Page 1
Quick Installation Guide KBD-3NET Network Keyboard with joystick, supports ONVIF protocol, RJ45, 12VDC Learn more about eneo IN series on our YouTube channel.
ABOUT THIS DOCUMENT In this document you will find a comprehensive description of a specific series of devices, which we have prepared with great care and accuracy in order to provide you with a deep insight into the general functions and features that characterize this series of devices� However, you should be aware that the detailed characterization presented in this document is based on the general product line�...
SAFETY INSTRUCTIONS Read the safety instructions and the operating instructions carefully before installing the product� Depending on the product type, individual points may be omitted� Mounting & Installation • Ensure that the intended mounting location is suitable for the respective product (e�g� in terms of weight)� •...
Page 7
Operation • The devices may only be operated within the temperature and humidity ranges specified in the data sheet� • Sufficient ventilation must be provided to prevent overheating� This applies in particular to devices such as recorders and switches that can generate heat� •...
• the product detail pages on the eneo website (www.eneo-security.com), • the eneo download portal (https://datacloud.videor.com/s/eneodownloadportal)� In case that previous link is broken, the latest link to the eneo download portal can be found on the respective eneo product page at www. eneo-security.com�...
PRIOR TO USE • Make sure that the device is working properly and meets your requirements� • Make sure that the latest firmware is installed on the device� • Install the product in a suitable location� • Depending on the location, use the material supplied for installation� Dimensions (in mm) &...
1 - PRODUCT OVERVIEW 1.1 - Brief Description The A3 keyboard is a brand new product with an innovative design made of PC + ABS, which provides high manoeuvrability and effectively solves the problem of camera control when using the website� The elegant and attractive appearance, industrial line crossing module display and clear characters give the A3 keyboard a high-end atmosphere�...
2 - PRODUCT INTERFACE DESCRIPTION No� Item Description DC 12V Standard 5�5/2�1 Power Interface, DC 12V A±10 RJ-45 Network Interface, supports RJ-45 RS-485 Supports RS-422 & RS-485 Interface 2.1 - Connections 2.1.1 - Networking Network mode ONVIF PTZ Camera connection schematic diagram Video Conference Camera Cable Cable...
Page 12
The keyboard is connected to the PTZ camera in the same LAN and ensures that the IP address is in the same network segment, such as: 192�168�1�123 and 192�168�1�111 belong to the same network segment; 192�168�1�123 and 192�168�0�125 does not belong to the same segment, at this time need to modify the keyboard or PTZ camera IP address�...
3 - DESCRIPTION OF KEYBOARD FRONT KEY 3.1 - Function Key Note NOTE: The control keyboard can not be invoked if this feature is not built into the following protocols or fastball itself Create preset button: Press [SET PRESET], then the corresponding number and finally SET PRESET [confirm] to confirm the setting�...
Exit button� ENTER / remote Confirmation button sensing keys Keys for setting the keyboard� To query the list of added devices� Keyboard device information, display of keyboard firmware version, hardware version, web version, IP, gateway, subnet The camera number to quickly switch to the device that binds the coding to the camera (CAM NUMBER ENTER Switch) 3.2 - Rotary Rocker Operating...
4 - ADD DEVICES 4.1 - Add network equipment Use the keyboard to add LAN devices as follows: 1� Click on the keyboard to enter the main menu� 2� Select >Device: Add to add webcam, fill in: IP, Port, username, password, camera add finish 3�...
5 - NETWORK CONFIGURATION 5.1 - Home Link and Login Connect the power cord of the keyboard and connect the network cable� When the keyboard is started, the local machine will be displayed on the display screen IP 192�168�x�xxx, enter this IP address into the browser to access the page configuration initial user name: admin;...
Page 17
4� Click the button to add and modify the device parameters in the LAN� The page shows the following: Enter the device number, corresponding IP address, port number and user name and click Save� NOTE: When you enter the keyboard WEB terminal to add a device successfully, it will be synchronized with the keyboard�...
5.2 - WEB and network setting LAN settings can modify the device IP acquisition mode and port parameters, as shown below: Static address (STATIC): Changes the network type to static when the user needs to set the network segment by himself, and fill the network segment information that needs to be modified�...
