U SER M A N UA L
ICA Turn-Assist XR45
Turning assistant
Blind Spot Information System
AXION systems comply with the current CE and EMC regulations. Copyright ©
2020 AXION AG
All rights reserved. No part of this publication may be reproduced, processed or
transmitted in any form or by any means, including photocopying, recording or
any other electronic or mechanical process, without the written permission of the
publisher.
The AXION camera monitor systems comply with the current CE and EMC regulations.
Copyright © 2020 AXION AG
All rights reserved. No part of this publication may be reproduced in any form, including
photocopying, recording, or any other electronic or mechanical process without the written permission of the publisher distributed.
03/2022 EN
Version: 1.00
Subject to change and error.
Advertisement
Table of Contents
Summary of Contents for Axion ICA Turn-Assist XR45
- Page 1 The AXION camera monitor systems comply with the current CE and EMC regulations. Copyright © 2020 AXION AG All rights reserved. No part of this publication may be reproduced in any form, including photocopying, recording, or any other electronic or mechanical process without the written permission of the publisher distributed.
-
Page 2: Table Of Contents
Table of contents General _________________________________________________________________3 General notes_____________________________________________________________3 Explanation of the safety instructions __________________________________________3 Storage instructions ________________________________________________________3 Intended use _____________________________________________________________4 Disclaimer________________________________________________________________5 Warranty ________________________________________________________________5 Product information _______________________________________________________6 Scope of delivery __________________________________________________________6 Technical data ____________________________________________________________7 Operating and display elements ______________________________________________8 Area of use _______________________________________________________________8 Functional description ______________________________________________________9 Assembly and commissioning________________________________________________10 Safety instructions for assembly ______________________________________________10... -
Page 3: General
General General Notes This document describes the function, Furthermore, the document is intended for installation, operation, maintenance and instructed drivers who have the qualification troubleshooting of the ICA Turn Assist XR45 and suitability to drive the motor vehicle. bending system. Make sure you have read and understood the This document is aimed at professional complete instructions and all safety... -
Page 4: Intended Use
Intended use The ICA Turn-Assist XR45 is designed exclusively for use in closed vehicles with 12V/24V power supply. Qualification and suitability for driving the vehicle cannot be compensated or replaced by using the turn assist system! The road traffic regulations must always be followed in full. The system does not... -
Page 5: Disclaimer
Neither AXION AG nor any of its other. AXION AG also reserves the right to affiliates or subsidiaries shall be held... -
Page 6: Product Information
Product information Scope of delivery Figure Description Article number MWR-XR45 Radar sensor incl. cover ICA-MCU45 Control unit (MCU) ICA-WLED45 LED warning light Warning buzzer ICA-WBZ45 ICA-EBT45 Control knob (button) Connection cable set ICA-MCC45 Radar connection cable ICA-RCC45 Extension cable 6m WPC-4506 Screws + nuts Mounting material... -
Page 7: Technical Data
Technical Data Radar Specifications - MWR-XR45: Dimensions 102 mm x 104 mm x 29mm (WxHxD) Operating voltage DC 9-32V Power consumption <495mA @ DC 12V Frequency 76~77 GHz Frame Rate 20 Hz 180° Resolution ± 0,25 m Waterproofness IP67 Operating temperature -40°C - 85°C Storage temperature -40°C - 85°C... -
Page 8: Operating And Display Elements
Operating and Display elements The system can be operated via the button included in the scope of delivery. The brightness level of the LED warning light can be adjusted by pressing the button. The brightest level is automatically reactivated each time the system is started. The LED warning light is used as an indicator element for the system status and for all visual indications and warnings: LED lights up yellow... -
Page 9: Functional Description
For this purpose, a camera is mounted on the outside of the vehicle, which displays the cover area, and a monitor is mounted in the area of the A-pillar. For recommendations, please contact the manufacturer AXION (see reverse) or your specialist dealer. -
Page 10: Assembly And Commissioning
Assembly and commissioning Safety instructions for the assembly Observe the safety instructions and requirements prescribed by the vehicle manufacturer and the motor trade! Ensure that you have read and understood the instructions and all safety information before using this product. Failure to follow these instructions may result in serious injury or death. - Page 11 • Never use the appliance outside the specified temperature range. • Do not use the unit if the relative humidity is above the specified limit. • Do not use the device if it interferes with the safe driving of the vehicle. •...
-
Page 12: Wiring Diagram
Wiring diagram Plug connections are identical (6m) Radar R_Lamp LED warning light Buzzer BSW_Power Control unit Button ACC / VBAT (Kl.15 12/24 Vdc) Red Black GND (ground terminal 31) Brown Left indicator Right Grey indicator Speed Purple (analogue speed signal) Yellow (Reverse, not used) (Side... -
Page 13: Assembly Instructions
Assembly instructions The radar must be mounted in the designated mounting area. This begins at a distance of 1 m from the technical front edge of the vehicle and ends at a distance of 6 m from the front edge. The mounting height starts at 0.6 m and is limited to a maximum of 1.2 m measured from the centre of the radar to the ground. -
Page 14: Parameterisation Of The System
The mounting position and orientation can be freely selected. Parameterisation of the system A separately available USB-CAN adapter and the SystemSetup application are used to parameterise the radar sensor and calibrate the speed: See document: AXION App Instructions XR45.pdf USB CAN adapter:... -
Page 15: Troubleshooting
Troubleshooting Error pattern Possible causes Solution System does not start • Faulty connection • Check the connections according to the connection diagram • Check power supply • Plug connection or cable • Check plug Warning LED does not damaged connection and light up at system start-up cables •... -
Page 16: Further Information
Recycling materials helps to conserve natural resources. Simplified EU Declaration of Conformity AXION AG hereby declares that the ICA Turn-Assist XR45 complies with EU Directive 2014/30EU. The full text of the EU Declaration of Conformity at the following email: service@axionag.de...
