitshinweise). Target group These instructions are intended for use by qualified fitters >10 (commissioning) and electricians (connection work). Tab. 1: Product-specific lower limit position...
  • Page 4: Aids For Commissioning

    Commissioning Aids for commissioning UP button DOWN button Optional: WAREMA Smart programming cable (art. no. 2010652) INFO For WMS Hand-held transmitters up to a certain version (see label Rev.D/M on the back), Mode 1 needs to be performed (for the procedure, see the WMS Application brochure).
  • Page 5: Setting The Motor Limit Positions

    Commissioning Setting the motor limit positions INFO For commissioning, voltage must be applied to the drive. However, voltage should only be applied to one product at a time. The limit positions are set ( articulated arm awnings). The limit positions are not set (awning window system, facade awnings, window awning as markisolette, basic awning (formerly vertical awning),, conservatory awning D3, roller blinds). The limit positions can also be set via the WMS Central transmitter (as of rev.
  • Page 6 Commissioning Press the UP button/DOWN button. Move to the lower limit position (see Tab. 1/Page see Tab. 2/Page "Klack" Press control button A or comfort button C The drive clicks or jerks briefly. briefly. Press the UP button/DOWN button. Move to the upper limit position (see Tab.
  • Page 7: Trial Run

    Commissioning Trial run Press the DOWN button briefly. The drive stops in the lower limit position. Press the UP button briefly. The drive stops in the upper limit position. The trial run is completed. The next step is "starting the setting procedure" if the limit positions are not correct, or to connect the drive according to the wiring diagram.
  • Page 8: Programming A Hand-Held Transmitter Into The Product

    Programming a hand-held transmitter into the product Programming a hand-held transmitter into the product WMS Hand-held transmitter basic (art. no. 1002953) INFO Only product types of the same type can be operated with a WMS Hand-held transmitter basic. For programming, voltage should only be applied to one receiver. Press a button to wake up the hand-held trans- mitter.
  • Page 9 Programming a hand-held transmitter into the product WMS Hand-held transmitter plus (art no. 2016192) INFO One WMS Hand-held transmitter plus can only be used to operate the same product types. For programming, voltage should only be applied to one receiver. Press a button to wake up the hand-held trans- mitter.
  • Page 10 Programming a hand-held transmitter into the product 1x flash = awning 2x flashes = roller shutter Press an arrow button briefly. Automatic LED flashes. Press the STOP button briefly. Transmission LED lights up green for 2 s. The allocation is stored. Press the learn button briefly.
  • Page 11: Drive Description

    The limit positions are set using a hand-held transmitter, central control unit or special WMS Studio pro PC software. The drive notifies the control system of its current position. WAREMA declares herewith that the Comfort position drives contained in these instructions,...
  • Page 12: Learning/Moving To The Comfort Position

    Learning/moving to the comfort position Learning/moving to the comfort position Press the UP button/DOWN button. Move to the desired position. Press the comfort button for approx. 5 s. The transmission LED  lights up. Explanation of the colours: Green = position stored Red = procedure failed Briefly press the comfort button .
  • Page 13: Dismantling/Installation Of Pusher

    Dismantling/installation of pusher Dismantling/installation of pusher INFO Only applies to drives with a rated torque of 8 Nm to 20 Nm. With dismantling tool (art. no. 2020967): Using the dismantling tool, squeeze the catch Pull the tappet off of the motor. and push the tappet over the catch. With needle-nosed pliers: Using the needle-nosed pliers, squeeze the Pull the tappet off of the motor.
  • Page 14: Wiring Diagram

    Degree of protection IP 44 Safety class Short-term operation (S2) 4 min. Limit switch range [revolutions] Transmission frequency [GHz] 2.40-2.48 Transmission power < 10 dBm INFO Detailed technical data can be requested from WAREMA. Page 14 | 18 2009201 [Rev. 7 - en]/2021-08-02...
  • Page 15: Possible Faults

    INFO To narrow down the cause of the fault, connect the test cable/programming cable and operate the product. With the WAREMA Smart programming cable, a check can be performed without the additional activation of the hand- held transmitter. First step: operate the product using the smart test cable/programming cable.
  • Page 16 Possible faults Malfunction: The drive does not move Cause Note Remedy The drive is not programmed for the Check the programming as specified in Check the programming of the trans- hand-held transmitter. the operating instructions. mitter. The wind safety function is active. On the WMS Hand-held transmitter Wait for the delay time of the wind basic/plus, the A LED flashes during...
  • Page 17 Malfunction: In the outward direction, the drive moves in steps and in the inward direction it moves normally. Cause Note Remedy The heartbeat wind safety function is On the WMS Hand-held transmitter Check the communication between the active. basic/plus, the A LED flashes during drive and sensors.
  • Page 18 Hans-Wilhelm-Renkhoff-Straße 2 97828 Marktheidenfeld Germany WAREMA Renkhoff SE www.warema.com info@warema.com...