5.4 - System Reset When device is reset, keyboard removes configuration information and clears added device� 5.5 - Restart When the device runs for a long time, need to restart maintenance, click restart to achieve the purpose of restart maintenance� 5.6 - Import configuration Import the device information of the previous keyboard (for example, export the file type when the keyboard is a multiplex device, use as an import to another device when adding a...
5.7 - Export configuration Export the current keyboard to add multi-channel device information, can be exported to other keyboard devices for use� 5.8 - Version Information Displays software and hardware information for the current keyboard 6 - FAQ 1� When the screen shows connection failure, check that the device corresponding to this IP is normal in the LAN Connection�...
ÜBER DIESES DOKUMENT In diesem Dokument finden Sie eine umfassende Beschreibung einer bestimmten Geräteserie, die mit großer Sorgfalt und Genauigkeit erstellt wurde, um Ihnen einen detaillierten Einblick in die allgemeinen Funktionen und Merkmale zu geben, die diese Geräteserie auszeichnen� Bitte beachten Sie jedoch, dass sich die detaillierte Charakterisierung in diesem Dokument auf die allgemeine Produktlinie bezieht�...
SICHERHEITSHINWEISE Lesen Sie die Sicherheitshinweise und die Bedienungsanleitung vor der Installation des Produkts sorgfältig durch� Je nach Produkttyp können einzelne Punkte entfallen� Montage & Installation • Stellen Sie sicher, dass der vorgesehene Montageort für das jeweilige Produkt geeignet ist (z�B� hinsichtlich Gewicht)�...
Betrieb • Die Geräte dürfen nur innerhalb der im Datenblatt angegebenen Temperatur- und Feuchtebereiche betrieben werden� • Zur Vermeidung von Überhitzung ist für ausreichende Belüftung zu sorgen� Dies gilt insbesondere für Geräte wie Recorder und Switches, die Wärme erzeugen können� •...
• die Produkt-Detailseiten auf der eneo Website (www.eneo-security.com), • das eneo Download-Portal (https://datacloud.videor.com/s/eneodownloadportal)� Sollte der vorherige Link nicht mehr funktionieren, finden Sie den aktuellen Link zum eneo Downloadportal auf der jeweiligen eneo Produktseite unter www.eneo-security.com� • das Download-Paket Ihrer Firmware� Die vollständigen Open Source Software-Lizenzinformationen für Ihr Produkt sind in dem entsprechenden Software-Download-Paket enthalten, das Sie in unserem Download-Portal finden�...
VOR GEBRAUCH / INSTALLATION • Vergewissern Sie sich, dass das Gerät ordnungsgemäß funktioniert und Ihren Erwartungen entspricht� • Vergewissern Sie sich, dass auf dem Gerät die neueste Firmware installiert ist� • Installieren Sie das Produkt an einem geeigneten Ort� • Nutzen Sie für die Montage je nach Ort das mitgelieferte Material� Abmessungen (in mm) &...
1 - PRODUKTÜBERSICHT 1.1 - Kurzbeschreibung Die A3-Tastatur ist ein brandneues Produkt mit einem innovativen Design aus PC + ABS, das eine hohe Beweglichkeit bietet und das Problem der Kamerasteuerung bei der Webseitennutzung effektiv löst� Das elegante und ansprechende Aussehen, das industrielle Linienüberquerung-Modul-Display und die klaren Zeichen verleihen der A3-Tastatur eine hochwertige Atmosphäre�...
2 - INTERFACE BESCHREIBUNG Nr� Element Beschreibung DC 12V Standard 5�5/2�1 Stromanschluss, DC 12V A±10 RJ-45 Netzwerkanschluss, unterstützt RJ-45 RS-485 Unterstützt RS-422 & RS-485 Schnittstelle 2.1 - Verbindungen 2.1.1 - Vernetzung Netzwerkmodus ONVIF PTZ Kamera Anschlussschema Videokonferenz-Kamera Kabel Kabel Dome Kamera Dome Kamera...
Page 30
Die Tastatur ist mit der PTZ-Kamera im selben LAN verbunden und stellt sicher, dass die IP- Adresse im selben Netzwerksegment liegt, z�B�: 192�168�1�123 und 192�168�1�111 gehören zu demselben Netzwerksegment; 192�168�1�123 und 192�168�0�125 gehören nicht zum selben Segment, dann müssen Sie die IP-Adresse der Tastatur oder der PTZ-Kamera ändern�...
