Summary of Contents for Sunerg Solar Energy Frog+
- Page 1 INSTALLATION MANUAL FORCED WITHOUT BOILER NATURAL...
-
Page 2: Meaning Of Symbols
Meaning of symbols Failure to comply with these instructions carries a risk of death by voltage. Danger Failure to comply with these instructions may cause serious health damage, e.g. burns or serious injury. Danger Failure to comply with these instructions may cause serious damage to the control unit, to the plant or environment. -
Page 3: Electrical Connections
Electrical Resistance Installation Before proceeding to the installation and connection of the electrical resistance read Warning carefully and make sure that you have understood the following instructions. Boiler Installation (only for Frog+ Forced and Frog+ Natural) -Place and fasten the boiler firmly on the wall by means of suitable brackets. -Inside the boiler must be inserted the photovoltaic electrical resistance (this Warning resistance must not be connected to the grid of the distributor) the same is already... - Page 4 Example of electrical installation with WI-FI control unit T° Sensor Grounding Power supply 220V Resistance supply Brown Blue (Indifferent polarity of the resistance for the 2 output cables) Frog+ WI-FI Control Unit Sensor cable Forced or Natural (inside the colors (There can be 2, Boiler red, yellow and...
-
Page 5: Control Unit Electrical Connections
Control unit electrical connections Red indicator Green indicator Presence supplied of 220V resistance electric grid Grounding Photovoltaic modules Electrical resistance Yellow Black Temperature sensor... - Page 6 Sunerg Solar Energy Srl Via Donini, 51 Loc. Cinquemiglia 06012 Città di Castello – PG info@sunergsolar.com www.sunergsolar.com +039 075 85 40 018 P.IVA 03728000542...
