- Page 1 Dual Clima HT Commissioning Guide...
-
Page 2: Table Of Contents
Contents 1.0 Pre-Commissioning ...................... 1.1 Pre-Commissioning Checks ................1.2 Filling the System ....................2.0 Heat Pump Electrical Connections ................2.1 Controller Connection ................... 2.2 Room Thermostat Connection ................2.3 DHW Connection ....................2.4 Connection of Additional Circulating Pumps ............ 3.0 Heat Pump Controller and Settings ................4.0 System Configuration .................... -
Page 3: Pre-Commissioning
1.0 Pre-Commissioning 1.1 Pre-Commissioning Checks Pre commissioning 1. Ensure the heat pump is installed in accordance with the installation manual. 2. Ensure power is isolated. 3. Remove the side and front panels as well as the isolation panel of the electrical enclosure. 4. -
Page 4: Heat Pump Electrical Connections
2.0 Heat Pump Electrical Connections 2.1 Controller Connection COMM4 Heat Pump Controller Single (Cat 6) Cable The heat pump touch screen controller must be connected as per the diagram above. Connection between Power Card PCB and Controller must be made from COMM4 to BAGV. This connection is LOW VOLTAGE ONLY. A maximum distance of 30 metres and cable diameter of 0.25mm²... -
Page 5: Room Thermostat Connection
2.2 Room Thermostat Connection Connection of room thermostat(s) to the heat pump for HEATING must be made using terminals (24-25). When these contacts are closed the heat pump will receive a run signal to operate in heating mode only. Connection of room thermostat(s) to the heat pump for COOLING must be made using terminals (24-26) for cooling. -
Page 6: Dhw Connection
2.3 DHW Connection DHW Sensor Connection of the DHW sensor must be made into terminals 19 and 20. The 5m long sensor supplied with the heat pump is a 5K NTC type. A maximum distance of 20 metres and cable diameter of 0.25mm2 - 1.25 mm2 should be observed. -
Page 7: Connection Of Additional Circulating Pumps
2.4 Connection of Additional Circulating Pumps Connecting a single backup pump for use in both Heating/ Cooling and DHW mode This circulation pump will run in parallel with the appliance’s internal pump (C1) and will be active when the appliance is running in either Heating, Cooling or DHW production mode. The pump is connected between electrical terminals 9 (Live) and 11 (Neutral). -
Page 8: Heat Pump Controller And Settings
3.0 Heat Pump Controller and Settings Switching the heat pump ON and OFF To switch on the heat pump, press and hold the On button (9) for 5 seconds. The heat pump will switch on in the last previously selected operating mode and the On button will light up in red. Home screen Temperature selection: Programming Menu touch button:... - Page 9 Working Status Screen To access the Working Status screen, press setting menu button (7) and then System Parameters. This is used to live view all vital heat pump operations. Working Status r/min 24.7 ℃ Tout: 2.00 0.15 Ps:Mpa 38.5 ℃ ℃...
-
Page 10: System Configuration
4.0 System Configuration To Access parameters, press setting menu button (7) and then System Parameters, Enter the password 99. Below is a list of parameters relevant to different system types. Work through each parameter and change to suit your system type, emitters and DHW requirements. For a full list of parameters see Installation Manual. Temperature Set Points Parameter Description... -
Page 11: Domestic Hot Water
5.0 Domestic Hot Water If not using DHW, change parameter P63 to 0 and disregard the following To meet requirements set in MBIE NZBC, clause G12 stored DHW must be heated to 60°C once a day, or 60°C for the period of one hour once a week, for protection against Legionella. -
Page 12: High Flow Temperatures And Underfloor
6.0 High Flow Temperatures and Underfloor With underfloor installations it is important that high flow temperature ie. >50°C are not introduce to the floor. High temperatures can cause damage to certain construction materials as well as being uncomfortable. Please fit the supplied sticker to the bezel/surround of the heat pump controller to advise users of hazards when increasing the setpoint. -
Page 13: Resetting Errors
7.0 Resetting Errors To reset errors, the heat pump power supply must be cycled off and on at the isolation switch. At the point of commissioning a common error is E15 (Insufficient water flow) this is likely caused by air still being present in the system or installation debris blocking the filter ball valve.