3 - KEYBOARD-TASTEN 3.1 - Tastenfunktionen NOTE: Die Steuerungstastatur kann nicht aufgerufen werden, wenn diese Funktion nicht in den folgenden Protokollen oder Fastball selbst integriert ist Preset-Taste erstellen: Drücken Sie [SET PRESET], dann die entsprechende Nummer und SET PRESET schließlich [confirm], um die Einstellung zu bestätigen� Rufen Sie die voreingestellte Taste auf: Drücken Sie [CALL PRESET] und dann die Nummer, CALL PRESET drücken Sie [confirm], um die Voreinstellung erfolgreich aufzurufen�...
0 - 9 0-9, Zifferntasten für die Funktionsnummerierung� Geschwindigkeit, mit der Sie die Geschwindigkeit der Wippe zur Kamera einstellen können� SPEED Sie haben die Wahl zwischen niedrig, mittel und hoch� Taste zum Beenden� ENTER / Tasten zur Taste zur Bestätigung� Fernabfrage Tasten zur Einstellung des Keyboards�...
4 - GERÄTE HINZUFÜGEN 4.1 - Netzwerkgeräte hinzufügen Verwenden Sie das Keyboard, um LAN-Geräte wie folgt hinzuzufügen: 1� Drücken Sie auf die Tastatur, um das Hauptmenü zu öffnen 2� Wählen Sie >Gerät: Hinzufügen, um eine Webcam hinzuzufügen, geben Sie ein: IP, Port, Benutzername, Kennwort, Kamera hinzufügen fertig 3�...
5 - NETZWERKKONFIGURATION 5.1 - Home Link und Login Schließen Sie das Netzkabel des Keyboards an und verbinden Sie es mit dem Netzwerkkabel� Nach dem Einschalten des Keyboards erscheint auf dem Display die IP 192�168�x�xxx, geben Sie diese IP-Adresse in den Browser ein, um auf die Seite Konfiguration zuzugreifen initialer Benutzername: admin;...
Page 35
4� Klicken Sie auf die Schaltfläche, um die Geräteparameter im LAN hinzuzufügen und zu ändern� Die Seite zeigt Folgendes an: Geben Sie die Gerätenummer, die entsprechende IP-Adresse, die Portnummer und den Benutzernamen ein und klicken Sie auf Speichern� NOTE: Wenn Sie das WEB-Terminal der Tastatur eingeben, um ein Gerät erfolgreich hinzuzufügen, wird es mit der Tastatur synchronisiert�...
5.2 - WEB- und Netzwerkeinstellungen Mit den LAN-Einstellungen können Sie den IP-Erfassungsmodus und die Port-Parameter des Geräts ändern, wie unten gezeigt: Statische Adresse (STATIC): Ändert den Netzwerktyp auf statisch, wenn der Benutzer das Netzwerksegment selbst festlegen muss, und füllt die zu ändernden Netzwerksegmentinformationen aus�...
5.4 - System Reset Wenn das Gerät zurückgesetzt wird, entfernt die Tastatur die Konfigurationsinformationen und löscht das hinzugefügte Gerät� 5.5 - Neustart Wenn das Gerät lange Zeit läuft und Sie die Wartung neu starten müssen, klicken Sie auf Neustart, um den Zweck der Neustart-Wartung zu erreichen� 5.6 - Konfiguration importieren Importieren Sie die Geräteinformationen der vorherigen Tastatur (exportieren Sie z�B�...
5.7 - Konfiguration exportieren Exportieren Sie die aktuelle Tastatur, um Mehrkanal-Geräteinformationen hinzuzufügen� Diese können zur Verwendung auf andere Tastaturgeräte exportiert werden� 5.8 - Versionsinformationen Zeigt Software- und Hardware-Informationen für die aktuelle Tastatur an 6 - FAQ 1� Wenn der Bildschirm „Verbindungsfehler“ anzeigt, überprüfen Sie, ob das Gerät, das dieser IP entspricht, normal in der LAN-Verbindung ist�...
Page 40
Videor E. Hartig GmbH Exclusive distribution through specialised trade channels only. Videor E. Hartig GmbH Carl-Zeiss-Straße 8 63322 Rödermark / Germany Tel. +49 (0) 6074 / 888-0 Technical changes reserved Fax +49 (0) 6074 / 888-100 www.videor.com...
