Summary of Contents for Lotus HD750X
- Page 1 ™ P e r f o r m a n c e , D e l i v e r e d . 750W Impact Drill Made in China/Fabriqué en Chine Lotus Tool Group (Philippines) www.lotustoolworks.com HD750X...
-
Page 2: General Power Tool Safety Warnings
Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury. Lotus Tool Group ®... - Page 3 Certain cleaning agents such as gasoline, carbon tetrachloride, ammonia etc. may damage plastic parts. SAFETY RULES FOR DRILLS a) Hold tool by insulated gripping surfaces when performing an operation where the cutting tools may Lotus Tool Group ®...
- Page 4 Some dust created by power sanding, sawing, grinding, drilling and other construction activities contains chemical known to cause cancer, birth defect, or other reproductive harm. Some example of this are: ·Lead from lead based paints Lotus Tool Group ®...
- Page 5 European Directive 2012/19/EU. It will then be recycled or dismantled in order to reduce the impact on the environment. Electric and electronic equipment can be hazardous for the environment and for human health since they contain hazardous substances. Lotus Tool Group ®...
-
Page 6: Technical Data
TECHNICAL DATA HD750X Rated Voltage/Frequency 220V~/ 60Hz Rated Input Power 750W Revolution Per Minutes (No Load) 0-2800r/min Chuck Capacity 13mm Drilling Capacity in Mild Steel/Masonry/Wood 10mm/13mm/25mm Spindle Thread 1/2”x20 Sound Pressure Level 93.2 dB(A) Sound Power Level 104.2 dB(A) Vibration Level... - Page 7 3) Open or close the chuck jaws to a point where the opening is slightly larger than the bit size you intend to use. Also raise the front of the drill slightly to keep the bit from falling out of the chuck jaws. Lotus Tool Group...
- Page 8 To lock-on: 1) Depress the switch trigger. 2) Push in and hold the lock-on button located on the side of the handle. 3) Release the switch trigger. Lotus Tool Group ®...
-
Page 9: Wood Drilling
Apply pressure inline with the bit. Applying pressure at an angle could cause the bit to bind or break. c)Thin materials that may splinter should be drilled with another piece of wood placed underneath. d)Twist bit can be used for wood drilling but will overheat if the flutes are not cleared of wood chips Lotus Tool Group ®... - Page 10 The handle can be rotated 360°. NOTE: For convenience and ease of starting threads the hex nut has been trapped inside the molded slot in the handle assembly. Lotus Tool Group ®...
- Page 11 HAMMER/DRILL FUNCTION 1) To use the tool as a hammer, move the hammer/drill selector switch to the right. 2) To use the tool as a drill move the hammer/drill selector switch to the left. Lotus Tool Group ®...
-
Page 12: Using The Depth Gauge
·Any repair of the tool in unauthorized service centers is performed at own responsibility ·The owner of the tool is responsible for all works on the tool that were not performed in authorized service center and therefore he losses the claim for guarantee. Lotus Tool Group ®... -
Page 13: Exploded View
EXPLODED VIEW Lotus Tool Group ®... -
Page 14: Parts List
On -Off Switch Big Gear Wire Needle Bearing Capacitor Function Knob Power Cord Protector Function Plate Power Cord Bearing Support+Impact Block Housing Screw Ball Bearing Right Housing Armature Bolt Field Handle Support Brush Holder Side Handle Lotus Tool Group ®...
